Carrier Infinity 25VNA0 Service Manual page 37

Yellow
Output Terminals To Compressor (male spades )
Scroll Thermistors
˚
Ω Value Temp C
412314 (43.00)
336936 (40.00)
177072 (30.00)
97088 (20.00)
55325
(10.00)
32654 0
19903 10
12492 20
10000 25
6531
35
4368 45
2987 55
2084 65
1482 75
1072
85
788 95
589 105
446 115
342 125
265 135
235 140
185 150
Black Red Ground
Fig. 24 – High Voltage Input- -Output Connections on Drive
Table 8—Thermistor Resistance Values
˚
Temp F
(45.40) HW Trip
(40.00) SW Trip
(22.00)
(4.00)
14.00
32.00
50.00
68.00
77.00 Calibration Pt
95.00
113.00
131.00
149.00
167.00
185.00
203.00
221.00
239.00
257.00
275.00 SW Trip
284.00
302.00 HW Trip
Motor Thermistors
˚
Ω Value Temp C
206108 (43.00)
168433 (40.00)
88526 (30.00)
48538 (20.00)
27663
(10.00)
16327 0
9951 10
6246 20
5000 25
3266
35
2184 45
1494 55
1042 65
741 75
536
85
459 90
394 95
37
A11561
˚
Temp F
(45.40) HW Trip
(40.00) SW Trip
(22.00)
(4.00)
14.00
32.00
50.00
68.00
77.00 Calibration Pt
95.00
113.00
131.00
149.00
167.00
185.00
194.00 SW Trip
203.00 HW Trip
