Texim Europe ACP-5187 Manual

Multi-touch panel pc
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
M u l t i - T o u c h P a n e l P C
A C P - 5 1 8 7
ACP-5187
®
TM
18.5" Intel
Core
i7/
TM
Core
i5/ Celeron Processor
High Brightness
Fanless Multi-Touch Panel PC
ACP-5187 Manual 1st Ed
July 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ACP-5187 and is the answer not in the manual?

Questions and answers

Related Manuals for Texim Europe ACP-5187

Summary of Contents for Texim Europe ACP-5187

  • Page 1 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 ACP-5187 ® 18.5” Intel Core Core i5/ Celeron Processor High Brightness Fanless Multi-Touch Panel PC ACP-5187 Manual 1st Ed July 2013...
  • Page 2 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Copyright Notice This document is copyrighted, 2013. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice.
  • Page 3 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Acknowledgments ® ®  Intel , Core are registered trademarks of Intel Corporation. ® ®...
  • Page 4 A C P - 5 1 8 7 Packing List Before you begin installing your Panel PC, please make sure that the following items have been shipped:  ACP-5187 Infotainment Multi-Touch Panel PC Power Adapter x 1   Product DVD Contains User’s Manual (in PDF format), Drivers and...
  • Page 5 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Safety & Warranty 1. Read these safety instructions carefully. 2. Keep this user's manual for later reference. 3.
  • Page 6 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 14. If any of the following situations arises, get the equipment checked by service personnel: a.
  • Page 7 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Classification 1. Degree of production against electric shock: not classified 2. Degree of protection against the ingress of water: IPX1 3.
  • Page 8 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received...
  • Page 9 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 UL Module Description ACP-5187 AC modules are developed to suitable for the Classification Mark requirement...
  • Page 10 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Safety Symbol Description The following safety symbols are further explanations for your reference. Medical equipment with respect to electric shock, fire and mechanical hazards only in accordance with UL 60601-1, and CAN/CSA C22.2 NO.
  • Page 11 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Panel PC/ Workstation 有毒有害物质或元素 部件名称 铅 汞...

  • Page 12: Table Of Contents

    2.3 Clear CMOS (JP11) ..........2-3 2.4 COM Port 2 Connector (CN11) ......... 2-3 2.5 COM Port 1 (D-SUB 9) (CN27) ......... 2-5 2.6 A Quick Tour of the ACP-5187........2-6 2.7 2.5” Hard Disk Drive (HDD) Installation ....2-9 Chapter 3 AMI BIOS Setup 3.1 System Test and Initialization .
  • Page 13 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Appendix B I/O Information B.1 I/O Address Map ............B-2 B.2 Memory Address Map..........B-4 B.3 IRQ Mapping Chart ..........B-5 B.4 DMA Channel Assignments........B-5 Appendix C Miscellanea C.1 General Cleaning Tips ..........
  • Page 14 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Chapter General Information Chapter 1 General Information...

  • Page 15: Chapter 1 General Information

    The ACP-5187 includes all the features of a powerful computer into a slim and attractive chassis. The ACP-5187 has 300 nits TFT display with 1366 x 768 resolution. This model equips two-point Multi-Touch Window design and is easy to clean.

  • Page 16: Features

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 1.2 Features  18.5” WXGA (1366 x 768) Fanless TFT LCD Display  Easy-To-Clean: Multi-Touch Window Design (Two-Point) ®...

  • Page 17: Specification

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 1.3 Specification System ®  Onboard Intel Core™ i7/ Core™ i5 / Processor Celeron Core™ Processor ...
  • Page 18 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Mechanical  Construction IP-65/ NEMA4 for front bezel, IPX1 from the top plastic housing ...
  • Page 19 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7  Display Type 18.5” TFT-LCD, CCFL  Max. Resolution 1366 x 768  Max. Colors 16.7 M colors (6/8-bit for R, G, B) ...

  • Page 20: General Information

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 1.4 General Information 1.3M Camera (Optional) LCD On/Off Volume+ Volume- RFID (Optional) Brightness+ Brightness- Chapter 1 General Information...
  • Page 21 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 VESA 100 Mounting Holes Mounting Holes Chapter 1 General Information...
  • Page 22 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 RS-232 USB x 2 DVI-I USB x 2 Power Input Smart Card Reader (Optional) Power Switch Line-out USB x 2...

  • Page 23: Chapter 2 Hardware Installation

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Chapter Hardware Installation Chapter 2 Hardware Installation...

  • Page 24: Safety Precautions

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 25: Com2 Pin8 Function Selection (Jp8)

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 2.2 COM2 Pin8 Function Selection (JP8) +12V Ring Function +12V Ring (Default) 2.3 Clear CMOS (JP11) 1 2 3 1 2 3 Normal...
  • Page 26 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 ±9V ±9V RI/+5V/+12V IN/ PWR +5V/+12V RS-422 Pin Name Signal Type Signal Level RS422_TX- ±5V RS422_RX+ RS422_TX+...

  • Page 27: Com Port 1 (D-Sub 9) (Cn27)

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 NC/+5V/+12V +5V/+12V Note: COM2 RS-232/422/485 can be set by BIOS setting. Default is RS-232. Pin 8 function can be set by JP8. 2.5 COM Port 1 (D-SUB 9) (CN27) Pin Name Signal Type...

  • Page 28: A Quick Tour Of The Acp-5187

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 2.6 A Quick Tour of the ACP-5187 Mechanical Drawing ACP- 5 1 8 7 Un i t s :m m 8 6 .
  • Page 29 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Rear Chapter 2 Hardware Installation...
  • Page 30 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Cable Cover (Optional) Note 1: You may turn on the power by cutting and destroying the protective cover as it shows below.

  • Page 31: Hard Disk Drive (Hdd) Installation

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 2.7 2.5” Hard Disk Drive (HDD) Installation Step 1: Unscrew the rear cover screws (15 screws) Step 2: Remove EMI Cover (5 screws) Chapter 2 Hardware Installation...
  • Page 32 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 3: Remove HDD Bracket (4 screws) Step 4: Get the HDD and HDD Bracket ready 2-10 Chapter 2 Hardware Installation...
  • Page 33 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 5: Fasten the four screws to fix HDD Bracket and HDD Step 6: Connect the SATA and power cables to the HDD and fasten the four screws to fix the HDD Bracket 2-11 Chapter 2 Hardware Installation...
  • Page 34 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Chapter BIOS Setup Chapter 3 AMI BIOS Setup 3-1...

  • Page 35: System Test And Initialization

    4. The CMOS memory has lost power and the configuration information has been erased. The ACP-5187 CMOS memory has an integral lithium battery backup for data retention. However, you will need to replace the complete unit when it finally runs down.

  • Page 36: Ami Bios Setup

    M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 3.2 AMI BIOS Setup AMI BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.
  • Page 37 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Setup Menu Setup submenu: Main Options summary: (default setting) System Date Day MM:DD:YYYY Change the month, year and century. The ‘Day’ is changed automatically. System Time HH : MM : SS Change the clock of the system.
  • Page 38 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Setup submenu: Advanced Options summary: (default setting) ACPI Settings System ACPI Parameters Trusted Computing Trusted Computing Settings CPU Configuration CPU Configuration Parameters...
  • Page 39 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Intel TXT(LT) Configuration Intel Trusted Execution Technology AMT Configuration AMT Configuration Parameters USB Configuration USB Configuration Parameters H/W Monitor Monitor hardware status...
  • Page 40 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 ACPI Settings Options summary: (default setting) Enabled Enable Hibernation Disabled Enabled or disabled hibernate (OS/S4 Sleep State). Suspend Disabled S1 only(CPU Stop Clock) ACPI Sleep State...
  • Page 41 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Disabled Enabled or disabled wake on ring function. RTC Wake Settings Options summary: (default setting) Wake system with Disabled Fixed Time...
  • Page 42 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Wake up minute 0-59 Wake up second 0-59 Wake system with Disabled Dynamic Time Enabled Enable or disable System wake on alarm event.
  • Page 43 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Options summary: (default setting) Security Device Support Disabled Enabled En/Disable TPM support. TPM State Disabled Enabled En/Disable TPM functionality.
  • Page 44 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 CPU Configuration Options summary: (default setting) Hyper-Threading Disabled Enabled En/Disable CPU Hyper-Threading function Active Processor Cores 1 to Max CPU cores Number of CPU cores to be active.
  • Page 45 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Enabled En/Disable XD bit for supporting OS Intel Virtualization Disabled Technology Enabled En/Disable Intel VT-x function EIST Disabled Enabled...
  • Page 46 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Options summary: (default setting) SATA Controller(s) Disabled Enabled En/Disable SATA controller Configure SATA as AHCI RAID Available for QM77 Sku...
  • Page 47 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Intel TXT(LT) Configuration Options summary: (default setting) Intel TXT(LT) Support Disabled Enabled En/Disable Intel TXT function. This function only can be enabled/disabled if SMX, VT-x and VT-d support are enabled prior to it.
  • Page 48 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 AMT Configuration Options summary: (default setting) Intel AMT Enabled Disabled En/Disable Intel® Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled.
  • Page 49 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 USB Configuration Options summary: (default setting) Legacy USB Support Enabled Disabled Auto Enables BIOS Support for Legacy USB Support. When enabled, USB can be functional in legacy environment like DOS.
  • Page 50 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Enables BIOS Support for USB3.0 (XHCI). When disabled, PCH USB3.0 controller will also be disabled. Device Name Auto (Emulation Type)
  • Page 51 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Super IO Configuration Options summary: (default setting) Serial Port 1/2 Configuration Set Parameters of Serial Port 1/2 Power Off Restore AC Power Loss Power On...
  • Page 52 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Configure Energy-using Product(EuP) Power Control. Serial Port 1 Configuration Options summary: (default setting) Serial Port Disabled Enabled En/Disable specified serial port.
  • Page 53 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 IO=2F8h; IRQ=3,4,5,7,10,11,12; IO=3E8h; IRQ=3,4,5,7,10,11,12; IO=2E8h; IRQ=3,4,5,7,10,11,12; Select a resource setting for Super IO device. Serial Port 2 Configuration Options summary: (default setting) Serial Port...
  • Page 54 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 En/Disable specified serial port. Change Settings Auto IO=2F8h; IRQ=3; IO=3F8h; IRQ=3,4,5,7,10,11,12; IO=2F8h; IRQ=3,4,5,7,10,11,12; IO=3E8h; IRQ=3,4,5,7,10,11,12;...
  • Page 55 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Setup submenu: Chipset Options summary: (default setting) Onboard Device Configure Onboard Devices PCI-IO Configuration South Bridge Parameters Memory Configuration Memory Parameters...
  • Page 56 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Onboard Device Options summary: (default setting) Onboard HD Audio Disabled Enabled Auto En/Disabled HD Audio controller. HD Audio Internal Enabled HDMI Codec...
  • Page 57 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 En/Disabled Intel i82579 NIC Realtek LAN Controller Enabled Disabled En/Disabled Realtek RTL8111E NIC PCH-IO Configuration Options summary: (default setting) Power Mode ATX Type...
  • Page 58 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 PCIe Speed Auto Gen1 Gen2 Select PCI Express port speed. Some PCIe carsd must set to Gen1 for operation.
  • Page 59 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Memory Frequency Auto Limiter 1067 1333 1600 Maximum Memory Frequency Selections in Mhz. Max TOLUD Dynamic 1 GB 1.25 GB...
  • Page 60 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Graphic Configuration Options summary: (default setting) Primary Display Auto IGFX Select graphic adapters to boot Internal Graphics Auto Disabled...
  • Page 61 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Select the GTT Size Aperture Size 128MB 256MB 512MB Select the Aperture Size DVMT Pre-Allocated 64MB 32MB~1024MB Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the...
  • Page 62 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 LCD Control Options summary: (default setting) Primary IGFX Boot Auto Detect Display DVI-A LVDS1 DVI-D Select Primary IGFX boot display device Note: LVDS1 is the default main display device when this item set to “Auto...
  • Page 63 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 LVDS1(Internal) Enabled Enable Internal LVDS LVDS1 Panel Type 1366x768 24-Bit 1366x768 24-Bit resolution. Chapter 3 AMI BIOS Setup 3-30...
  • Page 64 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Setup submenu: Boot Options summary: (default setting) Quiet Boot Disabled Enabled En/Disable showing boot logo. Launch I82579LM/ Disabled RTL8111E PXE...
  • Page 65 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Boot Option #X/ XXXX Drive BBS Priorities The order of boot priorities. BBS Priorities Options summary: (default setting) Boot Option #x Disabled...
  • Page 66 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Setup submenu: Security Options summary: (default setting) Administrator Not set Password/ User Password Chapter 3 AMI BIOS Setup 3-33...
  • Page 67 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 You can install a Supervisor password, and if you install a supervisor password, you can then install a user password. A user password does not provide access to many of the features in the Setup utility.
  • Page 68 M u l t i - T o u c h P a n e l P C A E C - 5 1 8 7 Setup submenu: Exit Options summary: (default setting) Save Changes and Reset Reset the system after saving the changes Discard Changes and Reset Reset system setup without saving any changes Restore Defaults...

  • Page 69: Chapter 4 Driver Installation

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Chapter Driver Installation Chapter 4 Driver Installation...
  • Page 70 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 The ACP-5187 comes with an AutoRun DVD-ROM that contains all drivers and utilities that can help you to install the driver automatically.
  • Page 71 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 4.1 Installation: Insert the ACP-5187 DVD-ROM into the DVD-ROM drive. And install the drivers from Step 1 to Step 10 in order. Step 1 – Install Chipset Driver 1.
  • Page 72 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 ® Note 2: If the OS is Windows XP, you have to install the driver of dotNet Framework first.
  • Page 73 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 6 – Install ME Driver 1. Click on the STEP6-ME SW folder and select the OS folder your system is 2.
  • Page 74 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 10 –Install USB3.0 Driver 1. Click on the STEP10-USB3.0 folder and select the OS folder your system is 2.

  • Page 75: Appendix A Programming The Watchdog Timer

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Appendix Programming the Watchdog Timer Appendix A Programming the Watchdog Timer...

  • Page 76: Programming

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 A.1 Programming ACP-5187 utilizes ITE IT8728F chipset as its watchdog timer controller. Below are the procedures to complete its configuration and the AAEON intial watchdog timer program is also attached based on which you can develop customized program to fit your application.
  • Page 77 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 There are three steps to complete the configuration setup: (1) Enter the MB PnP Mode; (2) Modify the data of configuration registers; (3) Exit the MB PnP Mode.
  • Page 78 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 WatchDog Timer Configuration Registers Configure Control (Index=02h) This register is write only. Its values are not sticky; that is to say, a hardware reset will automatically clear the bits, and does not require the software to clear them.
  • Page 79 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 WatchDog Timer Control Register (Index=71h, Default=00h) WatchDog Timer Configuration Register (Index=72h, Default=00h) WatchDog Timer Time-out Value Register (Index=73h, Default=00h) Appendix A Programming the Watchdog Timer...

  • Page 80: Ite8728F Watchdog Timer Initial Program

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 A.2 ITE8728F Watchdog Timer Initial Program .MODEL SMALL .CODE Main: CALL Enter_Configuration_mode CALL Check_Chip mov cl, 7 call Set_Logic_Device ;time setting...
  • Page 81 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 ; game port enable mov cl, 9 call Set_Logic_Device Initial_OK: CALL Exit_Configuration_mode MOV AH,4Ch INT 21h Enter_Configuration_Mode PROC NEAR MOV SI,WORD PTR CS:[Offset Cfg_Port]...
  • Page 82 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Exit_Configuration_Mode ENDP Check_Chip PROC NEAR MOV AL,20h CALL Read_Configuration_Data CMP AL,87h JNE Not_Initial MOV AL,21h CALL Read_Configuration_Data CMP AL,12h JNE Not_Initial...
  • Page 83 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 MOV DX,WORD PTR CS:[Cfg_Port+06h] IN AL,DX Read_Configuration_Data ENDP Write_Configuration_Data PROC NEAR MOV DX,WORD PTR CS:[Cfg_Port+04h] OUT DX,AL XCHG AL,AH MOV DX,WORD PTR CS:[Cfg_Port+06h]...
  • Page 84 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 push ax push cx xchg al,cl mov cl,07h call Superio_Set_Reg pop cx pop ax Set_Logic_Device endp ;Select 02Eh->Index Port, 02Fh->Data Port Cfg_Port DB 087h,001h,055h,055h...

  • Page 85: Appendix B I/O Information

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Appendix I/O Information Appendix B I/O Information...

  • Page 86: I/O Address Map

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 B.1 I/O Address Map Appendix B I/O Information...
  • Page 87 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Appendix B I/O Information...

  • Page 88: Memory Address Map

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 B.2 Memory Address Map Appendix B I/O Information...

  • Page 89: Irq Mapping Chart

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 B.3 IRQ Mapping Chart B.4 DMA Channel Assignments Appendix B I/O Information...

  • Page 90: Appendix C Miscellanea

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 A ppendix Miscellanea Appendix C Miscellanea C-...

  • Page 91: General Cleaning Tips

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 C.1 General Cleaning Tips You may need the following precautions before you begin to clean the computer.

  • Page 92: Cleaning Tools

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 C.2 Cleaning tools Although many companies have created products to help improve the process of cleaning your computer and peripherals users can also use household items to clean their computers and peripherals.
  • Page 93 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7  Cotton swabs - Cotton swaps moistened with rubbing alcohol or water are excellent tools for wiping hard to reach areas in your keyboard, mouse, and other locations.

  • Page 94: Scrap Computer Recycling

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 C.3 Scrap Computer Recycling If the computer equipments need the maintenance or are beyond repair, we strongly recommended that you should inform us as soon as possible for the suitable solution.

  • Page 95: Installing Accessories

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 C.4 Installing Accessories Skype Phone Installation Step 1: Fasten the two screws(2-SELF TAPPING SCREWS) to fix the Skype Bracket with the ACP-5187 Appendix C Miscellanea C-...
  • Page 96 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 MSR Installation Step 1: Fasten the two screws (2-SELF TAPPING SCREWS) to fix the MSR Bracket with the ACP-5187 Appendix C Miscellanea...
  • Page 97 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Bar Code Scanner Installation Step 1: Fasten the three screws to fix the Bar Code Scanner with the backet Appendix C Miscellanea C-...
  • Page 98 A C P - 5 1 8 7 A C P - 5 1 8 7 Step 2: Fasten the two screws (2-SELF TAPPING SCREWS) to fix the Bar Code Scanner with the ACP-5187 Appendix C Miscellanea Appendix C Miscellanea...
  • Page 99 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 A ppendix RAID & AHCI Settings Appendix D RAID & AHCI Settings...

  • Page 100: Appendix D Raid & Ahci Settings

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 D.1 Setting RAID OS installation to SETUP RAID Mode Step 1: Extract the f6fly-x86.zip from “Driver CD -> STEP7-RAID&AHCI\WinXP_32”...
  • Page 101 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 3: Configure SATA Controller to RAID mode in BIOS SETUP Menu: Advanced -> SATA Configuration -> SATA Mode -> RAID Mode Step 4: Configure DVD/CD-ROM drive as the first boot device.
  • Page 102 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 5: Save changes and exit BIOS SETUP Step 6: Press CTRL-I to enter RAID Configuration Utility Appendix D RAID &...
  • Page 103 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 7: Choose “1. Create RAID Volume” Step 8 – Configure RAID parameters for the system Appendix D RAID &...
  • Page 104 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 9 – Choose “Create Volume” and confirmed in next warning message. Appendix D RAID & AHCI Settings...
  • Page 105 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 10 – Exit RAID Configuration Utility and Reboot to DVD/CD-ROM device to install OS Step 11 –...
  • Page 106 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 13 – Choose “Intel(R) Mobile Express Chipset SATA RAID Controller” Step 14 – It will show the model you selected and then press ”ENTER”. Windows Setup will continue to install OS.

  • Page 107: Setting Ahci

    M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 D.2 Setting AHCI OS installation to SETUP AHCI Mode Step 1: Extract the f6fly-x86.zip from “Driver CD -> STEP7 - RAID&AHCI\WinXP_32”...
  • Page 108 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 3: Configure SATA Controller to RAID mode in BIOS SETUP Menu: Advanced -> SATA Configuration -> SATA Mode -> AHCI Mode Step 4: Configure DVD/CD-ROM drive as the first boot device.
  • Page 109 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 5: Save changes and exit BIOS SETUP Step 6 – Boot to DVD/CD-ROM device to install OS Step 7 –...
  • Page 110 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 8 – Press “S” to install AHCI driver Step 9 – Choose “Intel(R) 7 Series Chipset Family SATA AHCI Controller”...
  • Page 111 M u l t i - T o u c h P a n e l P C A C P - 5 1 8 7 Step 10 – It will show the model you selected and then press ”ENTER”. Windows Setup will continue to install OS.
