- Page 1 3G WiFi Router Module name: Wifi-TW520R HSDPA/HSUPA Router USER MANUAL Last Update Time: 2009-10-29 TeleWins ( HK).Co., Ltd. Bldy1, Xiandaichenghuating, Chuangye Road Nanshan District, Shenzhen 518054, P.R.China Tel.: +86-755-86217635 Fax: +86-755-86229325...
-
Page 2: Table Of Contents
TeleWins(HK).,Co.LTD Table of Contents 1. PRODUCT OVERVIEW............................4 1.1 I NTRODUCTION ............................... 4 1.2 A PPEARANCE ..............................4 1.3 I NDICATORS ..............................4 1.4 I NTERFACES ..............................5 1.5 A PPLICATION ..............................5 2. INSTALLING THE ROUTER..........................6 2.1 I... - Page 3 TeleWins(HK).,Co.LTD 3.9.3 Firmware Upgrade........................26 3.9.4 Reboot.............................. 26 3.9.5 Reset to Default ..........................26 3.9.6 Password ............................27 4. TECHNICAL SPECIFICATIONS........................28 5. SERVICE AFTER SALE ........................... 29...
-
Page 4: Product Overview
1.1 Introduction Thank you for purchasing the 3G WiFi Router (WIF I-TW520R HSDPA/HSUPA) of TeleWins(HK). Co., Ltd. The WIFI-H200 is a new kind of wireless router that has built-in 3G modem, which lets you create your own WiFi hotspot via 3G (HSDPA/HSUPA) network at families, small offices, home offices (SOHO), vehicles, and anywhere. -
Page 5: Interfaces
TeleWins(HK).,Co.LTD Status Description Green The power supply is normal. Flickering The router is booting or upgrading. Power Indicator The power supply has failure. The router is turned off. 3G Connection The 3G connection is established. Indicator The 3G connection is not established. -
Page 6: Installing The Router
TeleWins(HK).,Co.LTD 2. Installing the Router 2.1 Installation Steps 1) Locate the router as per the installation environment requirement specified in Section 2.2. If you want to use the WiFi function, you’d better choose the place which has less obstruction between the router and WiFi-enabled devices (e.g. -
Page 7: Configuration Via Web Browser
TeleWins(HK).,Co.LTD 3. Configuration via Web Browser 3.1 Login 1) Open the web browser (Microsoft IE 5.0 or later / Netscape Navigator 6.0 or later) on your PC that is connected to the router. In the Address bar, type “192.168.16.1” (the default IP address of the router) and then press “Enter”, the login window as shown in the figure below will appear to let... -
Page 8: System Status
TeleWins(HK).,Co.LTD 3.2 System Status In the web configuration interface, click System Status in the left menu to check the current status and settings of the router as shown in below figure. All information is read-only. The description of each field is listed below. -
Page 9: Dynamic Ip
TeleWins(HK).,Co.LTD or 3G. If you need the router to access the Internet via 3G network (you have inserted SIM card inside the router), please choose the option of 3G. If you need the router to access the Internet via a cable/DSL modem (you have connected a cable/DSL modem to the router), please make the right choice as per the following guideline: If no any login parameters (e.g. -
Page 10: Static Ip
TeleWins(HK).,Co.LTD Fields Description Maximum Transmission Unit. The normal value for most Ethernet networks is 1500 bytes. For some ISPs you may need to enter a lower value. But this is rarely required and shall not be done unless you are sure that it’s necessary for your ISP connection. -
Page 11: Ppp Over Ethernet
TeleWins(HK).,Co.LTD 3) PPP over Ethernet If you choose PPP over Ethernet, you shall have the login username and password offered by your ISP. The configuration interface will show as below. You shall enter the values as per the following description and then click the Save Settings button. -
Page 12: Mac Clone
TeleWins(HK).,Co.LTD Fields Description Access Point Name. The name used to identify a UMTS/GPRS service in the global 3G/GSM network. Some 3G operators adopt “internet” as their APN. Please consult your local 3G ISP to get the correct APN and enter it in this field. -
Page 13: Lan Setting
TeleWins(HK).,Co.LTD Fields Description Use the device’s MAC Address Choose this to maintain the MAC address of the router, if you have registered the router’s MAC address or your ISP doesn’t require registering MAC address. Use this PC’s MAC Address Choose this to change the MAC address of the router to that of the PC which is connecting to the router, if you have registered the PC’s MAC address. -
Page 14: Dhcp Setting
TeleWins(HK).,Co.LTD Fields Description IP Address Specify the IP address of LAN Port of the router in dotted-decimal notation. (The default setting is 192.168.16.1.) Subnet Mask An address code that determines the size of the LAN. Usually specify it as 255.255.255.0. -
Page 15: Wlan Setting
TeleWins(HK).,Co.LTD the IP parameters of each DHCP client (i.e. the devices in your LAN). The status interface will show as below. Fields Description IP Address The IP address that is assigned to the DHCP client. Host The host name of the DHCP client. -
Page 16: Security
TeleWins(HK).,Co.LTD Wireless SSID Specify the name of W iFi hotspot that can be recognized by your WiFi-enabled devices. The value can include up to 32 characters and is case-sensitive. Wireless Channel This field determ ines what channel (operating frequency) will be used by the WiFi module of router. -
Page 17: Advanced Setting
TeleWins(HK).,Co.LTD speed is sacrificed at higher bit levels. Default KEY ID Select which of the 4 keys below will be used for the encryption. The key will be required when your WiFi-enabled device is connecting to the router. WEP KEY 1 ~ WEP KEY 4 After you specify the Default KEY ID, you shall choose the key format (“HEX”... -
Page 18: Security
TeleWins(HK).,Co.LTD protocol invokes RTS/CTS flow control. This field shall remain at the default setti ng of 2347 (bytes). Should you encounter inconsistent data flow, only minor modifications are recommended. Beacon Period This field specif ies the interval between beacon packets. A beacon is a packet broadcast by the router to synchronize the wireless network. -
Page 19: Url Filter
TeleWins(HK).,Co.LTD Fields Description Firewall Choose to switch on or off the general SPI firewall of the router. Block the ICMP Packet If you check this, you can prevent your network from being “pinged” from WAN or detected, by other Internet users. This function also reinforces your network security by hiding your network ports. -
Page 20: Mac Filter
TeleWins(HK).,Co.LTD Fields Description URL Filter Choose to enable or disable the URL filter. Filter Mode This field defines the global policy for the URL filtering section. - Only Deny: allow everything and deny only the URLs in the below list;... -
Page 21: Acl Setting
TeleWins(HK).,Co.LTD MAC Filter Choose to enable or disable the MAC filter. MAC Address Enter the appropriate MAC addresses into the fields. The MAC address shall be entered in this format: xx-xx-xx-xx-xx-xx (where x is any hexadecimal digit), for example, 00-0E-BE-00-B0-00-0B. -
Page 22: Forwarding
TeleWins(HK).,Co.LTD the traffic relative to the above IP addresses. Dest Port Range Choose the range of web ports to allow or deny outgoing traffic to these destination ports. Choose the working days for the ACL. Time Enter the working time for the ACL. -
Page 23: Dmz
TeleWins(HK).,Co.LTD TeleWins(HK).,Co.LTD forwarding in your LAN is defined as a service port, and all outside requests from the Internet to this service port will be redirected to the PC/device specified by the server IP address. Please note that, any PC/device which is being forwarded to must have a static IP address assigned to it because its IP address may change when using the DHCP function. -
Page 24: Routing Setting
TeleWins(HK).,Co.LTD Please note that, the PC/device used for DMZ host must have a static IP address assigned to it because its IP address may change when using the DHCP function. The configuration interface will show as below. You shall enter the values as per the following description and then click the Save Settings button. -
Page 25: System Tools
TeleWins(HK).,Co.LTD 3.9 System Tools In the web configuration interface, click System Tools in the left menu to check the current list of static routes in the router. There are 6 sub-menus: System Time, Backup Setting, Firmware Upgrade, Reboot to Default, and Password. -
Page 26: Firmware Upgrade
TeleWins(HK).,Co.LTD Restore Button Click the Browse button to select the backup file which you want to restore then click the Restore button. 3.9.3 Firmware Upgrade In the web configuration interface, click System Tools -> Firmware Upgrade in the left menu to upgrade your router with the latest version of firmware to keep your router up-to-date. -
Page 27: Password
TeleWins(HK).,Co.LTD Choose Yes and click the Save Settings button to reset all configurations to their default values, which include: Default user name: admin; Default password: admin; Default IP address: 192.168.16.1; Default subnet mask: 255.255.255.0; 3.9.6 Password In the web configuration interface, click System Tools -> Password in the left menu to change the default password to login the router. -
Page 28: Technical Specifications
TeleWins(HK).,Co.LTD 4. Technical Specifications Specifications Tri-band HSDPA/UMTS 850/1900/2100 MHz 3GPP R5 Supported Network/Technology Quad-band GSM EDGE/GPRS 850/900/1800/1900 MHz 3GPP R99 Data Speed Download: 7.2Mbps / Upload: 2Mbps • Power interface: AC220V±15% to DC 12V/1A • LAN and WAN interface: 2 RJ45 ports •... -
Page 29: Service After Sale
Your satisfaction is our priority. Offering a quick and effective technical support, we always put the customer first. Please don’t hesitate to contact us by the following ways if you have any questions. TeleWins( HK).Co., Ltd. Bldy1, Xiandaichenghuating, Chuangye Road Nanshan District, Shenzhen 518054, P.R.China Tel.: +86-755-86217635...
