WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
CLIMATE CONTROL –pages 12-13
-
Explain the different air modes to customer.
TIRE PRESSURE MONITORING SYSTEM
(TPMS) – page 28
Explain TPMS function to customer.
- When illuminated, one or more
tires are under-inflated.
- Blinks for approximately one minute
then remains illuminated when there
is a malfunction with the TPMS.
BLUE LINK – pages 20-21
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
after enrollment to initiate Welcome Call
CLOCK ADJUSTMENT – page 26
Hour
Pressing the H button will advance
the time displayed by one hour.
Minute
Pressing the M button will advance
the time displayed by one minute.
VEHICLE SETTINGS – pages 10-11 & 23-25
- Demonstrate vehicle settings
in instrument cluster
- Demonstrate navigation use,
enter dealer address
- Show radio presets
BLUETOOTH – pages 18-19
- Demonstrate phone pairing Refer to
www.hyundaiusa.com/bluetooth
- Demonstrate QR code
MAINTENANCE
Scheduled Maintenance
Normal Usage
Engine Oil and Filter
Replace
7,500 or 12 mos.
Tire Rotation
Perform
7,500
Inspect
7,500
Air Cleaner Filter
Replace
30,000
Battery Condition
Inspect
7,500
Vacuum Hose
Inspect
7,500
Climate Control Air Filter
Replace
15,000
(For Evaporator and Blower Unit)
Air Conditioning Refrigerant
Inspect
15,000
Brake Hoses & Lines
Inspect
15,000
Drive Shafts & Boots
Inspect
15,000
Electronic Throttle Control
Inspect
15,000
Exhaust Pipe & Muffler
Inspect
15,000
Front Brake Disc / Pads, Calipers
Inspect
15,000
Rear Brake Drums / Linings
Inspect
15,000
Rear Brake Disc / Pads
Steering Gear Box, Linkage & Boots/
Inspect
15,000
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Inspect
15,000
Brake/Clutch Fluid
Inspect
30,000
Fuel Filter
Inspect
30,000
Fuel Lines, Fuel Hoses and Connections
Inspect
30,000
Fuel Tank Air Filter
Inspect
30,000
Parking Brake
Inspect
30,000
Vapor Hose, Fuel Tank & Fuel Filler Cap
Inspect
30,000
Manual Transmission Fluid
Inspect
37,500
1st Inspect 60,000 or 72 mos.
Drive Belt (Alt, A/C)
Add'l Inspect 15,000 or 24 mos.
Spark Plugs (Iridium Coated)
Replace
100,000 or 10 yrs. Replace
1st Replace 120,000 or 10 yrs.
Coolant
Add'l Replace 30,000 or 24 mos.
Automatic Transmission Fluid
No check, No service required
*See Owner's Manual for details.
Looking for more detailed information?
This Quick Reference Guide does not replace your vehicle's Owner's
Manual. If you require additional information or are unsure of a specific issue, you should always refer to the
vehicle's Owner's Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing; however,
specifications and equipment can change without notice. No warranty or guarantee is being extended in this
Quick Reference Guide, and Hyundai reserves the right to change product specifications and equipment at any
time without incurring obligations. Some vehicles are shown with optional equipment. Specifications apply to
U.S. vehicles only. Please contact your Hyundai dealer for current vehicle specifications.
Severe Usage*
Replace
3,750 or 6 mos.
Perform
7,500
Inspect
Same As Normal
Replace
More Frequently
Inspect
Same As Normal
Inspect
Same As Normal
Replace
More Frequently
Inspect
Same As Normal
Inspect
Same As Normal
Inspect
7,500 or 6 mos.
Inspect
Same As Normal
Inspect
Same As Normal
Inspect
More Frequently
Inspect
More Frequently
Inspect
More Frequently
Inspect
Same As Normal
Inspect
Same As Normal
Inspect
Same As Normal
Inspect
Same As Normal
Inspect
Same As Normal
Inspect
More Frequently
Inspect
Same As Normal
Replace
75,000
Inspect
Same As Normal
More Frequently
Replace
Same As Normal
Replace
60,000
NP150-82014-C
(Rev 12/11/13)
Printing 12/14/13
ELANTRA COUPE
HYUNDAI
Quick Reference Guide
www.hyundai.com
1-800-243-7766
Roadside Assistance:
1-800-633-5151
Consumer Affairs:
1-800-967-2346
XM
Radio:
®
1-855-2BLUELINK
Blue Link:
(1-855-225-8354)
