Go/No Go Test
TM
Xperia
Z3 Compact
D5803, D5833
1291-4301 Rev 2
”
Sony Mobile Communications AB
Company Internal

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Xperia Z3 Compact and is the answer not in the manual?

Questions and answers

Related Manuals for Sony Xperia Z3 Compact

Summary of Contents for Sony Xperia Z3 Compact

  • Page 1 Go/No Go Test Xperia Z3 Compact D5803, D5833 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal...
  • Page 2 Loss Values – Antenna Coupler CMW-Z11..........6 1.3.2 Revision History ................8 D5803 no LTE is implemented in SERPII. D5833 no LTE is implemented in SERPII. D5803 & D5833 all bands is implemented in CMWRun 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 2(8)
  • Page 3 Nano USIM Card, instrument specific GSM-850/900/1800/1900 WCDMA-850/900/1700/1900/2100 LTE-BAND 1/2/3/4/5/7/8/13/17/20/28/40 Put the grid positioning holder with its reference point in position J15 and place the phone as shown in the adjacent picture. 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 3(8)
  • Page 4 This phone is available in 2 versions, D5803 and D5833, including the following bands: D5803: GSM-850/900/1800/1900 WCDMA-850/ 900/1700/1900/2100 LTE-1/3/5/7/8/28/40 not to be tested in SERPII, only in CMWrun D5833: GSM-850/900/1800/1900 WCDMA-850/ 900/1900/2100 LTE-1/2/3/4/5/7/8/13/17/20 not to be tested in SERPII, only in CMWrun 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 4(8)
  • Page 5 25.02 18.50 22.02 WCDMA 1900 18.00 18.42 18.00 22.42 High 15.00 18.65 15.00 19.65 14.00 17.79 14.00 17.79 WCDMA 2100 14.00 17.77 14.00 17.77 High 13.00 15.52 13.00 16.52 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 5(8)
  • Page 6 19.00 15.50 WCDMA 2100 22.00 11.90 18.00 15.00 High 20.00 12.10 19.00 14.80 21.00 14.00 17.00 17.60 LTE Band 1 21.00 12.90 16.00 16.90 High 20.00 13.60 16.00 16.20 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 6(8)
  • Page 7 13.90 LTE Band 20 13.00 15.20 High 12.00 16.00 15.00 9.20 LTE Band 28 17.00 9.10 High 18.00 9.50 18.00 19.40 LTE Band 40 20.00 21.70 High 24.00 24.60 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 7(8)
  • Page 8 Test and Calibration Repair Instruction Revision History Rev. Date Changes / Comments 2014-09-03 Initial release 2014-09-18 Added D5803 and D5833 to CMWrun 1291-4301 Rev 2 ” Sony Mobile Communications AB Company Internal 8(8)
