- Page 1 OC419000TX Streamer Trunk Side Table For assistance with assembly contact: Assembly Instruction Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com Max Top Load 25lb and inside load 25lb.
- Page 2 OC419000TX Streamer Trunk Side Table Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Screws shown actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
-
Page 3: Side Table
OC419000TX Streamer Trunk Side Table Assembly Instruction Step 1: Attach left side panel (C) and right side panel (D) to back panel (A) by using cam bolt (1) and cam lock (2) as shown. Step 2: Insert bottom panel (E) to the groove side panel as shown. - Page 4 Step 3: Attach front panel (B) to the frame by using cam bolt (1) and cam lock (2) as shown. Step 4: Using bracket (10) to fix the bottom corners of side panels as shown.
- Page 5 Step 5: Attach top (F) to the trunk base by using screw (7) and Phillips screw driver to tighten hinge (6) it as shown. Step 6: Attach support (3) (4) to the top (F) and trunk base by using screw (5) as shown. Attach handle (8) on side panel (C) (D) by using bolts (9) as shown.
-
Page 6: Parts Replacement Form
We'd love to hear from you! Email us photos of our products in your home at sei@seidal.com and we might feature it on our site or use it to model one of our inspirational photos. “PARTS WILL BE SENT IF AVAILABLE FROM SEI” Parts Replacement Form Customer Information...
