34 Appendix C - LED Patterns and Test Switch Settings

Other Indicators (on All LED Bars)

5,6 flashing: Router stacks starting up
3,4 & 7,8 flashing: No OS loaded. Running from ROM.
5,6 on solid, 2 (bars 1 & 3) and 9 (bars 2 & 4) flashing: Erasing OS in
Flash ROM
4,5,6,7 on solid, 2 (bars 1 & 3) and 9 (bars 2 & 4) flashing: Erasing
config in Flash ROM
Scanning from 2 to 9 (bars 1 & 3), and scanning from 9 to 2 (bars 2 &
4): Flash ROM erase due to switch setting five or six is complete. Set
switch to zero and cycle power.
Note: Any continuous flashing pattern not noted in this chapter may
v
be caused by a hardware failure. Please call Compatible Systems Tech-
nical Support if your router shows a hardware failure.

MicroRouter 1250i Switch Settings

0 Normal Operation
1 Unused*
2 Unused*
3 Run Boot ROM Downloader
4 Unused*
5 Erase Flash ROM (OS and Configuration)
6 Erase Flash ROM (Configuration Only)
7 Unused*
8 Unused*
9 Allow letmein password for 5 minutes after powerup
Caution: Settings marked with an asterisk may erase your Flash
M
ROM. Please do not use these settings without first contacting
Compatible Systems Technical Support.
