Intelligent Fire Integrator™
NION-2C8M
Installation & Operation Manual
A1
Document 53346
5/5/09
Rev:
P/N: 53346:A1
ECN: 09-347

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NION-2C8M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Johnson Controls NION-2C8M

  • Page 1 Intelligent Fire Integrator™ NION-2C8M Installation & Operation Manual Document 53346 5/5/09 Rev: P/N: 53346:A1 ECN: 09-347...
  • Page 2 National and/or local fire codes and Smoke detectors cannot be expected to provide adequate warning of should be performed by authorized professional fire alarm installers fires caused by arson, children playing with matches (especially in NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 3 Microsoft Corporation. is a registered trademark of GE Plastics, a subsidiary of General Electric Company. ©2009 by Honeywell International Inc. All rights reserved. Unauthorized use of this document is strictly prohibited NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 4 Manual page number • Your comment Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 5: Table Of Contents

    3.5.2: Rules for Mode Change Commands....................28 3.5.3: Special Operational Scenarios - Inputs....................29 3.5.4: Rules for Output State Changes......................30 3.5.5: Special Operational Scenarios - Outputs ...................30 3.5.6: Reset Conditions..........................30 Index............................31 NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 6 Table of Contents NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 7: Section 1 About This Nion

    Burglar Alarm Units and Systems, Fifth Edition Underwriters Laboratories Canada • CAN/ULC-S524-06—Standard for the Installation of Fire Alarm Systems, Fifth Edition • CAN/ULC-S561-03—Installation and Services for Fire Signal Receiving Centres and Systems, First Edition NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 8: Environmental Requirements

    A copy of this manual was shipped with the equipment and is also available from the manufacturer. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 9: Section 2 Description And Installation

    Section 2 Description and Installation 2.1 NION-2C8M Description The NION-2C8M (2 Control, 8 Monitor) is a discrete input/output interface used on the network. The NION provides a gateway to the network for equipment and panels that have dry contacts. It allows conventional panels and equipment to operate on the same network as equipment with an EIA-232 output.
  • Page 10: Nion-2C8M Motherboard Descriptions

    Transformer coupled network connection using SMX style plug-in network transceiver modules. • Transient protection to 2400V on all terminals. • Standard wall mount enclosure (JNISCAB-1 or CHS-4L with CAB-3/4 series enclosure). NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 11: 2: Nion-2C8M Led Descriptions

    JNISCAB-1 NION Enclosure Installation Description and Installation 2.2.2 NION-2C8M LED Descriptions LEDs on the front panel of the NION-2C8M provide information about module operation. The table below explains the possible conditions. NOTE: Refer to Table 2.1 for the position of each of the LEDs listed below.
  • Page 12 When using a chassis in conjunction with a CAB-3/4 series cabinet, DO NOT use the CHS-4 chassis. For chassis mounting, this NION requires the CHS-4L. Use of the CHS-4 can cause a circuit short on this NION motherboard resulting in possible damage. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 13 Standoffs attached Figure 2.3 NION Mounting Stud Locations NOTE: This enclosure must contain power limited wiring only. CAUTION: Electrostatic Discharge Always observe ESD protection procedures when handling the NION motherboard. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 14: Nion Hardware Connections

    Always remove power from any NION before making any changes to switch settings, when removing or installing; option modules, SMX network modules and software upgrade chips, or damage may result. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 15 200 nodes. A maximum load of 30 ohms on each leg of the Echelon wire network is permitted. Header Connection Bus Termination Electrical Termination Jumper Free Termination Data A Data B Figure 2.4 FTXC Network Transceiver Board Layout NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 16 Continuous link monitoring – flags a marginal link signal problem before failure. NOTE: The use of a 4WRMB (4-Way Repeater Motherboard) with a DFXC Fiber Optic Network Transceiver is not supported. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 17 FOXC Fiber Optic Transceiver DFXC Fiber Optic Transceiver Header Header Connection Connection ST Style Tx Connection ST Style Rx Connection ST Style Connection Figure 2.5 FOXC and DFXC Fiber Optic Transceivers Board Layout NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 18: Nion Power And Serial Data Connection

    SMX network modules and software upgrade chips, or damage may result. WARNING: NION Power Wiring Panel power connectors that are used to provide power for a NION must be made to the panel’s non-resettable connector. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 19: 2: Serial Data Connections

    NOTE: Each normally open input circuit requires a 10k EOL resistor installed in parallel with the contact. Normally closed inputs are not supervised and cannot be used for fire applications. This diagram is also printed on the circuit board next to the LEDs. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 20 NOTE: Input and output lines should not exceed 2000 feet. Output Wiring Connections The NION-2C8M provides two SPDT relay outputs. The relays are rated at 5A @ 30VDC. They can be wired for normally open or normally closed operation. All rated loads are resistive.
  • Page 21: Software Replacement/Upgrade Information

    Always remove power from the NION before making any changes to switch settings and removing or installing option modules, SMX network modules and software upgrade chips, or damage may result. Always observe ESD protection procedures. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 22 Description and Installation Software Replacement/Upgrade Information NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 23: Section 3 Nion-2C8M Configuration

    Section 3 NION-2C8M Configuration 3.1 About NION-2C8M Configuration In order to utilize all features available with the NION-2C8M, its scheduling plug-in utility must be configured at the IFI Workstation. The NION-2C8M can be configured to operate using a dedicated scheduler application plug-in.
  • Page 24: I/O Configuration

    Configuration box on the I/O Configuration form. Enter the range of input points in the From and To fields, select the desired state option in the Configure As combo box then click the Set State button to finish. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 25: Time Codes

    UTE. To add any of these codes to the NION time codes grid, simply click and drag the desired definition from the display on the right into the grid on the left. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 26: Holiday Codes

    The clear command is local to the current IFI Workstation, and only when you click on Apply the Workstation sends the updated holiday settings over the network. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 27: Functional Properties Of The Nion-2C8M

    State - The state of the input is the actual physical status of the point being monitored. The states are: Input Active Input Normal Open Circuit Short Circuit The NION reports different point states based on the current operational mode of the input. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 28: 2: Rules For Mode Change Commands

    Override mode it will ignore the next Arm command sent by the Scheduler. In addition, when a point is in Override mode it will respond to mode change commands issued manually (user action) or automatically (NetLogic). NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 29: 3: Special Operational Scenarios - Inputs

    Disarm it. If a point subject to scheduled control needs to delay entering the Armed mode, place the point in Override mode. The point can be issued a Manual Arm command later. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 30: 4: Rules For Output State Changes

    For hard reset only, all outputs are deactivated in the hardware. During a node reset, any input point that was in a Disabled mode at the time of the reset will remain in the Disabled mode. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 31: Index

    FTXC Network Transceivers 15 Hardware Requirements 9 Installation Environmental Conditions 8 JNISCAB-1 Installation 11 NION Connections Serial Data Connection 18 Power Connection 18 Regulatory Listings 18 SMX Network Transceivers 14 Software Replacement 21 NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 32 Index NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 33 This warranty replaces all previous warranties and is the only warranty made by the manufacturer. No increase or alteration, written or verbal, of the obligation of this warranty is authorized. NION-2C8M Installation & Operation Manual - P/N: 53346:Rev: A1 5/5/09...
  • Page 34 Controls Group www.johnsoncontrols.com 507 E. Michigan Street P.O. Box 423 Release Rev: A1 Milwaukee, WI 53201 Printed in U.S.A.
