Innovative Technology ITGS-9003 Installation And Operating Instructions

WALL PANIC ALARM
INSTALLATION AND OPERATING INSTRUCTIONS
Please keep these instructions in a safe place for future reference.
Kit contents:
1 x Panic alarm complete with 7" ripcord for activation
1 x Panic alarm holder
3 x Screws and wall plugs
1 x Instruction lea et

1. Introduction

The Wall Panic alarm is a convenient highly visible security device which is
ideal for use in the home or o ce. Its powerful 100dB siren and
bright ashing red light are immediately activated when the ripcord is pulled, yet it
can easily be deactivated using the switch on the side of the unit.

2. Battery installation

The Wall Panic Alarm requires 2 x AAA alkaline batteries (not included)
To install batteries:
• Unscrew the battery compartment cover and
remove (See Fig.1)
• Insert 2 x AAA alkaline batteries noting the
polarity diagram inside the compartment (see
Fig. 2)
• Replace the cover and screw closed
IMPORTANT:
• Remove batteries before storing the alarm for
long periods of time. Batteries corrode over time
and may cause permanent damage to the unit.
• Di erent types of batteries or new and old
batteries should not be mixed
• Depleted batteries should be removed from the
# ITGS-9003
. 1 .

3. Battery testing

• It is recommended that the alarm power is regularly tested by pressing the battery
test button on the front of the alarm or discreetly activating the alarm
• When the alarm siren weakens or the battery test indicates low batteries, replace
with new batteries

4. Mounting the Panic Alarm to the wall

• Select the location where you wish the Panic Alarm to be xed
• Use the panic alarm holder to mark the position of the 3 screws to be used to
secure it
• Drill holes in the 3 marked positions and insert wall plugs provided
• Place the holder on the wall and secure into the 3 wall plugs with the screws
provided
• Place the alarm unit in the holder, ensuring the ripcord is pulled through the hole
at the base of the holder

5. Operation

• Push the ON/OFF switch up to the ON position to arm the
alarm (Fig.3). The red LED will ash every 30 seconds to
indicate that the unit is armed.
• To activate the alarm simply pull downwards on the ripcord,
separating it from the alarm unit (Fig.4). The powerful 100dB
siren will sound and the red LED light will ash continually
• To stop the alarm, push the switch to the OFF position and
replace the ripcord pin into the alarm
• To deactivate the alarm, ensure the ripcord pin is replaced in
the unit, and push the ON/OFF switch to the OFF position
6. Care & maintenance
To clean the unit housing, use a soft cloth slightly dampened
Fig.1
with water, and wipe dry. Do not use chemical agents as this
may damage and discolour the unit
PROLONGED EXPOSURE TO THE ALARM SIREN MAY CAUSE
Fig.2
WARNING: RISK OF PERSONAL INJURY
PERMANENT HEARING LOSS
FOR INDOOR USE ONLY
DO NOT USE IN WET LOCATIONS
. 2 .
Fig.3
Fig.4
