M-system R7D-SV4/UL Instruction Manual page 3

■ INPUT RANGE
• Wide span: -10 – +10V DC, -5 – +5V DC, 0 – 10V DC,
0 – 5V DC, 1 – 5V DC
• Narrow span: -1 – +1V DC, 0 – 1V DC, -0.5 – +0.5V DC
• Current input: -20 – +20mA DC, 0 – 20mA DC,
4 – 20mA DC
■ EXTENSION MODULE
Combinations with all extension modules are selectable.
PC CONFIGURATOR
The following parameter items can be set with using PC Configurator Software (model: R7CON).
Refer to the users manual for the R7CON for detailed operation of the software program.
■ INTERFACE SETTING
PARAMETER
Communication Timeout
Status Data
Serial ID
■ CHANNEL INDIVIDUAL SETTING
PARAMETER
Input Range
Zero scale
Full scale
Bias
Gain
■ EXTENSION MODULE SETTING
PARAMETER
Output Hold/Clear
SEN TRONIC
SETTING RANGE
0.0 – 3276.7 (sec.)
ON: Disable
OFF: Enable
English one-byte characters within 8 characters
SETTING RANGE
-10 to +10 V DC
-5 to +5 V DC
-1 to +1 V DC
0 to 10 V DC
0 to 5 V DC
1 to 5 V DC
0 to 1 V DC
-0.5 to +0.5 V DC
-20 to +20 mA DC
0 to 20 mA DC
4 to 20 mA DC
-32000 to +32000
-32000 to +32000
-320.00 to +320.00
-3.2000 to +3.2000
SETTING RANGE
Output Hold
Output Clear
056 222 38 18 mailbox@sentronic.com
AG
R7D-SV4
DEFAULT SETTING
1.0 (sec.)
OFF: Enable
DEFAULT SETTING
-10 to +10 V DC
0
10000
0.00
1.0000
DEFAULT SETTING
Output Hold
