- Page 1 TF2200RW Product & Installation Manual TF2200RW – Off White Electric Radiant Heater With Remote www.heatstrip.com.au Ph: 03 9562 3455 E: sales@thermofilm.com.au...
- Page 2 March 2023 V2 Electric heater for protected undercover outdoor and indoor areas such as alfresco areas, verandas, patios, garages, bathrooms etc. Features & Benefits • 2200 Watts • Gentle heat output, slimline design. • LED control panel with easy On/Off functionality, 3 heat levels and adjustable 0-24 hour timer. •...
- Page 3 HEATSTRIP® TF2200RW TF2200RW is a custom designed and manufactured heater. It has been designed for ease of use and to provide low running cost. It provides 3 levels of temperature control, Adjustable set timer option from 0-24 hours with the touch of a button. When the heater is plugged in or hardwired , press “power”...
- Page 4 Remote Control Operation Receiver is located on the heater. Signal Transmitter LED / Control Panel • To use the remote controller, aim the transmitter to the heater. A line of sight transmission is required for the unit to function. • The controller does not have a protection rating.
-
Page 5: Installation Requirements
Installation Requirements The ideal mounting position for the heater is on the ceiling directly above the area to be heated. If this is not possible, the heater can be mounted on a wall and angled downwards. In this situation, ensure the mounting height is in the range of 2.1m to 2.4m and the table is within 1.0m of the wall. -
Page 6: Installation Location
Installation location — the diagrams below provide the minimum recommended clearances in (mm). WARNING: This heater is not equipped with a device to control the room temperature. Do not use this heater in small leaving the room on their own, unless constant supervision is rooms when they are occupied by persons not capable of provided. -
Page 7: Standard Mounting Brackets
Standard Mounting Brackets The HEATSTRIP® TF2200RB comes with a pair of standard mounting brackets. These adjustable brackets allow direct ceiling or wall mount, and come with preset angle options of parallel, 22.5˚ ˚ and 45˚ . “X” MODEL MINIMUM DISTANCE (mm) TF2200RW 1000 PACKAGED... - Page 8 The TF2200RW has undergone extensive testing both in laboratory conditions, in Thermofilm’s manufacturing fa- cility and field trials in Australia and overseas. It is this testing that gives the purchaser the confidence of a high quality product.
-
Page 9: Warranty Terms And Conditions
Thermofilm) is the sole responsibility of the customer. • All products are inspected and tested before despatch and are at the risk of the purchaser after the shipment from the Thermofilm factory, if not delivered by Thermofilm to destination. •...
