- Page 1 OC915400TX For assistance with assembly contact: Double-Door Mirrored Cabinet - Red Southern Enterprises Inc. Customer Service 1-800-633-5096 Assembly Instruction service@seidal.com www.seidal.com PO# 12985...
-
Page 2: Parts List
OC915400TX Double-Door Mirrored Cabinet - Red Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. - Page 3 Assembly Tool Required Phillips and Flat Head HZ205700TX DOUBLE-DOOR MIRRORED CABINET - RED Assembly Instructions Step 1: Attach bottom panel (F) and back top rail (D) to left frame (B) using camlock (2), cambolt (3), wood dowel (4), and allen wrench (5).
- Page 4 Step 2: Attach right frame (C) to bottom panel (F), and back top rail (D) by using camlock (2), cambolt (3), wood dowel (4), and allen wrench (5). Tighten camlock with screwdriver. Step 3: Attach back panel (3) using screw (6).
- Page 5 Step 4: Attach magnet (8) to top panel (A) using screw (6) Step 5: Attach top panel (A) to back top rail (D), left frame (B) and right frame (C) using camlock (2), cambolt (3), and allen wrench (5). Tighten camlock with screwdriver.
- Page 6 Step 6: Attach knobs (10) to left and right doors (G) and (H) using screw (9). Step 7: Attach doors to assembled unit by aligning the pre-installed hinges on the doors to the pre-drilled holes located on the left and right frame (B) and (C).
- Page 7 Step 8: Insert shelf supports (7) into the desired holes inside the assembled unit and place the adjustable shelf (I) on top of the shelf supports.
-
Page 8: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
