Quick Install Guide
Compex Wireless-G
Network PCI
Adapter
WLP54G
Ordering Information: WLP54G 2a
Version 1.2
1. Introduction
Figure 1
Compex iWavePort WLP54G
Compex iWavePort WLP54G is a 54Mbps PCI Wireless LAN
adapter. Utilizing 2.4GHz radio frequency band, Compex iWavePort
WLP54G provides 54Mbps network connectivity via open air. Data
security is facilitated with either 64-bit or 128-bit WEP (Wired
Equivalent Privacy). Compex iWavePort WLP54G supports easy
Plug and Play installation. Compex iWavePort WLP54G combines
simplicity, data privacy and reliability for your wireless network.
2. Hardware Installation
Actual product appearance may slightly differ depending on the
hardware version.
Compex iWavePort WLP54G
PCI slot
Figure 2
Inserting Compex iWavePort WLP54G into PCI slot
The following installation process is operated under Windows XP.
For installation process operating under 98SE//ME/2000, kindly refer
to the Drivers & Utilities Installation Guide in the Product CD. If you
have installed the Wireless PC Card driver & utility before,
please uninstall the old version first.
1. Turn off your PC and switch off the power from the power point.
2. Insert Compex iWavePort WLP54G into your PCI slot as shown
above.
3. Power up your PC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the COMPEX WIRELESS-G WLP54G and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compex COMPEX WIRELESS-G WLP54G

Summary of Contents for Compex COMPEX WIRELESS-G WLP54G

  • Page 1 Quick Install Guide Compex Wireless-G Network PCI Adapter WLP54G Ordering Information: WLP54G 2a Version 1.2 1. Introduction Figure 1 Compex iWavePort WLP54G Compex iWavePort WLP54G is a 54Mbps PCI Wireless LAN adapter. Utilizing 2.4GHz radio frequency band, Compex iWavePort WLP54G provides 54Mbps network connectivity via open air. Data security is facilitated with either 64-bit or 128-bit WEP (Wired Equivalent Privacy).
  • Page 2 However, you will notice that the RALINK Wireless Utility screen appears automatically, together with the RALINK Wireless Network Card Setup. Before you can configure the Utility program, first exit the latter by clicking Finish. If you wish to exit the utility program, simply go to the taskbar and place your cursor on the icon (as circled in red).
  • Page 3 9. To activate the utility program if you have already exited it, simply proceed to Start Menu, Programs, RaLink and select RT2500. From RT2500, select RaConfig2500. Once you click on the utility option, the following screen shot will appear. You may start to configure your Compex iWavePort WLP54G.

  • Page 4: Technical Specification

    Technical Specification Network Protocol, Standards and Electrical Emissions Industry Standards Interoperable with • IEEE 802.11g (OFDM) • IEEE 802.11b (DSSS) Safety Certifications • CE Mark • Perfomance Frequency Band 2.4 GHz Data Rate Up to 54Mbps (with Automatic Scale Back) Host Interface 32-bit PCI Operating Voltage...
