- Page 1 ARCUS MRM01 INTERIOR & EXTERIOR LIGHT Operating Instructions...
-
Page 2: Table Of Contents
CONTENTS Preface............................... 3 Features ............................. 3 Precautions ............................3 Controls and Connectors........................4 Installation ............................6 Appearance............................9 Technical Specifications........................9 Warranty............................10 Declaration of Conformity......................... 11 _________________________________________________________________________________... -
Page 3: Preface
Do The ARCUS MSR01 series is designed to light not use abrasive or highly alkaline cleaners. to the floor under the angle of 45 degrees or Never scrape with razor blades or other straight. - Page 4 COMPONENTS AND CONNECTORS (1) Optical window High-Grade Polycarbonate Glass Optical Window. (2) Interior & exterior light casing Stainless steel casing with fixing holes for surface-mount models or basic mounting plate for rail- mount model. (3) Face shape Different stainless steel face shapes. (4) Wires Red, black and green wires to connect the 12-24Vdc power supply and control.
-
Page 5: Installation
• 2 x fixing screw 2.9x13 or M4x8 for rail-mount model • Operating Instructions with Declaration of Conformity and Warranty conditions The ARCUS MSR01 has to be installed on a flat surface of the vessel’s staircase, ceiling or floor or on the vessel’s rail with diameter of 30mm. - Page 6 • It is highly recommended to seal the front shape thread to avoid unscrewing. Connection The interior & exterior light has to be connected as described in the table below: GREEN BLACK ARCUS MSR01 FUNCTION wire color + DC Power Supply Black...
- Page 7 The interior & exterior light can be controlled by using the key-switch. T he color or mode of lighting an be changed sequentially by pressing the key switch for 1 second: ARCUS MSR01 Sequence of lighting Custom Color Cool White...
-
Page 8: Appearance
APPEARANCE TECHNICAL SPECIFICATIONS Power supply 12 – 24 Vdc, max. 32 mA/12 Vdc or 18 mA/24 Vdc Lens angle 60º (angular lighting) or 90º (straight lighting) Optical window High-grade polycarbonate glass Luminous flux 9 lm Lighting color RGB spectrum Operating temperature -10°C - +50°C Casing Stainless steel (SAE316L) -
Page 9: Warranty
WARRANTY 1. The equipment manufactured by ASTEL d.o.o. is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 10: Declaration Of Conformity
Dutovlje 138 Manufacturer's Address: 6221 Dutovlje Slovenija declares that the products 1. Interior & Exterior light ARCUS MSR01 Item, Product Name and Model Number: conform to the following Product Specifications: EN 55022 (CISPR 22: 1993) EMC: EN 50130-4: 1994... - Page 12 ASTEL d.o.o., Dutovlje 138, 6221 Dutovlje, Slovenia Tel: +386 5 7310771, +386 5 7310772 Fax:+386 5 7310789 info@astel-marine.com E-mail: www.astel-marine.com Web:...
