- Page 1 USER MANUAL USB Bluetooth Adapter UBT-120...
-
Page 2: Table Of Contents
Introduction--------------------------------------------------------------------------------- 2 Package Content------------------------------------------------------------------------- 2 Product Features------------------------------------------------------------------------- 2 System Requirements------------------------------------------------------------------ 3 Driver Installation ----------------------------------------------------------------- 3 ® Windows 98SE/ME/2000/XP Driver Installation------------------------------3 ® Windows 98SE Platform -----------------------------------------------------------9 Bluetooth Logo Conditions ------------------------------------------------------- 10 FCC Statement -------------------------------------------------------------------------- 11 Disclaimer ----------------------------------------------------------------------------- 11 CONTENT USB Bluetooth Adapter User Manual Page 1... -
Page 3: Introduction
Introduction The Comsol Bluetooth Adapter is a quick and easy solution for users wanting to add Bluetooth capability to their desktop or notebook. It plugs directly into your USB port of your computer and enables wireless connectivity with Bluetooth devices including mobile phones, PDAs, printers and other computers. -
Page 4: System Requirements
System Requirements ® PC Pentium 133 or higher or compatible system Available USB2.0 port (up to 480 Mbps) or available USB1.1 port (up to 12Mbps) ® Windows 98, Windows Driver Installation ® 5.1 Windows 98SE/ME/2000/XP Driver Installation DO NOT INSERT THE BLUETOOTH ADAPTER BEFORE FOLLOWING THESE INSTRUCTIONS 5.1.1 Insert the supplied CD disk into the CD-ROM drive. - Page 5 5.1.3 Select “I accept …” to enable installation of the software and click Next. 5.1.4 NOTE: Depending on the OS installed, this screen may not appear during initial installation. USB Bluetooth Adapter User Manual Page 4...
- Page 6 Choose the destination folder for installation and click Next. 5.1.5 Click Install to confirm installation of the software. USB Bluetooth Adapter User Manual Page 5...
- Page 7 5.1.6 Click OK to disable unsigned driver warnings and proceed with the installation. 5.1.7 PLEASE DO NOT ADAPTER Click Cancel to continue installation without the Bluetooth device. CONNECT THE COMSOL USB BLUETOOTH USB Bluetooth Adapter User Manual Page 6...
- Page 8 5.1.8 When installation is completed, follow the instructions to reboot the system. 5.1.9 Insert the Comsol USB Bluetooth Adapter into an available USB port of the PC after the software installation is complete and the system has rebooted. After the Comsol Bluetooth Adapter is inserted, the Found New Hardware Wizard will pop up.
- Page 9 5.1.10 After completion of the driver installation, an icon will show up at the lower-right corner of the desktop, announcing the availability of the new hardware. USB Bluetooth Adapter User Manual Page 8...
-
Page 10: Windows ® 98Se Platform
5.2 Win98SE platform 5.2.1 When installing, it would request the Win98 CD as below. 5.2.2 Click “OK”. 5.2.3 And then the dialog would appear, Click “Cancel”. 5.2.4 Then wait the installation finished, and reboot the system. If Windows booted, insert the dongle. The driver would auto-loaded. USB Bluetooth Adapter User Manual Page 9... -
Page 11: Bluetooth Logo Conditions
Bluetooth Logo Conditions 6.1 Condition 1: Disconnection of the Bluetooth Network (The Bluetooth Network is disconnected while the Bluetooth dongle is still plugged in and the software is under operation.) 6.2 Condition 2: Failure to detect the Bluetooth dongle (The Bluetooth icon turns red, indicating the failure to detect the Bluetooth dongle.) 6.3 Condition 3: Availability of the Bluetooth dongle (The Bluetooth icon turns white, indicating the availability of the Bluetooth... -
Page 12: Fcc Statement
FCC Statement This device generates and uses radio frequency and may cause interference to radio and television reception if not installed and used properly. This has been tested and found to comply with the limits of a Class B computing device in accordance with the specifications in Part 15 of FCC Rules.
