Set Up and User Guide
SM-340H RFID Locker Lock
Thank you for purchasing the SM-340H RFID Locker Lock. Please keep this short user
guide handy so that you can understand all the functions of this product.
Important Note: These locks can be installed on a door with a thickness of ≥11.5 mm.

What comes in the box?

Each lock is packaged in its own box that includes the follow parts:
1 x SM-340H RFID Lock Housing (Installed Inside Locker Door)
2 x Phillips wood screws to secure the housing
1 x SM-340H Reader (Installed Outside Locker Door)
2 x Multi-head screws to secure the cover plate to housing
1 x Latch Stopper
3 x Phillips wood screws to secure the housing
1 x Screw for Battery Cover

What is not included?

RFID Cards: You will need 2-6 pcs RFID Card for initial set up and ongoing lock
management. These can be purchased from SYNOMETRIX at time of order.
RFID Tags: No matter what type of locker lock system you purchase, your guests will
need an RFID wristband, key fob or card to open the locker. These can be purchased
from SYNOMETRIX at time of order.

Overview - Setting Up Your Locker System

There are two types of systems available for the SM-340H RFID Lock:
•
Standalone Fixed System: Numbered RFID wristbands are coded to operate on
a specific numbered locker. Guest is assigned a numbered locker and issued an
RFID card, wristband or key fob that opens/closes it.
•
Software Managed System: Guest is issued an RFID card, wristband or key fob
that is assigned to an available locker using a central software suite.
No matter what kind of system you install, SM-340H RFID Locker Locks are easy to set
up and manage. Before you begin an installation, here are a few things to consider:
1. Locker Numbering: Each locker door should have a number on its outside that is
visible to the guest. This normally comes in the form of an engraved plastic or metal
number plate or handle that is affixed to the outside of the locker door.
