DIGITAL VIDEO CAMERA
GR-DVL9000
Downloaded from:
INSTRUCTIONS
https://www.usersmanualguide.com/
Please visit our CyberCam Homepage on
the World Wide Web and answer our
Consumer Survey (in English only):
http://www.jvc-victor.co.jp/index-e.html
ENGLISH
EN
LYT0166-001A

Advertisement

Table of Contents
loading

Related Manuals for JVC GR-DVL9000U

Summary of Contents for JVC GR-DVL9000U

  • Page 1 DIGITAL VIDEO CAMERA GR-DVL9000 ENGLISH Please visit our CyberCam Homepage on the World Wide Web and answer our Consumer Survey (in English only): http://www.jvc-victor.co.jp/index-e.html INSTRUCTIONS LYT0166-001A Downloaded from: https://www.usersmanualguide.com/...
  • Page 2 Dispose of used battery properly. camcorder. Keep away from children. If you lose the provided AC Power Adapter/ Do not disassemble and do not dispose of in Battery Charger or if it malfunctions, please fire. consult your nearest JVC service dealer. Downloaded from: https://www.usersmanualguide.com/...
  • Page 3 SAFETY PRECAUTIONS About Batteries DANGER! Do not attempt to take the batteries Do not point the lens or the viewfinder directly into apart, or expose them to flame or excessive heat, as the sun. This can cause eye injuries, as well as lead there is a risk of fire or explosion.

  • Page 4: Provided Accessories

    PROVIDED ACCESSORIES AC Power Remote control unit Adapter/Charger AA-V80EG RM-V711U MiniDV Cassette Tape 30 min Battery pack BN-V814U (DVM-30) M-DV30ME Lithium battery CR2025 for remote Shoulder Strap control unit (For function confirmation) Editing cable VIDEO/AUDIO cable (ø 3.5 mini-plug, 2 poles) (camcorder to TV or VCR, ø...
  • Page 5 S-VIDEO cable DC cord Cleaning cloth CD-ROM The CD ROM contains the following 3 software programmes: •JLIP Video Capture •JLIP Video Producer •MGI PhotoSuite SE JLIP-PC connection cable Downloaded from: https://www.usersmanualguide.com/...

  • Page 6: About Dv

    ABOUT DV The digital video camera converts incoming audio and video signals into digital form for recording. A video signal is composed of a luminance signal (Y) and colour signals (R-Y and B-Y). These signals are identified and recorded digitally (Digital Component Recording). The A/D (Analogue to Digital) converter samples the Y signal at 13.5 MHz, and R-Y and B-Y at 6.75 MHz, and changes them to an 8-bit quantum signal.

  • Page 7: Table Of Contents

    CONTENTS PROVIDED ACCESSORIES ABOUT DV GETTING STARTED Charging The Battery Pack ..............8 Installing The Battery Pack ..............9 Indoor Use ..................10 Using The Power Pack ............... 10 Date/Time Settings ................11 Loading/Unloading A Cassette ............. 12 Recording Mode Setting ..............13 Grip Strap Attachment ...............

  • Page 8: Getting Started

    GETTING STARTED Charging The Battery Pack You can charge one battery pack at a time, or two consecutively. ATTACH DETACH Battery pack BN-V814U To AC outlet Power cord Power cord Charger AC Power indicator 1 Adapter/Charger AA-V80EG Power lamp DC OUT jack Charger indicator 2 NOTES: SUPPLY POWER TO CHARGER...

  • Page 9: Installing The Battery Pack

    Charging Environment Perform charging where the temperature is between 10° and 30°C. (20° to 25°C is the ideal temperature range for charging.) If the environment is too cold, charging may be incomplete. Continuous Shooting Continuous shooting is possible (See table below for recording time) under the following conditions: •...

  • Page 10: Indoor Use

    GETTING STARTED (Cont.) Indoor Use When using the camcorder indoors, you can use the AC Adapter instead of a battery. Power cord To AC outlet Connector is under the cover DC-IN AC Power Adapter/Charger Power lamp When power is Core supplied, the Filter power lamp lights.

  • Page 11: Date/Time Settings

    Date/Time Settings Date and time will automatically be recorded on tape at all times. It is your choice to display it or not during playback ( pg. 54). LCD monitor REC MODE WIDE MODE Power lamp ZOOM GAIN UP Power Dial TO DATE / TIME MENU TO SYSTEM MENU Recording Menu...

  • Page 12: Loading/Unloading A Cassette

    GETTING STARTED (Cont.) Loading/Unloading A Cassette The camcorder needs to be powered up to load or eject a cassette. Cassette cover Cassette holder OPEN/EJECT PUSH-OPEN switch button Erase protection switch** Make sure the window PUSH HERE side is facing out. NOTES: OPEN LCD MONITOR ●...

  • Page 13: Recording Mode Setting

    Recording Mode Setting Set depending on your preference. LCD monitor Power lamp Recording Menu Power dial REC MODE WIDE MODE ZOOM GAIN UP TO DATE / TIME MENU TO SYSTEM MENU Lock button REC MODE WIDE MODE ZOOM MENU button Select Dial GAIN UP TO DATE / TIME MENU...

  • Page 14: Grip Strap Attachment

    GETTING STARTED (Cont.) Grip Strap Attachment Tripod Mounting Align the tripod’s screw with the mounting socket on the bottom of the camcorder. The camcorder can be mounted on a tripod even Zoom switch with the Power Pack attached. Bottom of the camcorder START/STOP ADJUST LENGTH Open the pad...

  • Page 15: Shoulder Strap Attachment

    Shoulder Strap Attachment When transporting the camcorder, it is convenient to use the shoulder strap. ATTACH SHOULDER STRAP As shown in of the illustration, thread the strap through the eyelets and the buckles. Pull the strap to make sure it is attached to the camcorder firmly.

  • Page 16: Remote Control Unit

    GETTING STARTED (Cont.) Remote Control Unit You can use the RM-V711U to control the camcorder. When using the remote control, be sure to point it at the remote sensor. The transmitted beam effective area for indoor use is approx. 5 m. The transmitted beam may not be effective or may cause incorrect operation if the remote sensor is directly exposed to sunlight or powerful lighting.

  • Page 17: Operation Mode

    Operation Mode Tuning the Power Dial allows you to choose the appropriate operation mode among the following modes: Full Auto mode ( ), Manual mode ( ), 5 second mode recording (5S), Self-Timer mode ( ) and “PLAY”. According to the Power Dial position you have selected, “F.AUTO”...

  • Page 18: Recording

    RECORDING Basic Recording You should already have performed the necessary preparations ( pgs. 8 – 17). Set the Power Dial to “ ” and try recording that way before attempting to use more advanced features. NOTE: Before starting recording, make sure you set the date and time ( pg.
  • Page 19 NOTES: SELECT OPERATION MODE ● The image will not appear simultaneously in the Set the Power Dial to “ ” while pressing down LCD monitor and the viewfinder. No image the lock button located on the dial. appears on the LCD monitor when the viewfinder PULL OUT VIEWFINDER OR OPEN is pulled out.
  • Page 20 RECORDING Basic Recording (Cont.) Recording From The Middle Of A Tape When removing a tape on which you were recording, or when you resume recording on a tape after playing back the recording previously made (without taking the tape out between recordings), perform this proce- dure.
  • Page 21 Time Code During recording, a time code is recorded on the tape. This code is to confirm the location of the recorded scene on the tape during playback. If recording starts from a blank portion, the time code begins counting from “00:00:00” (minute:second:frame).
  • Page 22 RECORDING Basic Recording (Cont.) Tape Remaining Indicator The time remaining on the tape is automatically monitored and displayed ( pg. 79). When the tape ends, “TAPE END” appears. If the indications are turned off, the tape remaining indicator appears when remaining time reaches 2 minutes.
  • Page 23 Journalistic shooting In some situations different angles of shooting may be required for more dramatic results. OPEN LCD MONITOR Make sure the viewfinder is pushed back and the LCD monitor is fully open (approx. 90°). TILT LCD MONITOR Tilt the LCD monitor in the most convenient direction.
  • Page 24 RECORDING Basic Recording (Cont.) Zoom Select any one of the three powers of magnification and get “closer” to the subject ( pg. 33). Simply set the zoom switch to either zoom in (towards “T”) or zoom out (towards “W”). The zoom speed is variable —...

  • Page 25: Advanced Features

    RECORDING Advanced Features Displaying The Date And Time During Recording When the Power Dial is set to “ ”, “5S” or “ ”, you can choose whether to display the date and time during recording or not. You must first set the date and time (see “Date/Time Settings” pg.
  • Page 26 RECORDING Advanced Features (Cont.) Scene (5-second recording) Record a vacation or an important event in 5-second clips to keep the action moving. The 5-Second function may also be activated during Full Auto operation. But the White Balance remains in the previously adjusted condition.
  • Page 27 Self-Timer Once the camcorder is set, the camcorder operator can become part of the scene in a more natural way adding the final touch to a memorable picture. Begins blinking Blinks quickly Stops blinking and ¥ ¥ (Self-Timer starts) (Self-Timer shooting stays on When the START/ starts soon)
  • Page 28 RECORDING Advanced Features (Cont.) Pro Snapshot Use your camcorder like a regular camera and take a snapshot, or several of them in succession. Progressive Button Display PHOTO Progressive Dial During snapshot Power Dial Lock button SELECT OPERATION MODE TAKE PRO SNAPSHOT First turn the Power Dial to “...
  • Page 29 Pro Snapshot mode Pro Snapshot mode Pin-Up mode with frame* with no frame* Multi-Analyzer 4** Multi-Analyzer 9** Nega/Posi mode* * : There is a momentary camera shutter-type blackout together with the sound effect of a shutter closing, which is recorded together with the image. ** : This will be disabled when P.AE/Effects other than “SHUTTER”...
  • Page 30 RECORDING Advanced Features (Cont.) Description of Progressive Scan CCD Progressive Scan is a special image sensing method which, unlike conventional interlace scanning, is able to pick up all the lines of picture information in one Scan. Since the Progressive Scan CCD is capable of outputting 50 full Frames* per second —...
  • Page 31 Menus The Recording Menu allows you to set these functions: Recording Mode, Wide Mode, Zoom Magnification, Digital Image Stabilizer, Gain Up, Date/Time Menu, System Menu . The following selection procedure applies to Recording Mode, Wide Mode, Zoom Magnifica- tion, Stabilization and Gain Up . Please refer to pages 32, 33 for details.
  • Page 32 RECORDING Advanced Features (Cont.) REC MODE WIDE MODE SQUEEZE CINEMA ZOOM GAIN UP 100X TO DATE / TIME MENU TO SYSTEM MENU REC MODE (Recording mode) You can change the tape recording speed. LP tape speed is slower than SP, allowing LP to record 1.5 times longer than SP.
  • Page 33 ZOOM (Zoom magnification) You can select 10X, 40X, or 100X maximum zoom magnifications. 10X–Optical zoom that does not degrade the quality of the recording. 40X–Electronic processing (Digital zoom) that lets you get closer up. 100X–Electronically-processed images at 100-times magnification. NOTES: ●...
  • Page 34 RECORDING Advanced Features (Cont.) System Menu The System Menu allows you to set the following functions: Scene, Beep/Tally, Wind Cut, Sound Mode and ID numbers. Display REC MODE WIDE MODE ZOOM GAIN UP TO DATE / TIME MENU TO SYSTEM MENU Recording Menu Power Dial SCENE...
  • Page 35 ANIM. SCENE BEEP / TALLY WIND CUT SOUND MODE 32kHz ID NUMBER 32kHz 48kHz This number is necessary when connecting the camcorder to a computer [01 to 99]. RETURN SCENE (5-Second Mode) ( pg. 26) WIND CUT 5S–Pressing START/STOP allows you to take a 5- When activated, this mode helps cut down on noise second “clip”.
  • Page 36 RECORDING Advanced Features (Cont.) FADE/WIPE Effects Use these to spice up the transition from one scene to the next. You can also vary transitions from scene to scene. Refer to pages 36 – 41 for Fade/Wipe effects and techniques. Select any one effect from the Fader/Wipe Menu. Display FADER / WIPE MANUAL...
  • Page 37 Fades and Wipes A scene gradually appears on a black or white screen (Fade In/Wipe In), or disappears, leaving a black or white screen (Fade Out/Wipe Out). Select Fade or Wipe at the Fader/Wipe Menu ( pg. 36). Select any one effect from , and of the Fader/Wipe Menu.
  • Page 38 RECORDING Advanced Features (Cont.) Picture Wipe/Dissolve Combine the Picture Wipe and Dissolve functions for a professional transition effect. There are 6 Picture Wipe effects and 1 Dissolve effect. Select the Picture Wipe effect at the Fader/Wipe Menu ( pg. 36). Select any one effect from of the Fader/Wipe Menu.
  • Page 39 Random Variations When is selected, the camcorder chooses one of the fades/wipes at random. START RECORDING Press START/STOP. The camcorder does the rest, selecting an effect at random. •The recording starts with a Fade In or Wipe In. If you press START/STOP during record- ing, Record-Standby mode is preceded by a Fade Out or Wipe Out;...
  • Page 40 RECORDING Advanced Features (Cont.) FADER AND WIPE MENU MENU EFFECT Fade in or out with a white screen. FADER — WHITE Fade in or out with a black screen. FADER — BLACK Fade in to a colour screen from a black and white screen, or FADER —...
  • Page 41 MENU EFFECT The new scene gradually appears as the old one gradually DISSOLVE disappears. The new scene wipes in over the previous one from the upper WIPE — CORNER right corner to the lower left corner. The next scene gradually wipes in from the centre of the screen WIPE —...
  • Page 42 RECORDING Advanced Features (Cont.) P.AE/Effects You can choose any one of the effects from the P.AE/Effect Menu. Display P. AE / EFFECT FOCUS AUTO EXPOSURE AUTO SLOW SHUTTER 1/50 PAUSE W. BALANCE AUTO VIDEO ECHO FADER / WIPE SHUTTER SEL. 4 1/50 1/50 P.
  • Page 43 SHUTTER (Variable Shutter (Speed) CLASSIC FILM 1/50–The shutter speed is fixed at 1/50th of a Gives recorded scenes a strobe effect. second. Black bands that usually appear when shooting a TV screen become narrower. 1/100–The shutter speed is fixed at 1/100th of a second.
  • Page 44 RECORDING Advanced Features (Cont.) Progressive Video Recording If an image is recorded using the Progressive Mode, it is possible to play back a jitter-free still image with superior quality. A high-resolution still image can also be processed on a personal computer or can be printed out ( pg.
  • Page 45 Manual Focus Adjustment The camcorder, in most cases, adjusts the focus from approx. 1.5 cm to infinity automatically. However, when focusing is difficult or when the subject is not in the middle of the LCD monitor or the viewfinder, adjust the focus manually. Factory preset is “AUTO”. Display Power Dial FOCUS...
  • Page 46 RECORDING Advanced Features (Cont.) Exposure Control Usually this is adjusted automatically. However, when the background is too bright or too dark in compari- son with the subject, the exposure could be corrected manually. Factory preset is “AUTO”. Display Power Dial FOCUS AUTO EXPOSURE...
  • Page 47 Iris Lock Use this function when shooting a moving subject, when zooming, when the subject changes its distance (thus its size in the LCD monitor or the viewfinder), or when you want to lock the brightness level. When the subject is close, keep the iris locked. Even when the subject moves away from you, the image will not darken.
  • Page 48 RECORDING Advanced Features (Cont.) White Balance Adjustment A term that refers to the correctness of colour reproduction under various lighting. If the white balance is correct, all other colours will be accurately reproduced. The white balance is usually adjusted automatically. However, the more advanced camcorder operator would prefer to control this function manually and achieve a more professional colour/tint reproduction.
  • Page 49 Manual White Balance Operation If the camera is operating in manual mode, perform a Manual White Balance when shooting under various types of lighting Display White paper FOCUS AUTO EXPOSURE AUTO W. BALANCE AUTO FADER / WIPE P. AE / EFFECT RETURN Manual Mode Item Menu...

  • Page 50: Playback

    PLAYBACK Basic Playback You can watch what you’ve recorded in the LCD monitor. Tape running indicator Volume switch VOL. Lock button Power lamp Power Dial LCD monitor Speaker OPEN LCD MONITOR VIEWING RECORDING Open the LCD monitor. Press 6/4. 4 appears and the recorded footage can be viewed.
  • Page 51 Slow-Motion Playback To Perform High-Speed Search ..press 2 or 3 after pressing 6/4. The tape ● To perform Slow-motion playback, the remote will move at approximately 9 times the normal control is necessary. playback speed. Watch in the LCD monitor and, ●...

  • Page 52: Advanced Features

    PLAYBACK Advanced Features Playback Zoom The recorded pictures can be magnified up to 10X at any time during playback. Stop button Zoom buttons RM-V711U (provided) Play button SHIFT Left/Right/Up/ Down buttons PLAY PAUSE STOP Lock button Power Dial Remote sensor Normal playback Press T Press...
  • Page 53 Playback Effects These effects allow you to be creative with the playback picture. You can use any one of the 5 effects. RM-V711U Play button (provided) PLAY EFFECT EFFECT ON/OFF Lock button Power Dial Remote sensor P. AE / EFFECT P.AE/EFFECT Select Menu (Playback) CLASSIC FILM...
  • Page 54 PLAYBACK Advanced Features (Cont.) Playback Menu The Playback Menu allows you to set the following functions: Playback Sound (32 kHz, 48 kHz), Synchro Comp, Display and Time Code . The following procedure applies to all except Synchro Comp ( pg. 66, 67). Display FULL SOUND Lock button...
  • Page 55 Playback Sound During playback, the camcorder detects the sound mode in which the recording was made, and plays the sound back. Select the type of sound to accompany your playback picture. (32 kHz is preset to “SOUND 1” and 48 kHz is preset to “FULL SOUND”.) RECORDING SOUND DISPLAY OUTPUT SOUND...

  • Page 56: Basic Connections

    PLAYBACK Basic Connections VCR/TV Connection Please refer to your VCR and/or TV instruction manual(s) when connecting. Connect when the S-VIDEO cable is not used To VIDEO IN connector VIDEO/AUDIO cable (provided) Yellow to VIDEO White to AUDIO L To AUDIO IN To AV OUT connector connector (L/R) Red to AUDIO R...
  • Page 57 NOTES: CONFIRM POWER-OFF STATUS ● Never connect any other VIDEO/AUDIO cable Make sure the camcorder’s power is off. than the provided VIDEO/AUDIO cable to the CONNECT CAMCORDER TO TV OR VCR camcorder’s AV OUT connector. Connect as shown in the illustration ●...

  • Page 58: Advanced Connections

    PLAYBACK Advanced Connections Connection To A Personal Computer This camcorder can transfer still images to a personal computer by using the provided software when connected as shown in the illustration below. It is also possible to transfer still images to a personal compu- ter with a DV connector-equipped capture board installed.
  • Page 59 Connection To A Video Unit Equipped With A DV Connector Connection to the Digital Printer GV-DT1 (optional) allows you to print out the images or to transfer the captured image from the Digital Printer to a personal computer. It is also possible to copy recorded scenes from the camcorder onto another video unit equipped with a DV connector.

  • Page 60: Editing

    EDITING Dubbing You can copy recorded scenes from the camcorder onto a videotape. Refer to your VCR’s instruction manual for details. Remote sensor Play button (Recording deck) Stop button Lock button DISPLAY ON/OFF button PLAY STOP RM-V711U Power Dial (provided) NOTES: MAKE CONNECTIONS ●...

  • Page 61: Digital Dubbing

    Digital Dubbing It is also possible to copy recorded scenes from the camcorder onto other video unit equipped with a DV connector. Since digital signal is sent, there is little if any image or sound deterioration. RM-V711U (provided) PLAY STOP To DV To DV OUT connector...

  • Page 62: Brand Setting

    9 5 Editing. 1 1 IMPORTANT 9 4 BLAUPUNKT 9 1 Although the MBR is compatible with JVC VCRs 9 7 9 6 FERGUSON and those of many other makers, it may not work 9 8 1 2 with yours or may offer limited functions.

  • Page 63: Random Assemble Editing

    VCR’s remote pause terminal using an editing cable. •Connections should be made while the power ● If you use a JVC VCR not equipped with a remote is off. Making connections with the power on pause terminal or a non-JVC VCR, connect the can lead to electrical shock or malfunctions.
  • Page 64 EDITING (Cont.) Program MODE – – – – : – – ~ Remote sensor RM-V711U (provided) TIME CODE – – : – – TOTAL 0 0 : 0 0 FADE/WIPE Random Assemble PLAY EFFECT Editing Menu R.A.EDIT ON/OFF Power Dial EDIT IN/OUT NOTES: SET EDIT-IN POINT...
  • Page 65 Remote Sensor Rewind button Pause button Stop button START/STOP button MODE 0 0 : 2 5 ~ 0 2 : 0 5 – – 0 7 : 1 8 ~ 0 8 : 3 1 – – 3 – – 0 3 : 3 3 ~ 0 5 : 5 3 RM-V711U 0 9 : 3 0 ~ 1 3 : 1 5 1 5 : 5 5 ~ 1 6 : 2 0 –...

  • Page 66: For More Accurate Editing

    EDITING (Cont.) For More Accurate Editing Some VCRs make the transition from Record-Standby to Record mode faster than others. Even if you begin editing for the camcorder and the VCR at exactly the same time, you may lose scenes you wanted, or find that you’ve recorded scenes you didn’t want.
  • Page 67 Adjustment of VCR‘s against Camcorder Timing Display 48kHz MODE FULL SOUND 32kHz MODE SOUND1 SYNCHRO 0 . 0 DISPLAY TIMECODE (Recording deck) Playback Menu Lock button 48kHz MODE FULL SOUND 32kHz MODE SOUND1 MENU button Select Dial SYNCHRO 0 . 0 DISPLAY TIMECODE Power Dial...

  • Page 68: Audio Dubbing

    EDITING (Cont.) Audio Dubbing The audio track can be customized only when recorded on the 32 kHz mode ( pg. 35). NOTES: ● Audio Dubbing is not possible on a tape recorded at 48 kHz, on a tape recorded in the LP mode or on a blank portion of a tape.

  • Page 69: Insert Editing

    Insert Editing You can record a new scene into a previously recorded tape, replacing a section of the original recording with minimal picture distortion at the in- and out-points. The original audio remains unchanged. NOTES: ● Insert Editing is not possible on a tape recorded in the LP mode or on a blank portion of a tape. ●...

  • Page 70: Troubleshooting

    TROUBLESHOOTING If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION 1. No power is supplied. 1. •The power is not connected 1. • Connect the AC Adapter properly.
  • Page 71 SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION 10. The tape is moving, but 10. •Your TV has AV input 10. •Set the TV to the mode or there’s no picture. terminals, but is not set to channel appropriate for its VIDEO mode. video playback ( pg.
  • Page 72 TROUBLESHOOTING (Cont.) SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION 18. The Picture Wipe and 18. •The last selected editing 18. • Select Picture Wipe or Dissolve functions don’t scene is ending. Dissolve before beginning work. •At the end of the last recording. The effects are selected scene for editing, then automatically the Power Dial was set to...
  • Page 73 •When the LCD monitor's fluorescent light reaches the end of its service life, images on the LCD monitor become dark. Consult your nearest JVC dealer. 31. The rear of the LCD 31. •The light used to illuminate 31. •Close the LCD monitor to monitor is hot.
  • Page 74 If the indication remains even though you repeat the above two or three times, please consult your nearest JVC dealer. 40. The charge indicator on 40. •The temperature of the 40. • To protect the battery, it is the AC Power Adapter/...

  • Page 75: After Use

    AFTER USE Cleaning The Camcorder Battery cover Open switch (BATTERY) Battery pack Hook Viewfinder eject knob LCD monitor REMOVE POWER SUPPLY PUSH VIEWFINDER BACK IN Remove the battery pack or disconnect the AC Return the viewfinder eject knob to its original position and push the viewfinder back in.

  • Page 76: Controls, Indications And Connectors

    CONTROLS, INDICATIONS AND CONNECTORS Connector cover Pull this out to open. & ) q w Downloaded from: https://www.usersmanualguide.com/...
  • Page 77 Zoom switch or volume switch (VOL.) Progressive Dial (PROGRESSIVE) pg. 24, 50) pg. 28, 44) Adjusts zoom during recording or the sound Turn for Progressive Video Recording or Pro volume during playback. Snapshot Recording. Grip strap ( pg. 14) Progressive Button ( pg.
  • Page 78 CONTROLS, INDICATIONS AND CONNECTORS (Cont.) Bottom of the camcorder Connector cover Pull this out to open. LCD monitor ( pg. 22) DC IN jack ( pg. 10) The image appears during recording or play- The DC cord of an AC Power Adapter can be back.

  • Page 79: Lcd Monitor/Viewfinder Indications During Recording

    5 6* 7* MANUAL LP 35 min 1/250 PAUSE PHOTO & MODE SOUND 32kHz 25 . 12 . 98 17 : 46 LCD Monitor/Viewfinder Indications During Recording FUNCTION Displays the operation mode position. pg. 17) Appears when taking a Pro Snapshot. pg.

  • Page 80: Lcd Monitor Indications During Playback

    CONTROLS, INDICATIONS AND CONNECTORS (Cont.) 32kHz SOUND1 25 . 12 . 98 TC 01 : 28 : 15 17 : 46 – – – – – – – – – – VOLUME LCD Monitor/Viewfinder Indications During Playback FUNCTION Displays the sound mode. pg.

  • Page 81: Warning Indications

    Press the reset button after removing the power supply (battery, etc.), and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer. pg. 74) Downloaded from:...

  • Page 82: Cautions

    CAUTIONS Battery Packs Cassettes To properly use and store your cassettes, be sure to The supplied battery pack is a read the following cautions: lithium-ion battery. Before using the supplied battery pack 1. During use . . . or an optional battery pack, be ..
  • Page 83 If malfunctioning occurs, stop using the unit the video heads may result. After the camcorder immediately and consult your local JVC dealer. plays back for about 20 seconds, it stops automatically. Also refer to the Cleaning Cassette’s instructions.

  • Page 84: Specifications

    SPECIFICATIONS CAMCORDER General Power : DC 6.3 V (using AC Adapter) DC 7.2 V (using Battery) Power consumption : 6.3 W (viewfinder on), 8.2 W (LCD monitor on) Format : DV Format (SD mode) Signal format : PAL Standard Video signal recording format : Digital Component Recording Cassette : MINI DV Cassette...

  • Page 85: Glossary Of Terms

    GLOSSARY OF TERMS Iris Works like the pupil of the human eye. In a well-lit environment, the human pupil contracts to keep too much light from entering. In low lighting, the pupil dilates to allow more light in. Colour temperature A measurement in Kelvin degrees which indicates the colour contents of a light source;...

  • Page 86: Index

    INDEX Animation ..........pg. 35 Motor Drive Mode ........pg. 29 Audio Dubbing ........pg. 68 Auto Focus ..........pg. 45 On-Screen Menus ..... pg. 31 – 35, 53 pg. 19 Auto Shut off ........... Operation Mode ........pg. 17 Battery ............
