Simex PMS-90R User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
data logger
●
Loggy Soft v. 1.5.5 or higher
●
S-Toolkit v. 1.7.0 or higher
●
device type:
Read the user's manual carefully before starting to use the unit or software.
Producer reserves the right to implement changes without prior notice.
29.04.2009
USER MANUAL for
with 0/4 ÷ 20 mA inputs
PMS-90R - 0/4..20
firmware version:
2.10 b972
or higher
V.2.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMS-90R and is the answer not in the manual?

Questions and answers

Related Manuals for Simex PMS-90R

Summary of Contents for Simex PMS-90R

  • Page 1 0/4 ÷ 20 mA inputs ● Loggy Soft v. 1.5.5 or higher ● S-Toolkit v. 1.7.0 or higher ● PMS-90R - 0/4..20 device type: 2.10 b972 firmware version: or higher Read the user's manual carefully before starting to use the unit or software.

  • Page 2: Table Of Contents

    User manual for Data Logger and cooperating software CONTENTS I. USER MANUAL FOR “PMS-90R” DATA LOGGER..........4 1. BASIC REQUIREMENTS AND USER SAFETY..................4 2. GENERAL CHARACTERISTICS........................5 3. TECHNICAL DATA............................6 4. DEVICE INSTALLATION..........................9 4.1. UNPACKING............................9 4.2. ASSEMBLY............................9 4.3. CONNECTION METHOD.........................12 4.4. MAINTENANCE..........................15 5.
  • Page 3 3.5.2.Configuring selected channels....................83 3.5.3.Configuring all channels......................83 3.6. UPDATING SOFTWARE OF PMS-90R DEVICE................84 Explanation of symbols used in the manual: - This symbol denotes especially important guidelines concerning the installation and operation of the device. Not complying with the guidelines denoted by this symbol may cause an accident, damage or equipment destruction.

  • Page 4: User Manual For "Pms-90R" Data Logger

    User manual for Data Logger and cooperating software I. USER MANUAL FOR “ PMS-90R ” DATA LOGGER 1. BASIC REQUIREMENTS AND USER SAFETY - The manufacturer is not responsible for any damages caused by inappropriate installation, not maintaining the proper technical condition and using the unit against its destination.

  • Page 5: General Characteristics

    Significant acceleration of data transfer is an additional advantage: data download can be 10 times faster than using RS-485 interface. WARNING! PMS-90R should work properly with any standard Flash Drives, but manufacturer can not guarantee proper cooperation with non-standard devices, or...

  • Page 6: Technical Data

    User manual for Data Logger and cooperating software • Wide range of power supply voltage and external sensor power supply The built-in pulse power supply allows power to be supplied to the unit with 85...230...260V AC/DC voltage or 16...24...35 AC, 19...24...50 DC voltage (depending on version).
  • Page 7 User manual for Data Logger and cooperating software Display LCD graphic display, 128 x 64 points, with backlight Data memory 2MB - version without USB Host 8MB - version with USB Host interface Protection level version without USB interface IP 65 (from front, after using waterproof cover) IP 40 (from front) IP 20 (housing and connection clips) version with USB interface IP 42 (from front, after using waterproof cover)
  • Page 8 User manual for Data Logger and cooperating software Range of operating voltage Air gap [mm] Surface gap [mm] Up to 50V RMS or DC Up to 100V RMS or DC Up to 150V RMS or DC Up to 300V RMS or DC Tab.

  • Page 9: Device Installation

    Attached with the unit please find: assembly brackets - 2 pieces, – warranty, – user’s manual for PMS-90R unit (device) – user’s manuals for cooperating software, – CD-ROM with the aforesaid manual in PDF format and installation files of cooperating –...
  • Page 10 User manual for Data Logger and cooperating software In order to assembly the unit, a 90,5 x 90,5 mm mounting hole (Fig. 4.1) must be prepared. The thickness of the material of which the panel is made must not exceed 5mm.
  • Page 11 User manual for Data Logger and cooperating software GOOD back side of device connector WRONG back side of device connector Fig. 4.3. Connectors removing method 115 mm Fig. 4.4. Minimum distances when assembly of a number of units...

  • Page 12: Connection Method

    User manual for Data Logger and cooperating software 4.3. CONNECTION METHOD Caution - Installation should be conducted by qualified personnel . During installation all available safety requirements should be considered. The fitter is responsible for executing the installation according to this manual, local safety and EMC regulations.
  • Page 13 User manual for Data Logger and cooperating software Use of screened signal cables is recommended. Signal cable screens should be connected to the earthing only at one of the ends of the screened cable. In the case of magnetically induced interference the use of twisted couples of signal cables (so-called “spirals”) is recommended.
  • Page 14 User manual for Data Logger and cooperating software Depending on version: 85...230...260V AC/DC or 19...24...50V DC; 16...24...35V AC FUSE Fig. 4.7. Connection of power supply additional terminals (internally connected) 15 16 17 18 19 20 21 22 23 24 25 26 external 28 29 30 31 32 34 35 36 37 38...

  • Page 15: Maintenance

    Fig. 4.10. Connection of digital input (depending on data recorder configuration) RS 485 12 13 RS232/485 interface Fig. 4.11. Connection of RS-485 transmission signals The PMS-90R device supports the following converters: USB / RS-485 converter (Converter USB/RS485) – RS-232 / RS-485 converter (Converter 232/RS485) – 4.4. MAINTENANCE The unit does not have any internal replaceable or adjustable components available to the user.

  • Page 16: Front Panel Description

    User manual for Data Logger and cooperating software 5. FRONT PANEL DESCRIPTION display programming pushbuttons Key designation and functions Symbols used in the manual: [ESC/MENU] and Functions: MENU • go to main menu (press and hold by at least 2 sec.), •...

  • Page 17: Principle Of Operation

    User manual for Data Logger and cooperating software 6. PRINCIPLE OF OPERATION After turning the power supply on, the logo and basic unit data are showed on the display, then the unit goes to the measurement mode. 6.1. MEASUREMENT MODE In the measurement mode the unit executes the measurement of values of signals connected to current inputs, hereafter called measurement channels (the number of available channels depends on the unit version).
  • Page 18 User manual for Data Logger and cooperating software Values corresponding to the results of current measurement conducted for each channel can be recorded (stored in the non-volatile memory of the unit) for further analysis. The recording of measurement results for all channels is performed with the same frequency, defined by the user in the range between 1 record per second to 1 record per hour ("Rec.

  • Page 19: Modes Of Result Presentation

    User manual for Data Logger and cooperating software Recording the measurement results in the non-volatile memory can be executed in two modes: "until full" or "cyclic" ("Write" parameter). The first mode enables the recording of such amounts of data as the unit's memory allows for, then the recording is stopped. In the second mode, once the memory is full, the results are recorded from the starting address in the memory, overwriting existing measurement results.

  • Page 20: Single Channel" Mode

    User manual for Data Logger and cooperating software - "Graph" mode (Fig. 6.5) enables the momentary values or averaged values of measurements conducted for one of measurement channels to be viewed in the form of a graph. Fig. 6.5. "graph" mode - "Channels list"...

  • Page 21: Measurements List" Mode

    User manual for Data Logger and cooperating software description of "Upper ext." and "Lower ext." parameters in "Inputs settings” menu). channel name current date unit name current time channel number measure result in numerical mode arrow indicates exceeding of nominal range percentage value of exceeding Fig.
  • Page 22 User manual for Data Logger and cooperating software channel exceeds allowable measurement range, instead of the result in numeric form the ”- Hi-” or "-Lo-" message is displayed (depending on the direction of exceeding, see description of "Upper ext." and "Lower ext." parameters in the "Inputs settings" menu). In order to go to the "Measurements list options"...
  • Page 23 User manual for Data Logger and cooperating software channel name unit name channel number recorded overload recording date and time measurement registered measurement registered before time point at (or after) time point defined by ”Date” and defined by „Date“ and ”Time”...

  • Page 24: Graph" Mode

    User manual for Data Logger and cooperating software During the download of data to be displayed from the unit's memory (recorded measurement results), an appropriate message is displayed instead of the measurement result (Fig. 6.13). "X" is displayed for data that has not been downloaded yet.
  • Page 25 User manual for Data Logger and cooperating software the form of an arrow indicating the direction of exceeding the range. If the measurement result for the given channel exceeds the allowable measurement range (Fig. 6.15, 6.16) instead of the current numeric value (displayed in the upper right corner) the display shows a "-Hi-" or "- Lo-"...
  • Page 26 User manual for Data Logger and cooperating software averaged. In the case of the upper limit, lower limit, or both limits of measurement range being exceeded in the given recording period, values represented in the form of arrows indicating the direction of exceeding (up, down, or both directions) will be recorded in the unit's memory instead of the averaged results.

  • Page 27: Channels List" Mode

    User manual for Data Logger and cooperating software • go to main menu (press and hold for approx. 2 seconds), MENU • go to "Graph options" menu, description on page 33. • change channel number, • change results presentation mode. 6.2.4.

  • Page 28: Device Programming

    User manual for Data Logger and cooperating software Functions of keys in "Channels list" mode: • go to main menu (press and hold for approx. 2 seconds), MENU • Go to "Channels list options" menu, description on page 34. • change channel number.

  • Page 29: Parameters Edition

    User manual for Data Logger and cooperating software edited password position is outlined and blinking Fig. 7.2. Password requested when accessing unit's main menu. presently configured current submenu name measurement channel number list position indicator presently selected item (edited parameter) current settings Fig.

  • Page 30: Text Parameters

    User manual for Data Logger and cooperating software Entering a new parameter value (Fig. 7.4) consists of changing the values of selected digits within the allowable range (using the [^], [v] keys). Some numeric parameters can take negative values (e.g. "Hi value" parameter). In such cases the "-" mark can be selected on the first decimal position of the parameter.
  • Page 31 User manual for Data Logger and cooperating software table displayed below edited text. The edited character is placed in brackets and flashes; its source is indicated in the characters table with brackets surrounding the edited character. edited position is edited text parameter (label) outlined and blinking Fig.

  • Page 32: Slider" - Type Parameters

    User manual for Data Logger and cooperating software 7.1.3. “SLIDER” - type parameters The parameters of this type are presented graphically in the form of a bar that turns black correspondingly to the ratio of the current value of the selected parameter to the maximum value of this parameter.

  • Page 33: Graph Options" Menu

    User manual for Data Logger and cooperating software Fig. 7.9. "Measurements list options" menu. "List type" parameter set as "current". ”historical” - the display will show 8 (or less) measurement results recorded before and 1 measurement result (located in the lower part of display, under the line) recorded at the time (or directly after it) defined by "Date"...

  • Page 34: Channels List Options" Menu

    User manual for Data Logger and cooperating software Fig. 7.11. “Graph options” menu 7.2.3. ”Channels list options” menu This menu contains options configuring the method of displaying measurement results for the "Channels list" mode: ”Display” - this option enables the selection of the method of displaying measurement results.

  • Page 35: Results Presentation Modes Menu Structure

    User manual for Data Logger and cooperating software 7.3. RESULTS PRESENTATION MODES MENU STRUCTURE Main menu Power on Initialization MENU Channel selection Mode: ”Single channel” ENTER MENU Parameter MENU Measurements list options Mode: ”Measurements list” List type edition ENTER MENU MENU Date Channel selection...

  • Page 36: Display Options" Menu

    User manual for Data Logger and cooperating software established on the basis of the currently set recording period and the number of recorded channels. In the case of controlling the recording process using the digital input, the value shown relates to the time, during which the voltage level on the digital input allows the recording of measurements.

  • Page 37: Logging Setup" Menu

    User manual for Data Logger and cooperating software Fig. 7.14. ”Display options” menu 7.4.3. ”Logging setup” menu This menu contains options defining the recording method and recorded channels: ”Write” - this option defines the behaviour of the unit after writing all available memory with the recorded measurement results.
  • Page 38 User manual for Data Logger and cooperating software Fig. 7.16. Warning in “cyclic” recording mode ”Triggering” - method of recording measurement results. The following options are available: ”always” - measurements are recorded in time intervals defined by the “Recording period” parameter, ”high level”...

  • Page 39: Input Settings" Menu

    User manual for Data Logger and cooperating software ”average v.” - averaged values will be recorded for the selected measurement channel (see section MEASUREMENT MODE, point 6.1.1). If the “Input type” in the “Inputs settings” menu shall be set as “disabled” for a given channel, then this channel will not be available on the list of recording channels in the “Logging setup”...
  • Page 40 User manual for Data Logger and cooperating software channel. Fig. 7.19. ”Inputs settings” (part 1) ”Input type” - type of input/sensor. The following options are available: ”inactive” - input is not active ”0-20 mA”,”4-20 mA” - current inputs, displayed value is defined by “Hi value”, “Lo value”...

  • Page 41: Date & Time Settings" Menu

    User manual for Data Logger and cooperating software ”Filter” - this option enables the level of the filtration of indications to be changed. Permissible values: from 0 (no filtration) to 5 (filtration with maximum time constant of approx. 2 seconds). - parameter defining the allowable range of input currents (Fig.

  • Page 42: Rs485 Port Settings" Menu

    User manual for Data Logger and cooperating software Fig. 7.22. ”Date & time settings” menu 7.4.6. ”RS485 port settings” menu This menu contains options to configure the RS485 interface: ”Address” - this parameter specifies the unit’s address, according to the Modbus protocol (in the range of 0 to 99).

  • Page 43: Access Setup" Menu

    User manual for Data Logger and cooperating software “38400” “57600” “115200” ”Baud rate” parameter ”Resp. delay” parameter “+10 ch.” “+20 ch.” “+50 ch.” Tab. 7.1. Settings of ”Resp. delay” parameter ”Conf. change” - this option allows the method of accessing unit’s configuration registers through the RS485 interface to be defined.

  • Page 44: Usb Options" Menu

    User manual for Data Logger and cooperating software Fig. 7.24. “Access setup” menu 7.4.8. ”USB options” menu This menu contains options which allows copying of device configurations between PC and data logger unit, and automatic data transfer using USB type FlashDrive (PenDrive): ”Write config.

  • Page 45: Language" Parameter

    User manual for Data Logger and cooperating software memory of the device. Due to the possibility of occurrence of: write error, FlashDrive or USB malfunction, and other incidental problems, autostorage function should be controlled by user from time to time. Lack of control can cause overwriting of data in internal memory or stopping of data recording due to impossibility of data storage on FlashDrive.

  • Page 46: Main Menu Structure

    User manual for Data Logger and cooperating software 7.5. MAIN MENU STRUCTURE Result presentation mode Press and hold at least 2 seconds MENU MENU 4-digit user password entering (if it is different from „0000”) 0 _ _ _ ENTER ENTER Parameters MENU Device information...

  • Page 47: Downloading Data From Data Logger

    For FlashDrive grater than 16GB, proper read / write operations are not guaranteed. To get data from the PMS-90R device plug a FlashDrive to USB Host port, located on the front panel of the device. The following message will appear after a few seconds: User can confirm ([ENTER] key) to start data downloading , or cancel the download ([ESC/MENU] key).

  • Page 48: The Modbus Protocol Handling

    User manual for Data Logger and cooperating software After successful data write the following message will appear: In order to transfer logged data to the PC, connect FlashDrive to PC and use Loggy Soft . Description of Loggy Soft can be found in further chapter of this manual. 9.
  • Page 49 User manual for Data Logger and cooperating software Register Write Range Register description Information about exceeding the allowable measurement range on the given measurement channel in binary form: HGFEDCBAhgfedcba. Higher(2 ) byte - exceeding upper limit of measurement range 0÷0FFFFh (H - channel no 8, A - channel no 1).
  • Page 50 User manual for Data Logger and cooperating software Register Write Range Register description Higher (2 ) word of serial number Lower (1 ) word of serial number 1, 4, 8 Number of units’ measurement channels Size of unit’s memory for recording in kB. Activation of logging for selected channel (binary): 0÷255 00000000hgfedcba (h –...

  • Page 51: Transmission Errors Handling

    User manual for Data Logger and cooperating software Register Write Range Register description “Name” parameter in “Inputs settings” submenu for channel 1; Character Higher byte – character No. 5; Lower byte – character No. 6 “Name” parameter in “Inputs settings” submenu for channel 1; Character Higher byte –...

  • Page 52: Examples Of Query/Answer Frames

    User manual for Data Logger and cooperating software 9.3. EXAMPLES OF QUERY/ANSWER FRAMES The examples concern a unit with address 1. All values are given in the hexadecimal system. Designations: ADDR Address of the device in the system FUNC Function number REG H,L Higher and lower part of registry number, to which the command refers to COUNT H,L...
  • Page 53 User manual for Data Logger and cooperating software ADDR FUNC REG H,L COUNT H,L CRC L,H The answer: ADDR FUNC BYTE C DATA H,L CRC L,H DATA H, L - displayed value = 255, no decimal point. Decimal point position can be read from reg.
  • Page 54 User manual for Data Logger and cooperating software DATA H3, L3 - 49h registry (6Eh - character "n", 65h - character "e"), DATA H4, L4 - 4Ah registry (6Ch - character "l", 20h - space " "), DATA H5, L5 - 4Ah registry (31h - character "1", 20h - space " "). a) The answer (we assume that input current is not out of range): ADDR FUNC...

  • Page 55: User's Settings List

    User manual for Data Logger and cooperating software 10. USER'S SETTINGS LIST Description Parameter Description Value page Parameters in the "Measurements list options” menu List type Type of measurement results list Date, Time Position of time line on historical list Parameters in the "Graph options”...
  • Page 56 User manual for Data Logger and cooperating software Description Parameter Description Value page Unit Unit for measured value Input type Type of input/sensor Value displayed for maximum value of input Hi value current Value displayed for minimum value of input Lo value current Dec.
  • Page 57 User manual for Data Logger and cooperating software Description Parameter Description Value page Unit Unit for measured value Input type Type of input/sensor Value displayed for maximum value of input Hi value current Value displayed for minimum value of input Lo value current Dec.
  • Page 58 User manual for Data Logger and cooperating software Description Parameter Description Value page Unit Unit for measured value Input type Type of input/sensor Value displayed for maximum value of input Hi value current Value displayed for minimum value of input Lo value current Dec.

  • Page 59: User Manual For "Loggy Soft

    Manual startup of the program is done using the Loggy.exe executable file. Initial startup of the application enables detection of all PMS-90R-type devices present in the network. The user is asked to perform an PMS-90R devices installation and measurement channel configuration procedure for all detected devices.
  • Page 60 After defining the communications port and baud rate, go to device detection screen (Fig. 2.2) by clicking on the [Next>>] button. Prior to scanning the network for devices, set the addresses identifying the selected PMS-90R devices in the network (a different address for each device – see page 42). In order to detect units connected to the network (after assigning addresses to the devices) press the [Scan network] button.
  • Page 61 The list shown on the figure (Fig. 2.2) contains one detected device. Order of devices on the list corresponds to the order of addresses assigned by the user to individual PMS-90R devices. Once all devices are detected press [Break scanning] button.

  • Page 62: Using The Program

    User manual for Data Logger and cooperating software 3. USING THE PROGRAM Upon application startup the Current measure menu is displayed (Fig. 3.1). Fig. 3.1Program window upon startup The selection from the currently active menu is made using the flat buttons in the upper part of the program window (Fig.

  • Page 63: Current Measure" Menu

    3.1. „ CURRENT MEASURE ” MENU Current measures menu allows to view current measurements results in table format. This table contains measures of channels of all installed PMS-90R units. Only the measurements from devices installed using the RS485 interface will be available. To enable continuous reading of data from the devices check Enable current measurement mode.
  • Page 64 - this box enables creating tables in two modes: - for a group - collective table for a maximum of 12 measurement channels (observed channels can belong to different PMS-90R devices), - for a single channel. Creating groups is described in the Group operations section (page 73).
  • Page 65 User manual for Data Logger and cooperating software Selecting table type (for a group or single channel) In order to select table type: • click appropriate tab Groups or Channels (Fig. 3.3), • check specific group or measurement channel. This will display measurement results for the selected group or single channel (displaying results takes place automatically after each change of group or measurement channel).

  • Page 66: Graph" Tab

    Fig. 3.6. Reports - Graph tab Graph tab (Fig. 3.6) is used for viewing and printing of measurement results recorded by an PMS-90R device (e.g. temperature, humidity) in the form of a graph. Measurements from a maximum of five recorded measurement channels can be viewed.
  • Page 67 - this box enables creating graphs in two modes: - for a group - collective graph for a maximum of 12 measurement channels (observed channels can belong to different PMS-90R devices); - for a single channel. Creating groups is described in the Group operations section (3.3.2, page 73).
  • Page 68 User manual for Data Logger and cooperating software Fig. 3.7. Enlarging graph • moving the graph - the graph can be moved to the left/right (earlier/later time period, correspondingly). In order to do this, right-click on the graph and drag the pointer in desired direction (Fig. 3.8). Fig.
  • Page 69 User manual for Data Logger and cooperating software • measurement points tracking - if Show cursor field is checked then special graphical cursor is displayed on the graph. This cursor allows to easy tracking of measured data. Colour of the cursor is same as selected channel colour.
  • Page 70 Fig. 3.10. Interruption in the graph (e.g. sensor fault) If measurements can not be executed for some time (e.g. power supply fault or the PMS-90R device is switched off) then the program will show this situation on the graph in the form of two vertical lines (Fig.

  • Page 71: Configuration" Menu

    3.3. „ CONFIGURATION ” MENU The Configuration menu is used to: • change the settings of channels of PMS-90R devices working in the system and getting data from these devices (Devices tab); • operations of groups (Groups tab).
  • Page 72 - shows the tree contains a list of all currently installed PMS-90R devices together with their addresses. The first level of the tree shows individual PMS-90R devices. After clicking the “+” sign next to the PMS-90R device name with mouse...

  • Page 73: Groups" Tab - Group Operations

    A group enables creating a collective current graph/report for a number of measurement channels belonging to the same or to different PMS-90R devices, which the user wishes to view on one graph/report. A group consists of a maximum of 12 measurement channels.
  • Page 74 User manual for Data Logger and cooperating software Removing a group In order to remove a group: • check the desired group on the Groups list, • click on the [Remove group] button. Changing group name In order to change a group’s name: •...

  • Page 75: Settings" Tab

    User manual for Data Logger and cooperating software 3.3.3. „ Settings ” ta b Fig. 3.15. Configuration - Settings tab Settings tab (Fig. 3.15) allows to change settings related to serial port and method of data downloading from the USB FlashDisk. The settings list contains following fields: •...

  • Page 76: List Of Errors And Fault Diagnostics

    User manual for Data Logger and cooperating software 3.4. LIST OF ERRORS AND FAULT DIAGNOSTICS Symptom Cause Action All points are a red colour and converter fault or one of • check converter power supply a question mark (?) is converter's connections •...

  • Page 77: User Manual For "S-Toolkit

    1. GENERAL CHARACTERISTICS The S-Toolkit software enables configuration reading and writing operations, updating the device firmware and obtaining basic information on PMS-90R-type devices through RS485 serial interface. This application enables to quickly and easily define device parameters in one of three possible configuration models. The set of parameters can be transmitted directly to the device or stored in a file for future use.

  • Page 78: Using Program

    User manual for Data Logger and cooperating software 3. USING PROGRAM Read current settings from device, from file or import settings from flash disk Write configuration set to device, to file or export settings to flash disk Fig. 3.1. Program main window There are four tabs in the central part of program window: •...

  • Page 79: Inputs Settings" Tab

    User manual for Data Logger and cooperating software [Export] - saves the settings shown in the Inputs settings tab and writes • the configuration set to the FlashDrive; • [Close] - exits the program. Status information concerning currently performed operation is shown in the bottom of the window.

  • Page 80: Logging Setup" Tab

    In the central part of the tab (in a separated panel) there are fields for configuring device parameters. The parameters can be configured in three modes. Detailed description of individual parameters can be found in the user manual for device PMS-90R. •...

  • Page 81: Interface Options" Tab

    In order for communication between the program and the device to be possible, the address and baud rate set in the program must be same as the ones set in the PMS-90R device. • Display options - this section allows changing parameters of LCD display of configured device.

  • Page 82: Device Information" Tab

    User manual for Data Logger and cooperating software If the PMS-90R device clock shows later time than computer's system clock, then the synchronization (in this case reversing the PMS-90R clock) will cause all data recorded by device after the time set during synchronization to be deleted.

  • Page 83: Configuration Modes

    PMS-90R device. Therefore perform one of the aforesaid operations prior to configuring the next group of selected channels. Due to the time of writing the configuration to PMS-90R device it is recommended to write the set configuration to file. 3.5.3. Configuring all channels After switching to all-channels configuration mode, the values for most recently configured channel remain in the configuration fields.

  • Page 84: Updating Software Of Pms-90R Device

    In exceptional cases (update interrupted or unit does not operate after update) contact the manufacturer. The newest version of PMS-90R device firmware is available at producer homepage. The USB driver update section in the Device information tab enables USB interface driver update.
  • Page 85 User manual for Data Logger and cooperating software...
  • Page 86 User manual for Data Logger and cooperating software...
  • Page 87 User manual for Data Logger and cooperating software...
