Technote - 066 (Rev 1.0)
10/100 Mbps PCI Network Adapter with Wake-On-LAN
The ReadyLink RE100ATX/WOL is a flexible network adapter that provides
automatic dual speed switching for the 10Base-T and 100Base-TX standards.
Harnessing the advantages of PCI-bus master architecture, RE100ATX/WOL
efficiently minimizes the amount of CPU utilization required for data transfers.
RE100ATX/WOL operates in full duplex mode which transmits and receives data
simultaneously and this would effectively double the network throughput. In
addition, a socket is provided for optional Boot ROM which allows diskless booting
from network operating systems such as NetWare, Microsoft LAN Manager and
Microsoft NT Server. Its Wake-on-LAN and ACPI features allow remote powering
of workstation

High-Performance

The Compex RE100ATX/WOL provides high
network throughput through its support for
100Mbps and Full-Duplex operations that
offers the workstation up to 200 Mbps
bandwidth at no additional cost.

Compatibility

Supporting the PCI 2.1/2.2 specifications for
easy integration to any desktop or workstation.
It supports both 10/100 Mbps networks and is
suitable to be used with any legacy network
devices that only offers 10Mbps connectivity.

Management

The Wake-On-LAN features allows users to
remotely wake up or start up the workstation
using the "magic packet" or "wake up frame".
RE100ATX/WOL

Plug and Play Operations

The Compex RE100ATX/WOL is a fully
plug and play device. Simply plug it into
a PCI bus and complete the drivers
installation giving users the ultimate
out-of-box experience.

Drivers Support

It supports major operating system like
Microsoft Windows 95, 98, ME, 2000,
XP, Linux, SCO Unix, Novell Netware
etc.
DATA SHEET
