All installations and services must be performed by qualified service personnel.
II. FURNACE SPECIFICATIONS
MODEL
INPUT IN BTUH
OUTPUT IN BTUH
MAIN ORIFICE-NAT.
MAIN ORIFICE-LP
GAS SUPPLY PRESSURE
L.P. MINIMUM
NAT. MINIMUM
L.P. MAXIMUM
NAT. MAXIMUM
GAS MANIFOLD PRESSURE
L.P.
NAT.
INTAKE SIZE IN INCHES
VENT SIZE IN INCHES
NOMINAL TEMPERATURE RISE
SEASONAL EFFICIENCY (AFUE*)
*ANNUAL FUEL UTILIZATION
EFFICIENCY
DIMENSIONS
CABINET SIZE
SUPPLY AIR OUTLET
ELECTRICAL SUPPLY
FUSE OR HACR BREAKER
TOTAL CURRENT AMPS
NOMINAL ANTICIPATOR SETTING
FILTER SIZE
APPROXIMATE SHIPPING WEIGHT
BLOWER DATA
BLOWER MODEL
MOTOR HORSEPOWER
MOTOR RPM
CFM @ .2 & .5 IN. W.C.
FOR BURNER COMBUSTION INFORMATION REFER TO INITIAL STARTUP.
VMA3-50D36
50,000
48,000
WIDTH 18" DEPTH 25-3/4" HEIGHT 57"
175 LBS.
SPEED .2"
LOW 805
MD-LOW 1010
MD-HIGH 1196
HIGH 1338
7
#42
#54
11" IN.W.C.
4.5"IN.W.C.
14" IN.W.C.
14" IN.W.C.
10.0" + .03 IN.W.C.
3.5" + .03 IN. W.C.
2"
2"
55°F
95%
WIDTH 12" DEPTH 12"
115 VOLTS-- 60HZ --1/PH
15 AMPS
7.15 AMPS
0.8 MILLIAMPS
(1) 18" X 24" X 1"
12-9T DIRECT DRIVE
1/2 PSC
1065 (HIGH SPEED)
.5" |
695 | 797
860 | 995
1038 | 1210
1162 | 1420
VMA3-75D36
75,000
72,000
65°F
185 LBS.
.2" .5"
668
869
1076
1259
