BALCONY SOLAR PANEL
EN
MOUNTING SYSTEM
Alu PV balcony mount (vertical)
Art.-Nr. :5410006

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5410006 and is the answer not in the manual?

Questions and answers

Related Manuals for SolarV 5410006

Summary of Contents for SolarV 5410006

  • Page 1 BALCONY SOLAR PANEL MOUNTING SYSTEM Alu PV balcony mount (vertical) Art.-Nr. :5410006...

  • Page 2: Dimension(Mm)

    BALCONY SOLAR PANEL MOUNTING SYSTEM Dimension(mm)  Alu-rail  J-Bracket 69.80 Ø8.5  Rail connector Ø10  End clamp  Hose clamp Ø8  M8*90 Hexagonal Bolt  M8*25 Hexagonal Bolt Ø8 Ø8 Ø8 Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 3 Tools (not incl.) Copyright© 2022 SolarV GmbH All rights reserved. M8 M10 Allen key Cordless screwdriver Use M10*25 bolt to connect the alu rails with rail connector Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 4 Mount the solar panel to the assembled rail with the end clamps and M8*30 bolts Tips: Please measure the height of the balcony railing before Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 5 Mount the J-brackts onto the solar panel with the M8*25 bolts Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 6 Hang the solar panel on the balcony railing with the M8*90 bolts to secure the J-brackets Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 7 Mount the assembled rail onto the balcony with hose clamps Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 8 Tighten all screws and bolts to secure the system Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 9 Copyright© 2022 SolarV GmbH All rights reserved.
  • Page 10 SolarV GmbH SolarV GmbH SolarV GmbH info@solarv.de info@solarv.de info@solarv.de www.solarv.de www.solarv.de www.solarv.de Copyright© 2022 SolarV GmbH All rights reserved. Copyright© 2022 SolarV GmbH All rights reserved. Copyright© 2022 SolarV GmbH All rights reserved.
