- Page 1 Product Manual ® H E AT S T R I P N a n o E l e c t r i c H e a t e r M o d e l N o . T H N 2 0 0 0...
-
Page 2: Features And Benefits
Innovative, Infra-red Electric Heating Technology Features & Benefits High Output radiant heat ® HEATSTRIP Nano electric radiant heaters produce radiant heat that travels through the air directly to people and surfaces below – similar to the heat rays emitted by the Sun. Radiant heating is the only viable option for outdoor or tough indoor sites. Radiant heat performance –... - Page 3 Specifications - Australia LEAD POWER CURRENT DIMENSIONS WEIGHT MODEL LENGTH PLUG (WATTS) (AMPS) (mm) (Kg) (mm) THN2000 2000 900 x 130 x 89.5 2000 MODEL HEATER TYPE Electric radiant, infra-red overheat heater with carbon filament element. OUTPUT 800 / 1200 / 1600 / 2000 Watts POWER 230-240 Volts Nominal at 50—60 Hertz, Single Phase CONNECTION...
- Page 4 Spot heating principle In most outdoor or difficult-to-heat indoor applications, there are 2 methods when looking at the quantity of heaters required. Option 1 is to comfort heat the entire area based on the total dimensions of the space, regardless of whether the entire area is being fully occupied or not.
-
Page 5: Selection Guide
Selection guide ® General recommendations for HEATSTRIP Nano: Ideal mounting height: 2.1m to 2.3m, and the maximum 2.5m outdoors and 2.7m indoors. • Ideal mounting location: ceiling mounted, directly above area to be heated (eg. above a table) Can only be wall mounted and angled downwards. For wall mounting applications, the heating area and radiant footprint is reduced. -
Page 6: Installation Requirements
Installation Requirements ® The ideal mounting position for the HEATSTRIP Nano is on the ceiling, directly above the area to be heated. If this is not ® possible, HEATSTRIP Nano can be mounted on a wall and angled downwards. In this situation, ensure the mounting height is in the range of 2.1m to 2.3m. -
Page 7: Installation Location
Installation location — the below diagrams confirm the minimum recommended clearances. Angled Wall Installation Surface Below Lights, fans, and sprinklers Heater must NOT be below heater 1000mm Ceiling Installation Surface Below Lights, fans, and sprinklers Heater must NOT be below heater Angled Ceiling Installation... -
Page 8: Standard Mounting Bracket
Standard mounting brackets ® The HEATSTRIP Nano comes with a pair of standard mounting brackets. These adjustable brackets allow direct ceiling or wall mount, and come with pre-set angle options of parallel, 22.5° and 45°. The flexible standard mounting bracket can be turned 90 degrees to mount onto a beam, it can also be used to suspend with chains. - Page 9 MOUNTING Fix the two mounting brackets to the ceiling or wall in the desired location (refer minimum bracket centre chart). Make sure the method of fixing (bolts or screws) will be more than strong enough to support the weight of the heater, allowing for strong winds and other conditions.
-
Page 10: Remote Control Operation
REMOTE CONTROL OPERATION Remote Control Instructions POWER BUTTON: Turn the heater On/Off. UP BUTTON: Increase timer and heat level. DOWN BUTTON: Decrease timer and heat level. HEAT LEVEL BUTTON: Use to adjust the heat levels(L1-L4). Press the Heat Level button then use the up and down buttons (buttons 2 and 3) to increase or decrease the heating level. -
Page 11: Maintenance
® HEATSTRIP has undergone extensive testing both in laboratory conditions; in Thermofilm’s facility in Melbourne and field trials in Australia and overseas. It has been this testing that gives the purchaser the confidence of a high quality product. Independent laboratory testing has confirmed Thermofilm’s full compliance with Australian and other International Standards. -
Page 12: Warranty Terms And Conditions
This warranty excludes damage to the product or components arising from circumstances outside the control of Thermofilm, including, but not limited to, where the product is not used for intended purpose; where the product has been rectified in any way; incorrect installation; incorrect power supply; damaged caused during delivery; misapplication, misuse, abuse, vandalism, lack of maintenance or accident.
