User Manual
FMTX100M
FM Transmitter
WARNING!
This Transmitter is capable of generating extremely high RF
potential. Touching internal parts, or the connected antenna
system, will cause serious RF burns. Antenna systems should be
installed such that exposure by any person to RF fields cannot
exceed safe limits. The permitted limits vary from country to
country. Expert advice should be sought about the safe
installation of this transmission system.
RISK OF FIRE!
RF (Radio Frequency) energy could cause ignition of combustible
surfaces during fault conditions. Installation should be left to
qualified personnel. RF can cause burns to skin. Ensure antenna
systems and feeder cables are not situated near, or could fall
onto, any combustible surface.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMTX100M and is the answer not in the manual?

Questions and answers

Related Manuals for lucoro FMTX100M

Summary of Contents for lucoro FMTX100M

  • Page 1 User Manual FMTX100M FM Transmitter WARNING! This Transmitter is capable of generating extremely high RF potential. Touching internal parts, or the connected antenna system, will cause serious RF burns. Antenna systems should be installed such that exposure by any person to RF fields cannot exceed safe limits.
  • Page 2 WARNING! Never operate this device without a suitable 50 ohm load connected to the RF OUTPUT socket, or without a suitably installed and matched antenna system connected. Although the output of this transmitter is protected against antenna load faults, MIS-OPERATION MAY RESULT IN DAMAGE NOT COVERED BY ANY WARRANTY.

  • Page 3: Before Operating

    The FMTX100M is a reliable and compact 125W FM Broadcast Transmitter operating from 87.5MHz to 108MHz At the heart of the FMTX100M is a high quality PLL modulator, and the RF Power Amplifier uses the latest high-gain Enhancement Mode MOSFET device, achieving new levels of efficiency and reliability.
  • Page 4 equipment at the transmission site at all times. Display posters detailing first aid treatment and treatment for electrical shock, along with telephone numbers for contacting the emergency services in the event of personal injury. Ensure antenna system lightning strike protection is in place. To reduce the risk of electrical shock, do not remove the cover, or any screws.

  • Page 5: Controls And Connectors

    Controls and Connectors 1. SYSTEM Status LED. Green indicates correct operation, red indicates a system error requiring urgent further investigation. 2. DOWN Push-button. Press this control to navigate the LCD menu. 3. ENTER Push-button. Press this control to navigate the LCD menu. 4.

  • Page 6: Installation

    9. REMOTE 9-pin D-sub Female. Remote control and monitor inputs and outputs are available on this connector: Pin 1. Reflected Power Alarm. TTL logic low during normal operation. Floats high to indicate a high level of reflected power (critical antenna mis-match) has been detected. Pin 2.

  • Page 7: Operation

    RF Power (using the rear panel RF ADJ control) to the desired level, not exceeding 100W. Operation The FMTX100M is designed for continuous reliable transmission, however the fans must be periodically checked for correct operation and free airflow. The front panel display shows the transmission frequency, forward...
  • Page 8 Correct operation is confirmed by a front panel green STATUS LED. Should this turn red, the transmission system may shut down its RF output and will, in any case, require URGENT attention. The LCD display shows all main parameters so no further menus are provided or required (except frequency setting detailed above).
  • Page 10 EC Declaration of Conformity to R&TTE Directive 1999/5/EC Lucoro Broadcast Clay Pit Lane Roecliffe York YO51 9FS hereby take sole responsibility to confirm that the product: FMTX100, FMTX250 (and versions thereof with M and RBRX suffix) which this declaration refers to, conforms to all applicable...

  • Page 11: Technical Specifications

    Technical Specifications Frequency range 87.5 to 108.00MHz Frequency stability Better than ±200Hz Output power 30 - 125W Harmonic & spurious output -75dBc typical AM Noise <0.5% @ ±40kHz deviation <0.15%@ ±75KHz deviation RF output connector ‘N’ type (F) Monitoring: BNC (F) -40dB 50 ohms BNC (F) 1V P-P 10K ohms MPX: MPX Input Level...
  • Page 12 No part of this document may be reproduced or transmitted, in any form, by any means, without prior written consent of the Lucoro Broadcast.
  • Page 13 Lucoro Broadcast shall not be liable for any direct, indirect, incidental, consequential or other damage or loss alleged in connection with the supply or use of this product. The information contained in this document is subject to change without notice. Lucoro Broadcast makes no warranty of any kind with respect to this information.
