- Page 1 Assembly SBM15 Instructions...
- Page 2 If you lend your product to another party, inform that party of the safety-related operating pro- cedures and hand over this assembly guide. If you require additional copies of this manual, you can obtain them free of charge from TW AUDiO or download them from www.twaudio.de Instructions in this user manual...
- Page 3 Assembly Instructions SBM15 Notes on the products Before using the device, carefully read the assembly instructions and keep it with the Read manual SBM15 swivel bracket. before use! General information Assembly instructions: OM-SBM15 Version 2.0 en, 05/2022 © by TWAMBO 2022; all rights reserved.
-
Page 4: Table Of Contents
Setup ........................9 Wind load ........................ 9 Assembly SBM15 to loudspeaker ................9 Assembly SBM15 swivel bracket to trusses or ceiling ..........10 Assembly SBM15 swivel bracket on tripod ............11 5. Transport and storage ....................12 6. CE Conformity Declaration .................... 13... -
Page 5: Safety | Intended Use
Note the operating modes described in this assembly instructions. Other uses are not per- missible. Damage caused by improper use is not covered by TWAMBO. Before every operation, check the scope of delivery of the SBM15 swivel bracket for its com- pleteness and ensure that all parts are in perfect condition. WARNING The SBM15 swivel bracket may only used with the M15 loudspeaker. - Page 6 Assembly Instructions SBM15 The payload of the SBM15 swivel bracket is designed of one M15 loudspeaker. Do not exceed this payload. WARNING Before mounting the SBM15 swivel bracket check that e.g. ceilings, trussus and tripods are capable to carrying the payload of the components.
-
Page 7: Overview
Assembly Instructions SBM15 2. Overview Components Figure 2.1 - Overview Inner bracket Outer bracket Retainer Cross handle... -
Page 8: Technical Data
Assembly Instructions SBM15 3. Technical data Data sheet Maximum load capacity 1x M15 Dimensions (h x w x d) 475 x 529 x 190mm [18.7 x 20.83 x 7,48 in] Weight 5,6 kg [12.3 lbs] Surface Powder-coated... -
Page 9: Commissioning
1. Place the M15 loud speaker on the floor with the bottom or top, depending on the appli- cation. Make sure to place the speaker on a clean, non-slippery surface. 2. Place the SBM15 swivel bracket with its lengthwise strut of the inner bracket on the rig- ging track of the M15 loudspeaker. -
Page 10: Assembly Sbm15 Swivel Bracket To Trusses Or Ceiling
Assembly Instructions SBM15 3. Then pull the two retainer (see figure 2.1 - pos.3) up. 4. Then snap the SBM15 swivel bracket into the rigging track of the M15 loudspeaker by releasing the two retainer again. 5. Make sure that all retainers are always completely inserted! WARNING Figure 4.3 - Assembly SBM15 to M15 loudspeaker... -
Page 11: Assembly Sbm15 Swivel Bracket On Tripod
Assembly Instructions SBM15 Assembly SBM15 swivel bracket on tripod Mount the M15 loudspeaker with SBM15 swivel bracket and the HSF pole mount flange on the tripod. Make sure that you use suitable fastening material and that the connections are set... -
Page 12: Transport And Storage
Assembly Instructions SBM15 5. Transport and storage When transporting and storing the unit, it is important to ensure that the surface of the swi- vel bracket are not damaged. Moisture can penetrate where steel surfaces are exposed by scratches and result in corrosion. -
Page 13: Ce Conformity Declaration
Assembly Instructions SBM15 6. CE Conformity Declaration Copy and translation of the original CE Conformity Declaration: We hereby declare that the below-referenced components by virtue of their design and con- struction, and in the configuration placed on the market by us, satisfy the safety and health requirements of the applicable EC directives. - Page 14 Assembly Instructions SBM15 TWAMBO GmbH Karl-Hofer-Str. 42 14163 Berlin Germany Phone: + 49 (0) 71 41-48 89 89 0 Fax: + 49 (0) 71 41-48 89 89 99 E-Mail: info@twaudio.de WWW: www.twaudio.de...
