- Page 1 All manuals and user guides at all-guides.com Mounting bracket User manual...
- Page 2 Intro All manuals and user guides at all-guides.com is bracket can be mounted on top or bo om of monitor. For monitors mounted more than 1100 mm above ground, mount bracket below monitor.
- Page 3 Measurements All manuals and user guides at all-guides.com Maximum thickness of screen 62 mm, minimum 10 mm. Minimum depth from front of screen to wall is 78 mm. 62 mm 10 mm...
- Page 4 1. Set depth All manuals and user guides at all-guides.com Choose the configuration that fits your screen...
- Page 5 2. Mount camera All manuals and user guides at all-guides.com Mount camera to the bracket. Gently tighten and align...
- Page 6 3. Fix bracket to monitor All manuals and user guides at all-guides.com Tighten clamp to grip the screen securely...
- Page 7 4. Connect All manuals and user guides at all-guides.com Connect the USB Cable...
- Page 8 5. Adjust All manuals and user guides at all-guides.com Adjust camera or bracket angle if needed...
- Page 9 6a. Lock All manuals and user guides at all-guides.com Secure camera with Kensington lock (optional). e lock prevents the camera to be detached from bracket...
- Page 10 6b. Lock All manuals and user guides at all-guides.com For smaller Kensington locks, use the included washer to secure the camera...
