PCB Piezotronics M1630-03C Installation And Operating Manual
S-type load cell, 200 n rated capacity, 65% static overload protection, 2mv/v output, m6 x 1.0 threads, integrated 3 meter cable with open end, aluminum construction
S-type load cell, 500 n rated capacity, 50% static overload protection, 2mv/v output, m6 x 1.0 threads, integrated 3 meter cable with open end, aluminum construction (12 pages)
Summary of Contents for PCB Piezotronics M1630-03C
Page 1
S-Type Load Cell, 200 N rated capacity, 65% static overload protection, 2mV/V output, M6 x 1.0 threads, integrated 3 meter cable with open end, aluminum construction Installation and Operating Manual For assistance with the operation of this product, contact the PCB Piezotronics, Inc. Toll-free: 716-684-0001 24-hour SensorLine: 716-684-0001 Fax: 716-684-0987 E-mail: info@pcb.com...
Page 2
Assistance is needed to safely operate equipment PCB Piezotronics is an ISO-9001 certified company whose Damage is visible or suspected calibration services are accredited by A2LA to ISO/IEC Equipment fails or malfunctions 17025, with full traceability to SI through N.I.S.T.
Page 3
CAUTION Refers to hazards that could damage the instrument. NOTE Indicates tips, recommendations and important information. The notes simplify processes and contain additional information on particular operating steps. The following symbols may be found on the equipment described in this manual: This symbol on the unit indicates that high voltage may be present.
S-TYPE LOAD CELL OPERATION MANUAL 3.1 Dimensions 1.0 INTRODUCTION S-type load cells manufactured by PCB Load & Torque, Inc. are accurate strain gage sensors used for weighing and force measurement. Their high accuracy makes them ideally suited for critical weighing applications. S-type load cells are typically used to measure tensile loads, however, compression loads can also be measured when compression loads are guided and any resultant extraneous loads are minimized.
S-TYPE LOAD CELL OPERATION MANUAL 5.1 Electrical Drawing / Western Regional Std. The instrument or control system is grounded through its power cord. Ground loops and measuring system wiring may All load cells are wired following the Western Region result in unstable or noisy signals. Standard.
S-TYPE LOAD CELL OPERATION MANUAL 7.1 Resistor Value 6.1.2 Hysteresis S-type load cells have a nominal 2.0 mV/V full scale output. The difference between the ascending and descending For a 350 ohm strain gage bridge the precision shunt resistor measured readings at 40% of full scale is used to calculate the is, 60,000 ohms ±...
S-TYPE LOAD CELL OPERATION MANUAL Yearly calibrations are recommended to ensure that the unit’s Standard calibration certificates list five force points outputs match the factory specifications. ascending and one point descending. Additional data points are available at extra cost upon request. A 60 K ohm (±0.1%) shunt calibration resistor is supplied with each load cell 9.0 TROUBLE SHOOTING calibration.
Page 11
Model Number Revision: D STRAIN GAGE LOAD CELL M1630-03C ECN #: 43825 Performance ENGLISH OPTIONAL VERSIONS Measurement Range 45 lb 200 N Optional versions have identical specifications and accessories as listed for the standard Sensitivity(± 10 %) 2 mV/V 2 mV/V model except where noted below.
Page 12
PCB Load & Torque Inc. claims proprietary rights in REVISIONS the information disclosed hereon. Neither it nor any reproduction thereof will be disclosed to others without DESCRIPTION the written consent of PCB Load and Torque Inc. RELEASED TO DRAFTING 36164 4 CONDUCTOR BLACK SHIELDED CABLE 10.0 FT [3.0 M] LONG TERMINATING IN PIGTAILS...
