PCB Piezotronics SM102A05 Installation And Operating Manual page 10

Model Number
102A05
Performance
Measurement Range(for ±5V output)
Useful Overrange(for ± 10V output)
Sensitivity(± 20 %)
Maximum Pressure(step)
Maximum Pressure(Total)
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Acceleration Sensitivity
Temperature Range(Operating)
Temperature Coefficient of Sensitivity
Maximum Flash Temperature
Maximum Vibration
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Electrical Isolation
Physical
Sensing Geometry
Sensing Element
Housing Material 17-4 / 304L Stainless Steel
Thread Adaptor Material 17-4 Stainless Steel
Diaphragm
Sealing
Electrical Connector 10-32 Coaxial Jack
Weight
[3]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
EN GLISH SI
100 psi 690 kPa
200 psi 1,379 kPa
50 mV/psi 7.3 mV/kPa
1 kpsi 6,900 kPa
15,000 psi 103,421 kPa
2 mpsi 0.014 kPa
≥ 250 kHz ≥ 250 kHz
≤ 2.0 µ sec ≤ 2.0 µ sec
0.5 Hz 0.5 Hz
≤ 1.0 % FS ≤ 1.0 % FS
≤ 0.002 psi/g ≤ 0.0014 kPa/(m/s²)
-100 to +275 °F -73 to +135 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
3,000 °F 1,650 °C
2,000 g pk 19,613 m/s² pk
20,000 g pk 196,133 m/s² pk
Positive Positive
≥ 1.0 sec ≥ 1.0 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
< 100 Ohm < 100 Ohm
8 to 14 VDC 8 to 14 VDC
8 8
≥ 10 Ohm ≥ 10 Ohm
Compression Compression
Quartz Quartz
17-4 / 304L Stainless Steel
17-4 Stainless Steel
Invar Invar
Welded Hermetic Welded Hermetic
10-32 Coaxial Jack
0.41 oz 11.6 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1]
- Ablative Coating
CA
M - Metric Mount
Supplied Accessory: Model 065A40 Seal ring 0.435" OD x 0.397" ID x 0.030" thk brass (3) replaces
Model 065A03
N - Negative Output Polarity
- Stainless Steel Diaphragm
S
[2]
Diaphragm
- Water Resistant Cable
W
N OTES:
[1]For +10 volt output, minimum 24 VDC supply voltage required. Negative 10 volt output may be
limited by output bias.
[2]Zero-based, least-squares, straight line method.
[3]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 065A03 Seal ring 0.435" OD x 0.377" ID x 0.030" thk brass (3)
Entered: LK Engineer: NJL
Date: 07/13/2020 Date: 07/13/2020 Date: 07/13/2020 Date: 07/13/2020 5960
3425 Walden Avenue, Depew, NY 14043
Revision: G
ECN #: 50860
OPTION AL VERSION S
316L Stainless Steel 316L Stainless Steel
Sales: RWM Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
