Service Facts
American Standard Link or AccuLink™ ™
Variable Speed Heat Pumps and Air Conditioners
4A6V0X24A1000A
4A6V0X36A1000A
4A6V0X48A1000A
4A6V0X60A1000A
The Diagnostics Mobile App is available by scanning a QR code
located inside this unit or by searching for the Link Diagnostics App
in your App Store ® .
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of heating, ventilating, and air-conditioning
equipment can be hazardous and requires specific knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person
could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that
are attached to the equipment.
August 2022
4A7V0X24A1000A
4A7V0X36B1000A
4A7V0X48A1000A
4A7V0X60A1000A
4A7V0X61A1000A
S S A A F F E E T T Y Y W W A A R R N N I I N N G G
4 4 A A - - V V 0 0 X X - - S S F F - - 1 1 C C - - E E N N
N N o o t t e e : : "Graphics in this document are for representation only. Actual
model may differ in appearance."
N N o o t t e e : : This unit can be used in AccuLink ™ mode or American Standard
Link mode.
