Set Up and User Guide
SM-338H-B RFID Locker Lock
Thank you for purchasing the SM-338H-B RFID Locker Lock. Please keep this short user
guide handy so that you can understand all the functions of this product.
Important Note: These locks can be installed on a door with a thickness of ≥15mm.These
locks are not recommended for use on metal lockers unless a 1-2 cm metal free area is
created around the round cover plate. This should be tested prior to ordering in volume to
ensure that the lock can function without metal interference.
What comes in the box?
Each lock is packaged in its own box that includes the follow parts:
1 x SM-338H-B RFID Lock Housing (Installed Inside Locker Door)
2 x Phillips wood screws to secure the housing
1 x Round Reader Module Cover Plate (Installed Outside Locker Door)
2 x Multi-head screws to secure the cover plate to housing
1 x Latch Stopper
3 x Phillips wood screws to secure the housing
1 x Screw for Battery Cover
What is not included?
RFID Cards: You will need 2-6 pcs RFID Card for initial set up and ongoing lock
management. These can be purchased from SYNOMETRIX at time of order.
RFID Tags: No matter what type of locker lock system you purchase, your guests will
need an RFID wristband, key fob or card to open the locker. These can be purchased
from SYNOMETRIX at time of order.
Overview - Setting Up Your Locker System
There are two types of systems available for the SM-338H-B RFID Lock:
•
Standalone Fixed System: Numbered RFID wristbands are coded to operate on
a specific numbered locker. Guest is assigned a numbered locker and issued an
RFID card, wristband or key fob that opens/closes it.
•
Software Managed System: Guest is issued an RFID card, wristband or key fob
that is assigned to an available locker using a central software suite.
Advertisement
Table of Contents
Related Manuals for Synotag SM-338H-B
Summary of Contents for Synotag SM-338H-B
- Page 1 Set Up and User Guide SM-338H-B RFID Locker Lock Thank you for purchasing the SM-338H-B RFID Locker Lock. Please keep this short user guide handy so that you can understand all the functions of this product. Important Note: These locks can be installed on a door with a thickness of ≥15mm.These locks are not recommended for use on metal lockers unless a 1-2 cm metal free area is created around the round cover plate.
- Page 2 Operating Instructions for SM-338H-B RFID Locker Lock No matter what kind of system you install, SM-338H-B RFID Locker Locks are easy to set up and manage. Before you begin an installation, here are a few things to consider: 1. Locker Numbering: Each locker door should have a number on its outside that is visible to the guest.
- Page 3 Operating Instructions for SM-338H-B RFID Locker Lock Once the lock is properly installed, follow the instructions below to set up the Owner Card, Master Card and Guest Tags. Owner Card (Maximum 1pc) a) Program Owner Card: After initialization, scan the first RFID card near the inductive area.
- Page 4 Operating Instructions for SM-338H-B RFID Locker Lock flashing scan an RFID card and that programmed card is now a master card. During the red and green light flashing period up to 5 cards can be scanned as master cards. b) Delete Some Master Cards: Scan the owner card near the inductive area, the music sounds and the red and green lights will flash for 6 seconds.
- Page 5 Operating Instructions for SM-338H-B RFID Locker Lock 4. Lock Functions a) Light Indication in Locked Status: When the lock is locked a red light flashes every 6 seconds to indicate the lock is in use. b) Illegal Card Alarm: Scan any unauthorized card 6 times and the lock will sound an alarm for 20 seconds.
