- Page 1 Assembly SBM6 Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions SBM6 Notes on the products Before using the device, carefully read the assembly instructions and keep it with the SBM6 swi- Read manual vel bracket. before use! General information Assembly instructions: OM-SBM6 Version 2.0 en, 05/2022 © by TWAMBO 2022; all rights reserved.
-
Page 4: Table Of Contents
Setup ........................9 Wind load ........................ 9 Assembly SBM6 to loudspeaker ................10 Assembly SBM6 swivel bracket to trusses or ceiling ..........10 Assembly SBM6 swivel bracket on tripod .............. 11 5. Transport and storage ....................12 6. CE Conformity Declaration .................... 13... -
Page 5: Safety | Intended Use
Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the SBM6 swivel bracket for its com- pleteness and ensure that all parts are in perfect condition. The scope of delivery includes specified components. Only use the recommended and cer- WARNING tified components. - Page 6 Assembly Instructions SBM6 The payload of the SBM6 swivel bracket is designed of one M6 loudspeaker. Do not exceed this payload. WARNING Before mounting the SBM6 swivel bracket check that ceilings, trussus and tripods are capable to carrying the payload of the components.
-
Page 7: Overview
Assembly Instructions SBM6 2. Overview Components Figure 2.1 - Overview Cross handle with thread M10 x 25 ..............1 piece Rotating plate (metal) ..................1 piece Swivel bracket SBM6 ..................1 piece... -
Page 8: Technical Data
Assembly Instructions SBM6 3. Technical data Data sheet Maximum load capacity 1x M6 Dimensions (h x w x d) 232 x 275 x 46 mm [11.61 x 25.28 x 1,97 in] Weight 0,9 kg [1.98 lbs] Surface Powder-coated... -
Page 9: Commissioning
4. Commissioning Setup The SBM6 swivel bracket is designed for the hanging and stacking operation. TW AUDiO pro- vides a wide range of accessories to securely attach the swivel bracket. Please note that setting up the system structures always requires two persons! -
Page 10: Assembly Sbm6 To Loudspeaker
Assembly SBM6 swivel bracket to trusses or ceiling Attach the DHST Doughty Halfcoupler Slimline to the ø12.6mm hole located on the crossbar of the SBM6 swivel bracket when using the SBM6 swivel bracket on trusses. Make sure that the connections are set firmly and correctly! -
Page 11: Assembly Sbm6 Swivel Bracket On Tripod
Assembly Instructions SBM6 Assembly SBM6 swivel bracket on tripod Mount the M6 loudspeaker with SBM6 swivel bracket and the HSF pole mount flange on the tripod. Make sure that you use suitable fastening material and that the connections are set... -
Page 12: Transport And Storage
Assembly Instructions SBM6 5. Transport and storage When transporting and storing the unit, it is important to ensure that the surface of the swi- vel bracket are not damaged. Moisture can penetrate where steel surfaces are exposed by scratches and result in corrosion. -
Page 13: Ce Conformity Declaration
Assembly Instructions SBM6 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 14 Assembly Instructions SBM6 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
