- Page 1 INSTALLATION GUIDE Air Switch KWDA-100, KWDA-101 www.kraususa.com Toll Free: 1.800.775.0703 © 2022 Kraus USA Plumbing LLC REV. November 17, 2022...
- Page 2 For technical assistance or replacement parts, please contact Kraus Customer Service and one of our representatives will be happy to help:...
-
Page 3: Prior To Installation
Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Pre-drilled hole size requirement: 1 3/8" (min) - 1 1/2" (max) ·... -
Page 4: Specifications
6. Air Tube Nut x2 7. Air Tube 8. Mounting Screws & Anchors Specifications · KWDA-100** (single-channel control): Input: 125V ac, 60Hz, 3A max Output: 125V ac, 60Hz, 3A max · KWDA-101** (Duplex outlets): Input: 125V ac, 60Hz, 6A max Output: 125V ac, 60Hz, Each socket 3A max ·... - Page 5 Dimensions 1 7/8" 2 7/8" (47mm) (72mm) KWDA-100 1 7/8" 2 7/8" (47mm) (72mm) KWDA-101...
-
Page 6: Installation And Use
Installation and Use Working principle : The first pushing on air button actuates the air switch and the air switch keeps actuating when air button is released . A second push on the air button will release the air switch. 1. - Page 7 Step 2. Mount Power Module Mount the power module to the cabinet wall atleast three feet within Anchor an electrical outlet and the disposer. (if needed) Use three screws (8) to fasten the power module to the cabinet. Use Screw the anchors if needed.
- Page 8 Step 3. Attach Air Tube Attach air tubing between the push button and power module. Make sure the two sides of the air tube have been connected. Tighten the air tube nut on the push button and power module until snug. Air Tube...
- Page 9 Step 4. Plug in Power Module Plug the power module into a dedicated, grounded 120V AC outlet which is continuously energized.
- Page 10 Step 5. Connect Power Module and Disposer Plug the disposer cord in the power module. Press the push button to ensure that the Countertop Switch can turn the disposer on and off. Be sure that the control system is Disposer operating properly before using Cord Power...
-
Page 11: Replacement Parts
Replacement Parts Replacement Parts List Finish/Color Part # 1. Cover Assembly SS, MB, CH* KP59000-CH SS, MB, CH* 2. Button Assembly KP59001-MB 3. Transmission Parts KP59002 4. Air Tube KP59003 KP59004 5. Rubber Washer KP59005 6. Metal Washer KP59006 7. Mounting Nut KP59007 8. - Page 12 (1) year from the date of purchase. Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired or replaced with a product of equal value at the option of Kraus.
- Page 13 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
- Page 14 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
