- Page 1 W a t e r p r o o f P a n e l P C FOX-80 ® Onboard Intel Ultra LV ® Celeron M Processor Multipurpose & Waterproof Panel PC with 8.4” SVGA Color TFT LCD FOX-80 Manual 2nd Ed December 2008...
- Page 2 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Copyright Notice This document is copyrighted, 2008. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice.
- Page 3 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Acknowledgments All other products’ name or trademarks are properties of their respective owners.
- Page 4 Connecter for LAN (optional) • waterproof Connecter for audio –Line-out (optional) • CD-ROM for manual (in PDF format) • FOX-80 Multi-purpose & Water-proof Panel PC If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
- Page 5 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Safety & Warranty 1. Read these safety instructions carefully. 2.
- Page 6 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C The equipment does not work well, or you cannot get it to work according to the user’s manual.
- Page 7 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量...
-
Page 8: Table Of Contents
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Contents Chapter 1 General Information 1.1 Introduction.............. -
Page 9: Chapter 1 General Information
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Chapter General Information 1- 1 Chapter 1 General Information... -
Page 10: Introduction
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 1.1 Introduction FOX-80 Multipurpose & Waterproof... -
Page 11: Features
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 1.2 Features ® ® Onboard Intel Ultra Low Voltage Celeron M Processor... -
Page 12: Specification
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 1.3 Specification System Onboard Intel ULV Celeron M 1.0GHz Processor Memory Onboard 512MB, up to 1G DDR... - Page 13 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C (266mm x 192mm x 59.8mm) Gross Weight 5.5 lb (2.5Kg) Environmental...
- Page 14 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Touch Screen Type 4-wire, low reflection analog resistive (FOX-80STT) 4-wire, analog resistive (FOX-80HTT)
- Page 15 W a t e r p r o o f P a n e l P C 1.4 Dimension 59.82 75.00 USB 0/1 COM2 COM1 POWER 25.00 30.00 13.5 FOX-80 Multi-Purpose & Water-Proof Panel PC Unit: mm Chapter 1 General Information...
- Page 16 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Sunlight Readable Touch Screen Front side (Optional) Day/Night Mode...
-
Page 17: Chapter 2 Hardware Installation
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Chapter Hardware Installation Chapter 2 Quick Installation Guide... -
Page 18: Usb 1/2 Connecter
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 2.1 USB 1/2 Connecter Signal Signal USB V+... -
Page 19: Com2 Connector For Rs-232/Rs-422/Rs-485
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 2.3 COM2 Connector for RS-232/RS-422/RS-485 RS-232 Signal Signal... -
Page 20: Audio (Line Out)
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 2.4 Audio (Line out) Signal Signal R-out... -
Page 21: Chapter 3 Award Bios Setup
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Chapter Award BIOS Setup Chapter 3 Award BIOS Setup... - Page 22 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 3.1 System Test and Initialization These routines test and initialize board hardware.
- Page 23 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C 3.2 Award BIOS Setup Awards BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.
- Page 24 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C PC Health Status This menu allows you to set the shutdown temperature for your system.
-
Page 25: Chapter 4 Driver Installation
M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Chapter Driver Installation 4 - 1 Chapter 4 Driver Installation... - Page 26 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C There are several installation ways depending on the driver package under different Operating System application.
- Page 27 W a t e r p r o o f P a n e l P C 4.1 Installation Insert the FOX-80 CD-ROM into the CD-ROM drive and install the drivers from Step 1 to Step 5 in order. Step 1 – Install Intel INF Update for Windows 9x-2003 Driver 1.
- Page 28 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Step 4 – Install Realtek AC97 codec Driver 1.
- Page 29 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C Appendix Appendix A FAQ A-...
- Page 30 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C A.1 FAQ 1 Installing Windows 2000 from a USB CD-ROM Drive May Cause a "Stop 0x7B"...
- Page 31 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C This article was previously published under Q294820 SYMPTOMS If you are using a Universal Serial Bus (USB) CD-ROM drive to install Windows 2000 on certain legacy-free computers, you may...
- Page 32 M u l t i p u r p o s e & F O X - 8 0 W a t e r p r o o f P a n e l P C A.2 FAQ 2 What type of anti-glare treatment are you putting onto your touch screen and what is the LCD brightness reduction with this treatment? Answer:...
- Page 33 Fax: +49 (0)89 436 086-19 info@texim-europe.com info@texim-europe.com Austria Pyrkergasse 6/1 A-1190 Wien Tel: +43 (0)1 369 09 09 - 0 Fax: +43 (0)1 369 09 10 info@texim-europe.com Texim Europe B.V. Elektrostraat 17 Tel: +31 (0)53 573 33 33 info@texim-europe.com www.texim-europe.com...
