Panasonic PT-DZ8700U Specifications
3-chip dlp projector
Hide thumbs
Also See for PT-DZ8700U:
- Operating instructions manual (129 pages) ,
- Specifications (6 pages)
Related Manuals for Panasonic PT-DZ8700U
Summary of Contents for Panasonic PT-DZ8700U
- Page 1 PT-DZ8700U P ro d u c t N u m b e r : 3-Chip DLP P ro d u c t N a m e : As of July 2010. Specifications subject to change without notice. SFD10M001 ® Projector...
-
Page 2: Specifications
When using both the KEYSTONE and CURVED corrections of the Geometric Adjustment function: Vertical ±5°, horizontal ±5° (vertical ±10° and horizontal ±10° with the ET-D75LE3, vertical ±10° and horizontal ±15° with the ET-D75LE4/D75LE8) Ceiling/floor, front/rear PT-DZ8700U . 6 W with ® projection system 60 Hz,... - Page 3 530 mm × 200 mm* (20-7/8˝ × 7-7/8˝ * × 21-19/32˝ * Approx. 24 kg (52.9 lbs) (without lens) 0°–45°C (32°–113°F)* 10%– 80% (no condensation) PT-DZ8700U 4:2:2 10-bit): 4:2:2 10-bit): (1,920 × 1,200), (1,920 × 1,200), ): 0.7 Vp-p, 75 ohms ): 0.7 Vp-p, 75 ohms...
- Page 4 *9 Operation range differs depending on environments. As of July 2010 SFD10M001 PT-DZ8700U 3 V DC (AA type battery × 2) Approx. 30 m (98 ft 5 in) when operated from directly signal receptor 51 × 176 × 28 mm (2˝ × 6-15/16˝ × 1-3/32˝) Approx.
- Page 5 Remote 1 output Remote 2 input Serial input Serial output SDI input HDMI input 11 12 13 PT-DZ8700U unit : mm (inch) NOTE: This illustration is not drawn to scale. 468 (18-7/16 ) Video input S-Video input 10 RGB 1 input...
-
Page 6: Standard Setting-Up Position
• All construction work should be done by a qualified technician. • When mounting to the ceiling, use the special mounting bracket. To prevent the projector from swaying or drop- ping, attach the wire that is included with the projector between the mounting bracket and the ceiling. -
Page 7: Projection Distance For 16:10 Aspect Ratio Screen
131.3 69.0 132.9 209.0 86.3 85.7 166.3 164.2 261.4 103.6 102.9 199.7 197.1 313.7 PT-DZ8700U Unit: millimeters Height from the edge of screen to center of lens (H) Fixed-focus Zoom lenses ET-D75LE8 ET-D75LE5 Zoom lens Fixed-focus Except ET-D75LE6 lens ET-D75LE6 min. - Page 8 39.1 -0.3 – 29.3 49.0 -0.4 – 39.1 65.5 -0.5 – 49.0 81.9 -0.6 – 11.6 58.8 98.4 -0.7 – 14.0 78.6 131.3 -0.9 – 18.6 98.3 164.2 -1.2 – 23.2 197.1 -1.4 – 27.9 PT-DZ8700U 8 / 1 9...
-
Page 9: Projection Distance For 16:9 Aspect Ratio Screen
135.0 70.9 136.7 214.9 88.7 88.1 170.9 168.8 268.6 106.5 105.8 205.2 202.6 322.4 PT-DZ8700U Unit: millimeters Height from the edge of screen to center of lens (H) Fixed-focus Zoom lenses ET-D75LE8 ET-D75LE5 Zoom lens Fixed-focus Except ET-D75LE6 lens ET-D75LE6 min. - Page 10 40.2 -0.5 – 30.1 50.4 -0.7 – 40.2 67.3 -0.9 – 50.4 84.2 -1.1 – 11.3 60.5 101.1 -1.3 – 13.5 80.7 134.9 -1.7 – 18.0 168.8 -2.1 – 22.5 202.6 -2.5 – 27.0 PT-DZ8700U 1 0 / 1 9...
-
Page 11: Calculation Of The Projection Distance
L (mm) = (diagonal screen size in inches) × 164.0 – 386.2 L (mm) = (diagonal screen size in inches) × 307.2 – 359.8 L (mm) = (diagonal screen size in inches) × 15.8 – 83.5 PT-DZ8700U 1 1 / 1 9... - Page 12 • Because the ET-D75LE5 is a fixed short-throw lens, the lens shift function cannot be used with it. Installable angle Install the projector at an angle within the range shown below. • Vertical direction The projector may be installed at a vertical angle of 360°.
-
Page 13: List Of Compatible Signals
NOTE: The native resolution of this projector is 1,920 × 1,200 pixels. If the display resolution of the input signal is different from the native resolution, image compression or expansion will be used to convert the input signal to a level within the native resolution. - Page 14 46.3 75.0 60.0 65.3 60.0 54.1 50.0 55.6 49.9 59.9 66.6 67.2 60.0 61.8 49.9 74.0 60.0 74.6 59.9 PT-DZ8700U Dot clock Format frequency (MHz) 68.0 HDMI/DVI-D/RGB 83.5 71.0 106.5 122.5 108.0 88.0 108.0 125.0 135.1 135.0 157.5 84.8 69.0 99.9...
- Page 15 • It may not be possible to send or receive commands for about 10 to 60 seconds when the lamp is first turned on. If this occurs, wait for 60 seconds, then try sending or receiving again. • When sending multiple commands, be sure to wait for at least 0.5 second after receiving a response from the projector before sending the next command.
- Page 16 * Do not send PON, POF, OSH, or OLP commands continuously in a short period of time. Doing so may burst the lamp or shorten the lamp replacement cycle. * When a command that cannot be executed during standby mode is sent, the projector will send an ER401 command in reply. As of July 2010...
- Page 17 SFD10M001 Callback p1p2p3p4p5 p1p2p3p4 p1p2p3p4 DLVI0=+00000 DLVI0=+00001 DLVI0=+00002 DLVI0=+00003 (*1) p1p2p3p4/p5p6p7p8 y1y2y3y4m1m2d1d2w h1h2m1m2s1s2 Command Parameter PT-DZ8700U Description Standby (Off) HDMI RGB 1 RGB 2 Video S-Video 00000h –99999h 0000h –9999h 0000h –9999h Dual (two lamps) Single (one lamp) High Natural...
- Page 18 7. If the projector is not to be set on the floor using adjuster legs, install it by using the five ceiling- mount screw holes (screw diameter: M6, length of each screw hole in the projector: 8 mm (5/16˝)).
- Page 19 Projector Operating the projector continuously If the projector is to be operated continuously 24 hours a day, use the dual-lamp optical system’s alter- nating lamp operation (lamp changer) function. The projector cannot be operated continuously 24 hours a day in dual-lamp mode.
