38" TRAILING PAVEMENT/LEAF/LAWN SWEEPER
MODEL MH-481
Owner's Manual and Parts List
SAVE THIS MANUAL
You will need this manual for the safety instructions, assembly instructions and parts list. Put it in a
safe, dry place for future reference.
Additional Information/Link to PDF Copy of this Manual:
©2019 Mid West Products, Inc.
-1-
Form No. M1-1726
Advertisement
Table of Contents
Related Manuals for MID WEST PRODUCTS MH-481
Summary of Contents for MID WEST PRODUCTS MH-481
- Page 1 You will need this manual for the safety instructions, assembly instructions and parts list. Put it in a safe, dry place for future reference. Additional Information/Link to PDF Copy of this Manual: ©2019 Mid West Products, Inc. Form No. M1-1726...
- Page 2 Your Lawn Sweeper comes mostly assembled on the pallet. The Hitch Assembly and Height Adjustment Handle may need attached: PARTS LIST OF MH-481 MANUAL HITCH ASSEMBLY HEIGHT ADJUSTMENT HANDLE WIND APRON ©2019 Mid West Products, Inc.
- Page 3 Step 3: Take Wind Apron (65) and fasten Velcro to both Side Hamper Tubes (42). Fasten the other Velcro strap to the rear of the Hamper Pivot Brackets (44). (See Image: Above – Right) ©2019 Mid West Products, Inc. Form No. M1-1726...
-
Page 4: Operation
LUBRICATION: 1. Remove Wheel by removing Snap Ring. Apply RETINAX LC grease (Available from Mid West Products – 937-337-3641) to Wheel Gear and Pinion Gear. NOTE: Apply grease to the center of Pinion Gear. Lubricate at beginning of each season and every 20 hours of use, or more often as conditions dictate. -
Page 5: Parts Drawing
PARTS DRAWING ©2019 Mid West Products, Inc. Form No. M1-1726... -
Page 6: Parts List
2 5/16-18 Pilot Nut X-1353 2 1/2-13 Lock Nut L-59 2 5/16-18 X 3/4 HHCS 30 1-C2328 2 Pivot Support Tube 65 1A-B2492 1 Wind Apron 1-1850 1 Adjustment Decal NI=Furnished, Not Illustrated ©2019 Mid West Products, Inc. Form No. M1-1726... -
Page 7: Instructions For Ordering Parts
GUARANTEE The merchandise you have purchased from us has been carefully engineered and manufactured under Mid West Products rigid quality standards and should give you satisfactory, dependable operation. However, like all mechanical merchandise, it may occasionally require adjustment or maintenance. - Page 8 • Dump Style, with Removable Tailgate for Easy Unloading. • Load Capacity: 10 Cu. Ft./500 pounds • Bed Dim: 40” L x 30” W x 12” H. • Overall Dim: 63” L x 34” W x 30” H. ©2019 Mid West Products, Inc. Form No. M1-1726...
