PT FW430 P ro d u c t N u m b e r : LCD Projector P ro d u c t N a m e : As of March 2011. Specifications and appearance are subject to change without notice.
Power cord with security lock (× 1) Wireless remote control unit (× 1) Batteries for remote control (AA/R6/LR6 type × 2) Software CD-ROM (Logo Transfer Software, Multi Projector Monitoring and Control Software Ver. 2.5, Wireless Manager ME 5.5) (× 1) PT-FW430 ×...
NOTE: Wireless connection may not be possible with some IEEE 802.11b/g/n wireless LAN systems. Macintosh computers must have a built-in wireless LAN adapter. For IEEE 802.11n connection, use a wireless LAN adapter, projector and access point that are IEEE 802.11n compatible, and connect with Infrastructure mode.
Page 5
LCD Projector Dimensions (2-3/32) (16-15/16 ) Terminals DVI-I IN COMPUTER IN AUDIO IN SERIAL IN AC IN 9 10 As of March 2011 SFL11M005-1 LAN connector HDMI input S-VIDEO IN DVI-I input Computer input VIDEO VARIABLE AUDIO IN 3 AUDIO OUT...
(56.5) -0.05 – 4.09 PT-FW430 ** Adjustable in 20 mm (25/32˝) steps. NOTE: Illustrations show the projector installed using optional ceiling mount bracket ET-PKF110H. This illustration is not drawn to scale. unit : mm (inch) unit: meters (feet) – 1.5) –...
Page 7
LCD Projector Projection distance for 16:9 aspect ratio screen Projection size Projection distance [L] [diagonal] Min [wide] 0.84 m 33˝ – (–) 1.02 m 40˝ (3.8) 1.27 m 50˝ (4.7) 1.52 m 60˝ (5.7) 1.78 m 70˝ (6.7) 2.03 m 80˝...
Page 8
Optical axis shift function allows to shift the position of a projected image as shown below. (Width of projected image) 0.24H Installable angle Install the projector at an angle within the range shown below. • Vertical direction The projector may be installed at a vertical angle of 30°. As of March 2011 SFL11M005-1 0.24H...
NOTE: The native resolution of this projector is 1,280 × 800 pixels. If the display resolution of the input signal is different from the native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution.
Page 10
• It may not be possible to send or receive commands for about 10 to 60 seconds when the lamp is first turned on. If this occurs, wait for 60 sec- onds, then try sending or receiving again. • When sending multiple commands, be sure to wait for at least 0.5 second after receiving a response from the projector before sending the next command.
* 1 Do not send PON, POF or OSH commands continuously in a short period of time. Doing so may burst the lamp or shorten the lamp replace- ment cycle. * 2 When a command that cannot be executed during standby mode is sent, the projector will send an ER401 command in reply. As of March 2011 SFL11M005-1 Callback: <Parameter>...
AV mute function status Keystone correction status Color temperature adjustment status Date setting status Time setting status NOTE: If a wrong command is received, the projector will send an ER401 command to the computer. As of March 2011 SFL11M005-1 Auto Auto...
<lamp condition> <acctch> <color temp> <date> <time> NOTE: If a wrong command is received, the projector will send an ER401 command to the computer. Command example To set the volume to +30, send the command as shown below. Start Command NOTE: When sending commands without parameters, a colon (:) is not necessary.
Page 14
Do not stack projector units directly on top of one another for the purpose of multiple (stacked) projection. When stacking projector units, be sure to provide the amount of space indicated below between them.
