operating for the first time

Choosing utensils for gas and electric hotplates
Refer to diagram below
GOOD BAD
GOOD BAD BAD BAD
(recessed base) (convex base)
(recessed base) (convex base)
Installation and service warning
WARNING
• Only an authorised person must install and service this
appliance (Certificate of Compliance to be retained)
• In order to avoid tipping of appliance the anti-tilt plate
MUST be installed
• Appliances requiring connection to 230 – 240V MUST
be earthed
• An authorised person should inspect this appliance
every 5 years
• This appliance must NOT be installed on a base, box or
in a closed cupboard
• If the electrical supply cord is damaged, a qualified
person MUST replace the cord to avoid a hazard or
void your warranty
WARNING
• Surrounding kitchen cabinets MUST
WITHSTAND 85°C
• In order to avoid a hazard the installation instructions
MUST be followed.
4 OPERATING FOR THE FIRST TIME Chef 540 Upright Cooker
BAD BAD
BAD BAD BAD BAD
(undersize) (oversize) (moisture on hotplate)
(undersize) (oversize) (moisture on hotplate)
Before operating first time
TIPS & INFORMATION
1. Read all the Warning and Safety information.
2. Remove all internal boxes and bags from oven.
3. Clean out the oven interior with detergent and hot water
and polish with a soft cloth. DO NOT close oven door
until the oven is completely dry.
4. New appliances can have an odour during first
operation. It is recommended to 'run in' the oven before
you cook. Run the oven at 180°C for 2 – 4 hours and
ensure that the room is well ventilated.
5. If your appliance is fitted with solid hotplates, turn
heat setting to high for 3 minutes to fully harden the
hotplate coating.

installing your oven accessories

Fitting oven shelves
1. Ensure shelf orientation is correct (refer to diagram below).
2. Slide oven shelves onto oven supports (side runners) at an
angle until raised back of shelf is past the stop on oven
supports (side runners).
3. Lower front of shelf and push in until stop is reached.
4. To remove oven shelves, withdraw to the stop and raise
the front of shelf to clear the stop.
BAD BAD
(no utensil)
(no utensil)
Oven shelf location
Not a shelf
position
5
4
3
2
1
NOTE: the top ledge is not a shelf position.
There are no stops for shelf withdrawal.
Fitting the grill dish
Separate Grill: Ensure rear of the dish is engaged with the
side support before sliding backwards. To remove, simply
pull forwards and upwards.
To ensure proper grill operation, slide the grill dish fully
rearward to the stop.
To remove, simply pull forwards and upwards.
Engagement of
rear of dish
Grill in Oven: see Fitting Oven Shelves
The grill dish with wire insert can be used in any of the two upper
height positions (shelf positions 4 and 5) between the runners.
NOTE: You must remove the grill dish when baking in the oven.
Replacing the oven light
warning WARNING
Ensure the appliance is switched off at power supply (not just
Note the orietaton of the
the control knobs) before replacing the light globe to avoid
side and rear features
possibility of electric shock.
Turn light anti-clockwise
to remove it for globe
Assemble grill tray handle
Assemble grill tray handle
Chef 540 Upright Cooker INSTALLING YOUR OVEN ACCESSORIES 5
Engagement of rear of dish
