Summary of Contents for Huddly 1912856
- Page 1 Mounting bracket User manual...
- Page 2 Intro is bracket can be mounted on top or bo om of monitor. For monitors mounted more than 1100 mm above ground, mount bracket below monitor.
- Page 3 Measurements Maximum thickness of screen 62 mm, minimum 10 mm. Minimum depth from front of screen to wall is 78 mm. 62 mm 10 mm...
- Page 4 1. Set depth Choose the configuration that fits your screen...
- Page 5 2. Mount camera Mount camera to the bracket. Gently tighten and align...
- Page 6 3. Fix bracket to monitor Tighten clamp to grip the screen securely...
- Page 7 4. Connect Connect the USB Cable...
- Page 8 5. Adjust Adjust camera or bracket angle if needed...
- Page 9 6a. Lock Secure camera with Kensington lock (optional). e lock prevents the camera to be detached from bracket...
- Page 10 6b. Lock For smaller Kensington locks, use the included washer to secure the camera...
