Page 1
- Liquid-cooling system - Dustproof design with sealed optical block S P E C F I L E PRODUCT NO.: PT-DW7000 - Dual lamp system and lamp relay function - Optional long-life lamp - Easy lamp replacement - Dust filter cleaning •...
HD digital serial component signal, SMPTE 292M compliant: 720/60p, 720/50p, 1035/60i, 1080/60i, 1080/50i, 1080/25p, 1080/24p, 1080/24sF, 1080/30p RJ-45 x 1, 10Base-T/100Base-TX, for network * Shift range is limited during simultaneous horizontal and vertical shifting. PT-DW7000 15.63 kHz; f 50 Hz, 31.25 kHz; f 50 Hz, 60 Hz, 1080/60i: f 33.75 kHz;...
Page 3
ET-PKD75 (for high ceilings) ET-PKD75S (for low ceilings) ET-DFD75 ET-HAD75 ET-D75LE1 ET-D75LE2 ET-D75LE3 ET-D75LE4 ET-D75LE8 ET-D75LE5 ET-MD77DV ET-MD77NT ET-MD77SD1 (480i,576i) ET-MD77SD3 (720/60p, 720/50p, 1035/60i, 1080/60i, 1080/50i,1080/25p, 1080/24p, 1080/24sF, 1080/30p) ET-RMRC2 Weights and dimensions shown are approximate. Specifications subject to change without notice. PT-DW7000...
Page 4
(18-3/16˝) (1-5/16˝) Weights and dimensions shown are approximate. Specifications subject to change without notice. signal * Effective when connected to a PC having proper functions. PT-DW7000 (7-1/2˝) (10-3/8˝) (18-7/16˝) Note: This illustration is not drawn to scale. Remote 1 input/output...
27.49 41.25 41.26 68.95 90.2 135.3 135.4 226.2 PT-DW7000 The projector with optional ceiling mount bracket ET-PKD75 and zoom lens ET-D75LE1. The projector with optional zoom lens ET-D75LE1. The projector with optional ceiling mount bracket ET-PKD75 and zoom lens ET-D75LE1.
As of April 2005 PT-DW7000 L (mm) = (diagonal screen size in inches) x 34.3 - 76 L (mm) = (diagonal screen size in inches) x 45.8 - 100.4 L (mm) = (diagonal screen size in inches) x 46.0 - 79.5 L (mm) = (diagonal screen size in inches) x 68.9 - 106.4...
