LG Flatron M4200C-AA Manual

LG Flatron M4200C-AA Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Table of Contents

Installation
and
Connection
Selecting and Adjusting the Screen
Input
How to adjust the OSD (On Screen Display) Screen
Selection
and Tracking
Troubleshooting
Miscellaneous
Specifications
is a trademark of SRS Labs,Inc.
technology is incorporated under license from SRS Labs,Inc.
Adjusting Screen Color
Adjusting the audio function
Selecting the Options
Adjusting Screen CLOCK/PHASE and Position
Adjusting PIP/POP/PBP Mode (Multiple Screen) Functions
i
A1
A4
A5
A8
A9
A10
A11
A11
A18
A19
A22
A23
A24
A25
A29
A30
A32
A35

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flatron M4200C-AA and is the answer not in the manual?

Questions and answers

Related Manuals for LG Flatron M4200C-AA

Summary of Contents for LG Flatron M4200C-AA

  • Page 1: Table Of Contents

    Table of Contents Safety Precautions Installation Accessories Using the Remote Control Connection To arrange cables in order - Optional Connecting the Speakers - Optional Name and Function of the Parts Connecting to External Devices When Connecting to your PC Watching RGB Outputs When Watching VCR/DVD When Watching HDTV (720p/1080i)

  • Page 2: Safety Precautions

    Safety Precautions Please read these safety precautions carefully before using the product. If you ignore the warning message, you may be seriously injured or there is a possibility of Warning accident or death. Caution If you ignore the caution message, you may be slightly injured or the product may be damaged Precautions in installing the Product Warning Keep away from heat sources like electrical heaters.
  • Page 3 Electrical Power Related Precautions Warning Make sure to connect the power cable to the grounded current. - You may be electrocuted or injured. Use the rated voltage only. - The product can be damaged, or you may be electrocuted. During a thunder or lightning storm, unplug the power cable or signal cable. - You may be electrocuted or a fire can break out.
  • Page 4 Safety Precautions Caution Do not shock the product when moving it. - You may be electrocuted or the product can be damaged Do not dispose the product-packing box. Use it when you move. Make the panel face forward and hold it with both hands to move. - If you drop the product, the damaged product can cause electric shock or fire.

  • Page 5: Accessories

    Accessories Please check the accessories in the product package. * The product and the accessories can be different from the figures shown here. Free Mount Type Desktop Stand Type Product Remote Control/ Batteries User's Guide/ 15-pin D-Sub Signal DVI-D Signal Cable Driver CD/Cards Cable RCA-PC...

  • Page 6: Using The Remote Control

    • PC: Automatic adjustment function which is supported (Operational for the analog signal only) * There is not a function which is supported * There is not a function which is supported Video Operation Button Applicable for LG products only...
  • Page 7 • Input Select Button • AV Button If you press the button once, This button will be enabled only when the following Input Signal you selected the AV signal. The signal Window will appear. Select type will be changed with the following the signal type you want order.
  • Page 8 Using the Remote Control SWAP Button You can swap the main screen and the sub-screen when the PIP/POP/PBP function is used. SWAP SWAP When 'Input Signal 1' comes on in the main screen, only 'Input Signal 2' can be displayed on the sub- screen.

  • Page 9: To Arrange Cables In Order - Optional

    To arrange cables in order - Optional * Applicable only for models that support the stand Disassemble the stand cover. The cover may be easily disassembled by pressing down on the base as shown in the figure. Stand cover After connecting the cables, correctly position the stand cover into the holes on the stand.

  • Page 10: Connecting The Speakers - Optional

    Connecting the Speakers - Optional * Applicable only for models that support the speakers Use the screws to secure the speakers on the rear side of the product as shown in the below figure. When the speaker is installed.

  • Page 11: Name And Function Of The Parts

    Name and Function of the Parts * The product image in the user’s guide could be different from the actual image. Rear View Back Cap - Open the back cap before you install the product. Power Connector : Connect the power cord Wired Remote Control Port RS-232C Serial Ports PC Signal Inputs...

  • Page 12: Connecting To External Devices

    Connecting to External Devices When Connecting to your PC First of all, see if the computer, product and the peripherals are turned off. Then, connect the signal input cable. When connecting with the DVI signal input cable. When connecting with the D-Sub signal input cable. (IBM compatible PC1) When connecting with the D-Sub signal input cable.
  • Page 13 Turn on power by pressing the power button on the product. Power button Turn on the PC. Select an input signal. Press the SOURCE button on the remote control to select the input signal. SOURCE Or, press the SOURCE button at the front side of the product. SOURCE SELECT When connecting with a DVI-D signal input cable.

  • Page 14: Watching Rgb Outputs A13

    Connecting to External Devices Watching RGB Outputs Use this function when displaying ANALOG RGB inputs of a PC to the other product. To use different products connected to each other • Connect one end of the signal input cable(15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB INPUT connector of other products.

  • Page 15: When Watching Vcr/Dvd A14

    When watching VCR / DVD Connect the video cable as shown in the below figure and then connect the power cord (See page A11). When connecting with a RCA cable. Connect the input terminal with a proper color match. • (Video –...

  • Page 16: When Watching Hdtv (720P/1080I) A15

    Connecting to External Devices When watching HDTV(720p/1080i) Connect the video/audio cable as shown in the below figure and then, connect the power cord (See page A11). Connect the input terminal with a proper color match. • Product HDTV Receiver The HDTV terminal also supports SDTV (480i/480p/576i/576p). Select an input signal.

  • Page 17: When Watching Dvd (480I/576I) A16

    When watching DVD(480i/576i) Connect the video/audio cable as shown in the below figure and then, connect the power cord (See page A11). Connect the input terminal with a proper color match. • Product DVD Receiver Select an input signal. Press the SOURCE button on the remote control to select the input signal. SOURCE Or, press the SOURCE button at the front side of the product.

  • Page 18: When Watching Dvi-D(Hdcp) From The Vcr/Dvd/Set-Top Box A17

    Connecting to External Devices When watching DVI-D(HDCP) from the VCR/DVD/Set-top Box Connect the video/audio cable as shown in the below figure and then connect the power cord (See page A11). Product DVI-D RCA-PC Signal Cable Audio Cable VCR/DVD/Set-top Box Select an input signal. Press the SOURCE button on the remote control to select the input signal.

  • Page 19: Watching Av Outputs

    Watching AV Outputs Connect to the external device if you record the broadcasting. • When you set the input signal of the main screen as 'AV (CVBS)', you can transmit the signal that you're watching to the AV output terminal. Product Video/TV/Product...
  • Page 20 Selecting and Adjusting the Screen Name of the Buttons in the Screen Adjustment Unit • Press this button to turn on the power. Press this button again to Power Button turn it off. • This Indicator lights up green when the display operates normally(on Power Indicator mode).
  • Page 21 Name of the Buttons in the Screen Adjustment Unit [For PC Analog signal] AUTO/SELECT Button [Other signals] • The current signal and mode information will be displayed. SOURCE Button • Select the input signal Composite Video S-Video Separate Video Component 1 HDTV Component 2 RGB1...
  • Page 22 Selecting and Adjusting the Screen OSD Menu Icon Function Description Adjusts screen brightness, contrast and color that you prefer. PICTURE Adjusts the audio function. SOUND Adjusts the screen status according to the circumstances. SPECIAL Adjusts the screen video. SCREEN Adjusts PIP/POP/PBP mode function. PIP/POP/PBP Note OSD(On Screen Display)
  • Page 23 How to adjust the OSD (On Screen Display) screen Save Pops up Move where Move where Exit from the Select a Select a Adjust the status adjustment the menu you want to you want to menu screen. menu icon menu icon adjust screen adjust...
  • Page 24 Selecting and Adjusting the Screen Adjusting Screen Color AV/S-Video/Component 1/ EZ Video Component 2 input only The EZ Video function automatically adjusts the screen image quality depending on the AV usage environment. • Dynamic : Select this option to display with a sharp image. •...
  • Page 25 Adjusting Screen Color RGB1, 2 / DVI input only • 6500K/9300K/3600K Selecting a factory setting color set. 6500K: Slightly reddish white. 9300K: Slightly bluish white. 3600K: Slightly yellowish white. • User : Select this option to use the user-defined settings. Contrast To adjust the contrast of the screen.
  • Page 26 Selecting and Adjusting the Screen Selecting the options Input If you press the button once, the following Input Signal Window will appear. Select the signal type you want using the button. Child Lock Use the buttons to select On or Off. The Set can be set up so that it can only be used with the remote control.
  • Page 27 Selecting the options To use this function • - Must be displayed with various other products. - Must be in a function that can be connected to RS-232C or RGB Out Tile mode It is used to enlarge the screen and also used with several products to view screen, Tile mode and choose Tile alignment and set the ID of the current product to set location.
  • Page 28 Selecting and Adjusting the Screen Selecting the options • Tile mode - Tile mode : row x column ( r = 1, 2, 3, 4 c = 1, 2, 3, 4) - 4 x 4 available. - Configuration of an integration screen is also available as well as configuration of one by one Display. - Tile mode (product 1 ~ 4) : r(2) x c(2) ID 1 ID 2...
  • Page 29 Selecting the options - Tile mode (product 1 ~ 2) : r(2) x c(1) ID 1 ID 2 column Reset Use this function to reset the product to the factory default. However, language selection will not be initialized. Selecting the options Set ID You can assign a unique Set ID NO (name assignment) to each product when several...
  • Page 30 Selecting and Adjusting the Screen Adjusting Screen CLOCK/PHASE and Position To select the image size of the screen. <AV/S-Video/Component 1, 2 input only> <RGB1, 2 / DVI input only> *When the Component 1 input signal is 720p or 1080i, the spectacle function is not supported. Auto- This button is for the automatic adjustment of the screen position, clock and phase.
  • Page 31 Adjusting PIP/POP/PBP Mode (Multiple Screen) Functions On/Off After selecting PIP in the PIP On/Off menu, the following menu items can be adjusted. After selecting POP in the POP On/Off menu, the following menu items can be adjusted. After selecting PBP in the PBP On/Off menu, the following menu items can be adjusted.
  • Page 32 Selecting and Adjusting the Screen Adjusting PIP/POP/PBP Mode (Multiple Screen) Functions Position To adjust the position to PIP screen. Swap To switch the main-screen and sub- screen in PIP/POP/PBP mode. SWAP SWAP...
  • Page 33 Troubleshooting No image is displayed ● Is the product power cord connected? • See if the power cord is properly connected to the outlet. ● Is the power indicator light on? • See if the power switch is turned on. ●...
  • Page 34 Troubleshooting The screen image looks abnormal. ● Is the screen position wrong? • D-Sub analog signal – Press the “AUTO” button in the remote control to automatically select the optimal screen status that fits into the current mode. If adjustment is not satisfactory, use the Position OSD menu.
  • Page 35 The audio function does not work. ● No sound? • See if the audio cable is connected properly. • Adjust the volume. • See if the sound is set properly. ● No sound is available when the • See if the Sound is set to On in the PIP/POP/PBP PIP/POP/PBP mode is engaged.
  • Page 36 Specifications The product specifications can change without prior notice for product improvement. LCD Panel [32 inch] 32 inches (80.04 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 80.04 cm 0.5025 mm (Pixel Pitch) [37 inch] 37 inches (94.03 cm) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel Visible diagonal size: 94.03 cm...
  • Page 37 The product specifications can change without prior notice for product improvement. Dimensions &Weight Width x Height x Depth [32 inch] [1] 80.30 cm (31.61 inches) x 54.00cm (21.26 inches) x 18.00 cm (7.09 inches) [2] 80.30 cm (31.61 inches) x 49.30 cm (19.4 inches) x 9.99 cm (3.93 inches) [3] 96.40 cm (37.95 inches) x 54.00cm (21.26 inches) x 18.00 cm (7.09 inches) [4] 96.40 cm (37.95 inches) x 49.30 cm (19.4 inches) x 9.99 cm (3.93 inches) [37 inch]...
  • Page 38 Specifications The product specifications can change without prior notice for product improvement. Dimensions &Weight [32 inch] [1] 19.4 kg (42.77 lbs) [2] 16.0 kg (35.27 lbs) [3] 21.1 kg (46.52 lbs) [4] 17.7 kg (39.02 lbs) [37 inch] [1] 26.7 kg (58.86 lbs) [2] 23.5kg (51.81 lbs) [3] 30.5 kg (67.24 lbs) [4] 25.7 kg (56.66 lbs)
  • Page 39 32/37/42 inch model The product specifications can change without prior notice for product improvement. Video Signal Max. Resolution RGB1 / RGB2 : 1600 X 1200 @60Hz DVI : 1280 X 1024 @60Hz – It may not be supported depending on the OS or video card type. Recommended Resolution RGB1 / RGB2 : WSXGA 1360 X 768 @60Hz DVI : WSXGA 1360 X 768 @60Hz –...
  • Page 40 Specifications 46 inch model The product specifications can change without prior notice for product improvement. Video Signal Max. Resolution RGB1 / RGB2 : 1920 X 1080 @60Hz DVI : 1920 X 1080 @60Hz Recommended Resolution RGB1 / RGB2 : WXGA 1920 X 1080 @60Hz DVI : WXGA 1920 X 1080 @60Hz Horizontal Frequency RGB1 / RGB2 : 30 - 83 kHz...
  • Page 41 PC Mode – Preset Mode [ 32/37/42 inch model ] Vertical Horizontal Vertical Horizontal Frequency Frequency Preset mode Frequency Frequency Preset mode (Hz) (Hz) (kHz) (kHz) 31.469 640 x 350 VESA 1024 x 768 60.123 31.468 720 x 400 VESA 1024 x 768 68.68 31.469...
  • Page 42 Specifications VESA wall mounting Connected to another object (stand type and wall-mounted type.) This product accepts a VESA- compliant mounting interface pad.- (optional) For further information, refer to the VESA Wall Mounting Instruction Guide. Kensington Security Slot- optional Connected to a locking cable that can be purchased separately at most computer stores...
  • Page 43 Controlling the Multiple Product RS-232C Use this method to connect several products to a single PC. You can control several products at a time by connecting them to a single PC. Connecting the cable Connect the RS-232C cable as shown in the picture. * The RS-232C protocol is used for communication between the PC and product.
  • Page 44 Command Reference List COMMAND1 COMMAND2 DATA(Hexa) 01. Power 00H - 01H 02. Input Select 02H - 08H 03. Aspect Ratio 01H - 06H 04. Screen Mute 00H - 01H 05. Volume Mute 00H - 01H 06. Volume Control 00H - 64H 07.
  • Page 45 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] * [Command 1]: First command. (j or k) * [Command 2]: Second command. * [Set ID]: You can adjust the set ID to choose desired product ID number in Special menu.
  • Page 46 Transmission / Receiving Protocol 01. Power (Command : a) To control Power On/Off of the Set. Transmission [k][a][ ][Set ID][ ][Data][Cr] Data 0 : Power Off 1 : Power On Acknowledgement [a][ ][Set ID][ ][OK][Data][x] To show the status of Power On/Off. Transmission [k][a][ ][Set ID][ ][FF][Cr] Data 0 : Power Off...
  • Page 47 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 03. Aspect Ratio(Command : c) (Manin picure format) To adjust the screen format. You can also adjust the screen format using the ARC (Aspect Ratio Control) button on remote control or in the Screen menu.
  • Page 48 Transmission / Receiving Protocol 05. Volume Mute(Command : e) To control On/Off of the Volume Mute. Transmission [k][e][ ][Set ID][ ][Data][Cr] Data 0 : Volume Mute On (Volume Off) 1 : Volume Mute Off (Volume On) Acknowledgement [e][ ][Set ID][ ][OK][Data][x] Data 0 : Volume Mute On (Volume Off) 1 : Volume Mute Off (Volume On) 06.
  • Page 49 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 07. Contrast(Command : g) To adjust screen contrast. You can also adjust the contrast in the Picture menu. Transmission [k][g][ ][Set ID][ ][Data][Cr] Data Min : 00H ~ Max : 64H Refer to ‘Real data mapping’...
  • Page 50 Transmission / Receiving Protocol 09. Color(Command : i) (Video only) To adjust the screen color. You can also adjust the color in the Picture menu. Transmission [k][i][ ][Set ID][ ][Data][Cr] Data Min : 00H ~ Max : 64H (Hexadecimal code) Acknowledgement [i][ ][Set ID][ ][OK][Data][x] Data...
  • Page 51 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 11. Sharpness(Command : k) (Video only) To adjust the screen Sharpness. You can also adjust the sharpness in the Picture menu. Transmission [k][k][ ][Set ID][ ][Data][Cr] Data Min : 00H ~ Max : 64H (Hexadecimal code) Acknowledgement [k][ ][Set ID][ ][OK][Data][x]...
  • Page 52 Transmission / Receiving Protocol 14. PIP/PBP/POP On/Off(Command : n) To control PIP/PBP/POP On/Off of the Set. Transmission [k][n][ ][Set ID][ ][Data][Cr] Data 0 : OFF 1 : PIP 2 : PBP 3 : POP Acknowledgement [n][ ][Set ID][ ][OK][Data][x] Data 0 : OFF 1 : PIP 2 : PBP 3 : POP...
  • Page 53 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 16. Balance(Command : t) To adjust the sound balance. Transmission [k][t][ ][Set ID][ ][Data][Cr] Data Min : 00H ~ Max : 64H (Hexadecimal code) Acknowledgement [t][ ][Set ID][ ][OK][Data][x] Data Min : 00H ~ Max : 64H * Balance : -50 ~ +50 17.
  • Page 54 Transmission / Receiving Protocol 18. PIP/PBP/POP SOURCE(Command : y) To select the sub-screen source. Transmission [k][y][ ][Set ID][ ][Data][Cr] Data 2 : AV 6 : RGB1 3 : S-Video 7 : RGB2 4 : Component 1 8 : DVI 5 : Component 2 Acknowledgement [y][ ][Set ID][ ][OK][Data][x] Data 2 : AV...
  • Page 55 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 21. Tiling Mode(Command : d d) Change a Tiling Mode. Transmission [d][d][][Set ID][][Data][x] Data Description Tiling mode is off. 1 x 2 mode(column x row) 1 x 3 mode 1 x 4 mode 4 x 4 mode * The data can not be set to 0X or X0 except 00.
  • Page 56 Transmission / Receiving Protocol 23. Tile V Position(Command : d f) To set the Vertical position. Transmission [d][f][][Set ID][][Data][x] * The data range is from 00 to 64(in Hex). Acknowledgement [f][][Set ID][][OK/NG][Data][x] 24. Tile H Size(Command : d g) To set the Horizontal size. Transmission [d][g][][Set ID][][Data][x] * The data range is from 00 to 64(in Hex).
  • Page 57 Controlling the Multiple Product RS-232C Transmission / Receiving Protocol 26. Tile ID Set(Command : d i) To assign the Tile ID for Tiling function . Transmission [d][i][][Set ID][][Data][x] * The data range is from 00 to 00 x 10 tile mode. Acknowledgement [i][][Set ID][][OK/NG][Data][x] 27.
  • Page 58 Transmission / Receiving Protocol *29. Temperature value Return(Command : d n) - Optional To read the inside temperature value. Transmission [d][n][][Set ID][][Data][x] * The data is always FF(in Hex). Acknowledgement [n][][Set ID][][OK/NG][Data][x] Data are 1 byte long in Hex ASCII format. *30.
  • Page 59 IR Codes RS-232C How to connect Connect your wired remote control to Remote Control port on the Product. Remote Control IR Code Output waveform single pulse, modulated with 37.917KHz signal at 455KHz Carrier frequency FCAR = 1/Tc = fosc/12 Duty ratio = T1/Tc = 1/3 Configuration of frame •...
  • Page 60 Code(Hexa) Function Note ▲ R/C Button ▼ R/C Button VOL( ) R/C Button VOL( ) R/C Button POWER ON/OFF R/C Button(Power On/Off) POWER ON Discrete IR Code(Only Power On) POWER OFF Discrete IR Code(Only Power Off) MUTE R/C Button Number Key 0 R/C Button Number Key 1 R/C Button...
