Taiga Patch Book
Taiga Desktop Electronic Musical Instrument Patch Book V1.0.1
Taiga is a trademark of Pittsburgh Modular LLC. Copyright © Pittsburgh Modular LLC. 2022

Advertisement

loading
Need help?

Need help?

Do you have a question about the Taiga and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pittsburgh Modular Taiga

Summary of Contents for Pittsburgh Modular Taiga

  • Page 1 Taiga Patch Book Taiga Desktop Electronic Musical Instrument Patch Book V1.0.1 Taiga is a trademark of Pittsburgh Modular LLC. Copyright © Pittsburgh Modular LLC. 2022...

  • Page 2: Patch Examples

    1 Patch Examples 1.1 Patch Book Overview: This Patch Book is a guide exploring the functionality of Taiga. It is not meant to be a collection of presets. The examples are designed to showcase the functionality of each module within the instrument using the simplest patch possible. This ensures that the patches are less confusing and keeps the focus of the patch on the highlighted function.
  • Page 3 The [Freq CV 2 Knob] is an attenuverter meaning it is off in the 12 o’clock position. Turning to the left adds negative modulation and turning to the right adds positive modulation. This can often be the cause of Taiga not making sound. The filter output provides a constant tone in the default patch.
  • Page 4 3.1 Oscillator MIDI Control and Free Running Mode The pitch of Taiga Oscillators is controlled using 2 modes. Midi and free running. Enable or disable the MIDI Mode mode by pressing and holding the [Edit Button] then pressing the [Seed Button].
  • Page 5 3.2 Paraphonic Taiga Setup Taiga to play 2 notes simultaneously while maintaining a monophonic filter and monophonic Dynamics signal path. This is not a perfect solution or a replacement for true polyphony. Many hardware compromises limit the functionality but if you want to play 2 notes at the same time, Paraphonic Mode can do that.

  • Page 6: Control Examples

    3 Control Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source ch 4 osc 1 noise Random decay decay adsr dynamics random time echos Envelope...
  • Page 7 3 Control Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source ch 4 osc 1 noise decay decay adsr dynamics random time echos mode lfo range...
  • Page 8 4.1 Oscillator Overview The Taiga oscillators have a wide range of sonic possibilities but there are a few rules to controlling them. The [Shape Knob] and [Shape CV Knob] work together to determine the shape of the waveform.
  • Page 9 Repeat this patch with the other 2 oscillators and Taiga turns into an unstable, rumbling beast. The [FM Input Jack] is linear. Exponential FM is available using the [Pitch Input Jack].
  • Page 10 4 Oscillator Patch Examples Taiga pittsburgh modular filter output glide response regen ch 2 attack attack control adsr pitch pitch pitch osc 2 mixer clock source frequency ch 4 osc 1 noise decay decay adsr dynamics random time echos mode...
  • Page 11 2 can be used as a free running modulation source. The Taiga mixer is actually 2 mixers. The sum of channels 1 and 2 is internally routed to the mix output of channels 3, 4, and the preamp. Patching the [Mixer 1 + 2 Output Jack] removes it from the [Mixer Mix Output Jack].
  • Page 12 5 Mixer / Preamp Patch Examples Taiga Taiga pittsburgh pittsburgh modular modular filter filter output output glide glide ch 2 ch 2 attack attack attack attack response response regen regen control control adsr adsr pitch pitch pitch pitch pitch pitch...
  • Page 13 5.3 Feedback Mixer The Preamp can be used to amplify external signals, overdrive internal signals, and to create feedback loops within Taiga. Patch [Echos Output Jack] into the [Preamp Input Jack]. Experiment with the delay time and regeneration of the delay along with the gain of the preamp.
  • Page 14 5 Mixer / Preamp Patch Examples Taiga Taiga pittsburgh pittsburgh modular modular filter filter output output glide glide ch 2 ch 2 attack attack attack attack response response regen regen control control adsr adsr pitch pitch pitch pitch pitch pitch...
  • Page 15 6 Filter Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source ch 4 osc 1 noise decay decay adsr dynamics random time echos mode...
  • Page 16 6 Filter Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source ch 4 osc 1 noise decay decay adsr dynamics random time echos mode...
  • Page 17 7 ADSR Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source ch 4 osc 1 noise decay decay adsr dynamics random time echos mode...
  • Page 18 8 Dynamics Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 19 8 Dynamics Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 20 9 Echos Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 21 10 Utility Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 22 10 Utility Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 23 10 Utility Patch Examples Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock frequency source Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 24 11 User Patch Sheet Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock source frequency Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 25 11 Patch Sheet Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock source frequency Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos mode...
  • Page 26 11 User Patch Sheet Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock source frequency Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 27 11 User Patch Sheet Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock source frequency Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
  • Page 28 11 User Patch Sheet Taiga pittsburgh modular filter output glide ch 2 attack attack response regen control adsr pitch pitch pitch osc 2 mixer clock source frequency Taiga ch 4 osc 1 noise decay decay adsr dynamics random time echos...
