- Page 1 ROYALE FLUSH Toilet Auxiliary Lift USER MANUAL...
- Page 2 AUTHORISED TOP GUN MOBILITY AFTER SALES SERVICE We have ensured that your new Top Gun Mobility Toilet Lift Seat is ready to deliver! Every member of our Team is dedicated to Customer Satisfaction. By making contact with the following personnel, you will be assured of Prompt and Efficient After Sales Service.
-
Page 3: Table Of Contents
CONTENTS PACKAGING AND COMPONENTS ..........................1 INSTALLATION .................................. 2 Handrail Installation ..............................2 Remote Control Box installation ..........................2 Adjustment of Supporting feet ..........................3 Positioning Seat Lift with the Toilet ........................3 How to use the lifting button ........................... 6 Water Pipe installation ............................... -
Page 4: Packaging And Components
PACKAGING AND COMPONENTS Open the package, check whether all parts are complete, and determine whether there is any damage. If any parts are missing or damaged, please contact the supplier. The package contains: A. Toilet auxiliary lift chair body B. Handrail (with lift switch) C. -
Page 5: Installation
INSTALLATION Handrail Installation Connect the armrest to the column of the main unit, and then use the screws provided in the installation tool bag to put it into the rear armrest screw hole and lock it. (When installing armrest B, pay attention to align the waterproof plug with the socket in the column for installation) Connect the handrail to the column of the main body Use the screws provided in the installation tool bag to put it into the rear armrest screw holes and... -
Page 6: Adjustment Of Supporting Feet
Adjustment of Supporting feet When the device leaves the factory, all 4 supporting feet have been adjusted to the lowest height. The installer uses the soft ruler in the installation tool bag to measure the height from the ground on the edge of the ceramic base of the toilet, and then adjusts the height of the rear beam of the device to be about 1cm higher than the edge of the ceramic base of the toilet by rotating the equipment support feet to avoid The device is in contact with the toilet. - Page 7 Fixing method 1: (bolt directly fixed) Page | 4...
- Page 8 Fixing method 2: (For the special situation of the toilet hole position, first use the extension piece to adjust the distance and then fix it) Page | 5...
-
Page 9: How To Use The Lifting Button
How to use the lifting button The lifting control switch of the device is located at the front end of the armrest. The user controls the lifting and lowering of the device by continuously pressing the left and right control keys. Release the switch to stop the device. -
Page 10: How To Use Manual Button/Side Control Panel
One end is connected to the water pipe, and the other end is connected to the main body HOW TO USE MANUAL BUTTON/SIDE CONTROL PANEL The design of this product is mainly controlled by remote control, and the side control panel. Page | 7... -
Page 11: Preparation
PREPARATION 1. Open the water inlet valve 2. Ensure the power plug is inserted into the socket and the indicator light is on 3. Confirm the power icon in LED display is on 4. If the power light on the product indictor panel is not lit, all functions will be unavailable, please press the power button on the operation button panel REMOTE CONTROL INSTRUCTIONS OF USE Stop/Power switch... -
Page 12: Seat Temperature Adjustment
Seat temperature adjustment Press the "seat temperature" button to set the seat ring temperature to switch between Low, Mid, High Grade and off. Indicator lights #4, 5 & 6 correspond to the status. Night lighting Press this button to turn on (or turn off) the night light below the seat ring. The night light turns off automatically after 10 minutes. -
Page 13: Cleaning And Maintenance
CLEANING AND MAINTENANCE Equipment cleaning Pull out the power plug first, and then clean the equipment with a mild, non-abrasive sanitary ware cleaner. If multiple people use the equipment, it is recommended to disinfect the equipment after each use; The equipment waterproof is IPX4, Do not rinse or immerse the equipment in liquid. Cleaning the nozzle Press the "△"... -
Page 14: Specifications
Commercial Use Any TopGun Mobility products used in a commercial application will only be covered by a 6 month warranty from the purchase date. All other conditions in this warranty will apply. The Product images shown are for illustration purposes only and may not be an exact representation of the product... -
Page 15: Additional Important Notes
ADDITIONAL IMPORTANT NOTES This product is only suitable for AC 220V / 50Hz power supply. The socket used should be firmly installed inside, at least 20cm away from the ground, and have grounding measures that meet the requirements. It cannot be installed in a place that is easily wetted by water/other conductive liquids to avoid electric shock accidents caused by water ingress. - Page 16 Page | 13...
- Page 18 Copyright Top Gun Mobility Owner’s Manual & Warranty Booklet 2022...
