BioLife Stirling Ultracold SU780XLE Operating Manual

-86ºc ultra-low temperature freezer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
UL T25NEU
Operating
Manual
-86ºC
Ultra-Low
Temperature
Freezer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stirling Ultracold SU780XLE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BioLife Stirling Ultracold SU780XLE

Summary of Contents for BioLife Stirling Ultracold SU780XLE

  • Page 1 UL T25NEU Operating Manual -86ºC Ultra-Low Temperature Freezer...

  • Page 2: Initial Setup

    ULT25NEU Quick Guide INITIAL SETUP The Port Stopper/Sealant must be in place during operation Port Stopper/ Sealant The unit is ON when lit Power Indicator Press and hold for two beeps Power ON Press and hold for three beeps Power OFF Displays chamber temperature LCD Display Press/Release to display current setpoint, S ## displayed...
  • Page 3 ULT25NEU QUICK GUIDE (Continued) NOTICE: When unit is first turned on, red Over Temp LED will be on until temperature is within10° of setpoint. Panel cannot be locked until temperature is within 10° of setpoint.Panel cannot be locked until temperature is within 10º of set point. TABLE OF CONTENTS ULT25NEU-LIT-OM-F BioLifeSolutions.com...
  • Page 4 THIS PAGE INTENTIONALLY LEFT BLANK TABLE OF CONTENTS ULT25NEU 02.10.2023 4 OF 34 OPERATING MANUAL...
  • Page 5 UL T25NEU -86˚C PORTABLE ULTRA-LOW TEMPERATURE FREEZER The ULT25NEU (Ultra-Low Temperature, 25 liter volume) incorporates next generation free-piston Stirling engine technology. Free-piston Stirling engine technology differs from conventional compressor-based refrigeration in that it provides high efficiency, deep-temperature cooling in a lightweight package allowing true portable operation.

  • Page 6: Safety Precautions

    SAFETY PRECAUTIONS To prevent personal injury, injury to others, or damage to property, read these safety precautions carefully before use. INJURY PREVENTION Do not cut, change or modify the power cable.* When removing the plug, hold onto the plug and not the cord. An ultra-low temperature freezer is qualitatively different than a home freezer.

  • Page 7: Damage Prevention

    SAFETY PRECAUTIONS (Continued) DAMAGE PREVENTION Do not disassemble, modify or repair. There are no user serviceable parts inside the freezer unit.* Do not immerse in water or pour water on the unit.* Do not put ice or liquid water directly in the freezer box, always use suitable containers.

  • Page 8: Transportation Care

    SAFETY PRECAUTIONS (Continued) TRANSPORTATION CARE Use only factory-provided packaging. If unavailable, contact the manufacturer for replacement packaging materials. Do not place unit on sides or turn upside down. FLAMMABLE REFRIGERANT USE ULT25NEU uses 10-12 grams of R-170 (Ethane) in a hermetically sealed thermosiphon tubing.

  • Page 9: Unpacking And Setup

    UNPACKING AND SET-UP Remove the freezer and all accessories from the box. Carefully inspect the freezer and all accessories for any shipping damage. Check the packing list to verify that the shipment is complete. Ensure the access port stopper or sealant is in place. Place the freezer on a level surface.
  • Page 10 UNPACKING AND SET-UP (Continued) Notes on operation in a vehicle. A The freezer will operate on vehicle battery power for a limited time before the battery is drained and the motor vehicle cannot be started. This time will vary from vehicle to vehicle but is generally only a few hours. B The vehicle engine should be running to prevent accidental total discharge of the battery.

  • Page 11: Pictorial Tour, Freezer

    FEATURES OF THE ULT25NEU FREEZER PICTORIAL TOUR, FREEZER The Stirling Ultracold ULT25NEU free-piston Stirling engine ultra-low temperature freezer has the following features: A freezer chamber which is protected by two lids > Inner lid has a tight fitting foam lid. Control Panel Described in more detail on page 13.
  • Page 12 FEATURES OF THE ULT25NEU FREEZER (Continued) Outer Lid: Inner Lid: Access Port: Slide-out Filter: double gasket high-density, 1/4” (6.3 mm). easy to clean, protects moisture seal. closed cell, heat rejection fins. rigid foam. AC Power Connection. Power Cord Available DC Power Connection. Power Cord Separately.

  • Page 13: Pictorial Tour, Control Panel

    FEATURES OF THE ULT25NEU FREEZER (Continued) PICTORIAL TOUR, CONTROL PANEL On/Off Indicator LED On/Off button > Turns freezer on and off. LCD display > Alpha/numerical display; default display is chamber temperature. ^ / v buttons Used to adjust Setpoint Temperature (when the display shows S ##). >...

  • Page 14: Power Cords

    FEATURES OF THE ULT25NEU FREEZER (Continued) POWER CORDS A simple line cord change can allow for multiple power and receptacle types. See Section 4.7 for directions. Make sure to use the cord and plug appropriate for your location. Power supply options include: North America.

  • Page 15: Operation

    OPERATION Important changes to the freezer settings require sustained button pushes. This helps prevent accidental changes to the settings during transportation. Some sequences require a three-second button press and hold while other sequences require a five-second button press and hold. For example, Turning the freezer ON requires a three-second press and hold (two beeps).
  • Page 16 OPERATION (continued) 4.2.2 Change the Setpoint to a New Value There are two ways to change the Setpoint. Manually adjust the temperature using ^ / v . > Use one of the three adjustable Preset Buttons. > Adjusting the Setpoint manually. >...

  • Page 17: Using Preset Temperatures

    OPERATION (continued) To change the Setpoint by Method B Press and hold the Set Temp button until the Set Temp LED glows. > – The Setpoint temperature will appear with the letter S in the first LCD display. The ^ / v buttons can be used to change the Setpoint. >...

  • Page 18: Over-Temperature Alarm

    OPERATION (continued) OVER-TEMPERATURE ALARM If the freezer compartment temperature is 10ºC warmer or colder than the Setpoint for five seconds then it will go into temperature alarm mode. The Over Temp LED will turn on (this is used for under temperature >...

  • Page 19: Locking The Control Panel

    OPERATION (continued) LOCKING THE CONTROL PANEL To Lock the Freezer Control Panel Press and hold the Temperature Preset 1, 2 and 3 buttons until the freezer beeps three times. The Locked LED will light up. > > The control panel cannot be locked if there is an over temperature or other error condition.

  • Page 20: Error Codes

    ERROR CODES These are displayed in the LCD display as E ##. The free-piston Stirling engine is not maintaining a working temperature. This could arise from blocked filters, blocked air passages, unusually hot ambient temperatures (for example >45ºC), or a fan failure. Check air passages and clear any blockages for good air circulation.

  • Page 21: Maintenance

    MAINTENANCE CARING FOR YOUR FREEZER GASKET The temperature differential between ambient and the ultra-low interior can attract moisture near the gasket. For best results always wipe away moisture during openings to prevent ice accumulation. Do not use sharp instruments to scrape ice from the surface. AIR INTAKE FILTER Clean accumulated dust and dirt on the air intake filter every month.

  • Page 22: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Solution Power is not Check the connections to the Freezer does getting to the power supply not power on freezer from Assure that the wall plug is firmly seated the AC input Reseat the connections to the DC power cord Power is not Assure that the DC input has live power...

  • Page 23: Calibration Guide

    CALIBRATION GUIDE CALIBRATING THE RTD WITH AN INDEPENDENT TEMPERATURE INDICATOR The ULT25NEU’s Resistance Temperature Device (RTD) is factory calibrated to display both setpoint and operating temperature from a single internal RTD. In the event that you must recalibrate the unit to match the reading of an independent temperature recording device or stand-alone electronic thermometer, please follow this process.
  • Page 24 CALIBRATION GUIDE (Continued) Procedure Place a thermocouple inside the cabinet via access port insert plug/port sealant. Note: Display temperature is calibrated using a NIST traceable thermocouple located in the center of the cabinet (4.4” from back, 6.6” from left side, 6.7” from bottom). Turn unit on.
  • Page 25 CALIBRATION GUIDE (Continued) Thermocouple through Access Port & Access NIST Traceable Temperature Measuring Device. Port Plug. Filter Door. Adjustment Tool. Calibration Screw visible through filter. TABLE OF CONTENTS ULT25NEU-LIT-OM-F BioLifeSolutions.com 25 OF 34...

  • Page 26: Freezer Specifications

    SPECIFICATIONS FREEZER SPECIFICATIONS 100V – 240 (± 10%) at either 50 or Electric Power 60 Hz or 12V DC from mobile source 280 watts (4 amps @120VAC, 2 amps Maximum Power (Current) @240VAC, 15 amps@12VDC) 15 amp or greater grounded circuit Electric Supply Rating Helium charged free-piston Stirling engine Cooling Engine...
  • Page 27 SPECIFICATIONS (Continued) 692.5 x 350 x 460 mm | 27.3" x 13.8" x 18.1" (L x W x D) Exterior Dimensions 21 kg (46 lbs.), nominal Net Weight, Empty High performance vacuum insulated panels and Insulation polyurethane foam using environmentally friendly blowing agent Advanced noise abatement, <45 dB(A) at 1 meter Noise...

  • Page 28: Freezer Dimensions

    SPECIFICATIONS (Continued) FREEZER DIMENSIONS 27.3" (692.5 mm) 13.8" (350 mm) 27.1" [688.1mm] 13.6" [346.5mm] 13.1" (332 mm) 8.7" (221 mm) 13.0" [320.2mm] 8.7" [222.2mm] FRONT SIDE .3" (8 mm) 0.3" [8.9mm] 13.5" (343 mm) 8.7" (220 mm) 15.7" [399.7mm] 9.0" [228.6mm] TABLE OF CONTENTS ULT25NEU 02.10.2023...
  • Page 29 SPECIFICATIONS (Continued) PULL-DOWN AND WARM-UP CHARACTERISTICS, 25OC AMBIENT AIR TEMP, EMPTY Middle Height, Pull-down to -86º C from Ambient POWER OFF, AIR TEMP 8 Liters of -86°C Ice, Middle Height AIR TEMP, EMPTY Middle Height, Steady State, Non-Cycling POWER OFF, ICE TEMP 8 Liters of -86°C Ice, Middle Height POWER OFF...

  • Page 30: Limited Warranty, Usa

    WARRANTY The following Warranty applies to the ULT25NEU manufactured by Stirling Ultracold, a division of Global Cooling, Inc. Due to the nature and size of the ULT25NEU, a product exchange may be preferable to field-level service. In order to maintain maximum uptime and to optimize customer service, Global Cooling, Inc.

  • Page 31: Limited Warranty, Canada

    WARRANTY (Continued) LIMITED WARRANTY, CANADA The warranty period starts ONE MONTH after the original date of shipment from Global Cooling, Inc. The Stirling Ultracold ULT25NEU is warranted for a period of ONE YEAR for materials and labor at our factory. If a service issue arises, contact the Global Cooling, Inc.
  • Page 32 THIS PAGE INTENTIONALLY LEFT BLANK TABLE OF CONTENTS ULT25NEU 02.10.2023 32 OF 34 OPERATING MANUAL...
  • Page 33 THIS PAGE INTENTIONALLY LEFT BLANK TABLE OF CONTENTS ULT25NEU-LIT-OM-F BioLifeSolutions.com 33 OF 34...
  • Page 34 T 740.274.7900 / 1.855.274.7900 F 740.274.7901 BioLifeSolutions.com ©2023 Stirling Ultracold, a part of BioLife Solutions. All Rights Reserved. Global Cooling technology is manufactured under U.S. and International patents. Stirling Ultracold is a trademark of Global Cooling, Inc. Specifications subject to change without notice.
