6.2.2.1 Rotor Belts
1.
Remove pivot wheel arm (1052) and rotor belt guard (1168).
2.
Loosen the belt tension by releasing tension from the idler pulley
(5314).
3.
Remove rotor belts (5325) by easing them off the pulleys (5316 &
1033).
4.
Fit new belts.
5.
Re-tension belts by tightening up the idler pulley, ensure you lock
the idler arm in place again by tightening the locking nut.
6.
Re-fit rotor belt guard & pivot wheel arm.
6.2.2.2 Rotor Relay Belts
1.
Push clutch lever (1485) all the way forward.
2.
Remove the main cover (2775).
3.
Remove rotor belts (5325) as described above, but only from the
transfer pulley (1033) end.
4.
Loosen the de-clutch bracket (1198) on the tension arm (2766)
and pivot the de-clutch bracket away from the belts.
5.
Ease rotor relay belts (5342) from top pulley (5741).
6.
Remove belts and replace with new belts.
7.
Tighten the de-clutch bracket back onto the tension arm in the
same position as before.
8.
Re-fit main cover.
9.
Re-fit rotor belts and rotor belt cover as per 6.2.2.1.
6.2.2.3 Gearbox Drive Belt
1.
Remove the main cover (2775).
2.
As per 6.2.2.2, remove the rotor relay belts, but from the top
pulley (5741) only.
3.
Remove tension from the belt by loosening the idler pulley and
moving it back in its mounting slot.
4.
With the tension now off the gearbox drive belt (5709), remove
the belt from the gearbox and engine pulleys and feed it off the
machine.
5.
Fit new transmission drive belt and re-tension the belt as per 6.1.4.
6.
Re-fit the rotor relay belts to the top pulley as per 6.2.2.2 and re-fit
main cover.
6.2.2.4 Transmission Drive Belt
1.
Remove tension from the transmission drive belt (5709) by sliding
the idler pulley forward in its mounting slot, then remove the belt
from the machine.
2.
Re-fit new belt and re-tension as per 6.1.5.
