Getting started
Congratulations on your purchase of this powerful WIFI temperature sensor. Once the temperature limit is exceeded, the sensor will send
an alarm signal to your smart phone via your home/business WIFI connection. Such signal is selectable as an Alarm Sound + Notification,
Notification Sound + Notification or just a silent Notification. This product works together with your smart phone and internet via WIFI. Please
check that your smart phone is either an Android or IOS (iPhone) and that the latest firmware has been installed. Please also check that your
WIFI router is working properly and that its operating manual confirms that it operates on 2.4 GHz with WPA/WPA2 encryption.
Installing the APP
1
install
1.
Before powering up the Sensor, please install our free 'NEXUSHOME ' APP onto your phone. The APP is available in an IOS version on the
Apple App Store and an Android version on the Google Play Store. Ensure your phone is connected to WIFI to complete account setup.
2.
Once downloaded, click and open the APP. The following message will appear. Please click OK.
3.
Now complete your User Profile by inputting your email address and a 6 digit or longer Password, click the REGISTER button, check your
email and click the link in the email from "Netify" to complete registration.
Setting up your DEVICE
1
connect WiFi
1.
Go to the location in the Building where you eventually wish to install the Sensor. Look at your smart phone and ensure you have a good
and steady WIFI connection there. Now, exit the APP, open SETTINGS on your smart phone and click "Wi-Fi". Check what is showing. If
you just have a main Router, it should be showing its reference name (or SSID). Each Router or Extender has its own unique reference
name or SSID. However, if you have a network with one or more extenders, it may also be showing, underneath, under "Choose a
Network", the SSID of an overlapping Extender, as in the picture 1 above. In this case, check whether you are closest to the main Router or
to an Extender and manually select, if necessary, the alternative closest/strongest SSID. THIS IS VERY IMPORTANT. The Sensor will only
communicate Alarm signals to the WIFI Router or Extender that you are about to "pair" it to so it is essential that you pair it to the closest/
strongest Wi-Fi signal.
2.
Re-Open the APP and click
"ADD DEVICE/WIFI SETTING".
3.
Please select "Wireless" at the bottom right hand side of the Page.
WT08
WIFI TEMPERATURE SENSOR
2
click OK
2
click "Add Device/WiFi Setting"
PROFILE at the bottom of the opening HOME page. This will take you to the APP's SETTINGS Page. Click
Product Specification
•
Built-in WIFI module that sends all alerts to your Smartphone
•
Temperature reading and alarm setting in APP
•
Send alert once temperature is out of range
•
Life-time cloud service provided free of charge
•
Powerful APP for your Smartphone provided free of charge
•
User can create floorplans in the APP showing device location
•
APP records last 30 activations time and date stamped
•
3M double sided tape for permanent fixing included
•
2 x AAA battery, last for six months
•
Blue LED for status indication
•
Schedule up to 4 periods per day when unit is automatically
turned off
3
register
1
3
choose Wireless Pairing
