- Page 1 User’s manual – A S Eco String trimmer 5 in 1 REBO ECO string trimmer 5in1 AR-HE-MT51ET Please follow all security measures in this user’s manual to ensure a secure use. Thank you for trusting AREBOS.
-
Page 2: Table Of Contents
User’s manual – A S Eco String trimmer 5 in 1 REBO List of contents 1. Safety instructions ..........3 1.1 Explanation of the symbols ..........3 1.2 Safety rules ..............5 2. Parts list ..............6 3. Intended Use ............7 4. -
Page 3: Safety Instructions
User’s manual – A S Eco String trimmer 5 in 1 REBO Please read and safe these instructions. Read through this user’s manual carefully before using this product. Protect yourself and others by observing all safety information, warnings and cautions. Failure to comply with instructions could result in personal injury and/or damage to product or property. - Page 4 User’s manual – A S Eco String trimmer 5 in 1 REBO Warning! Wear protective gloves! Warning! Wear protective gloves! Warning! Wear protective clothing! Warning! Flammable material! Pay attention to flying stones! Pay attention to pedestrians! Do not touch the utility pole!
-
Page 5: Safety Rules
User’s manual – A S Eco String trimmer 5 in 1 REBO Please note the sound power level. 1.2 Safety rules • Read the instruction manual carefully before using the unit. This applies in particular to the safety instructions. Otherwise you may injure yourself or damage the device. •... -
Page 6: Parts List
User’s manual – A S Eco String trimmer 5 in 1 REBO • Perform continuous checks to ensure safe and efficient operation of the machine. For a complete check, please contact a specialist workshop. • Keep the machine away from fire or sparks. •... -
Page 7: Intended Use
User’s manual – A S Eco String trimmer 5 in 1 REBO 3. Intended Use • Motor brush (use the cutting knife): Cutting of light wood, strong weeds and undergrowth. • Lawn trimmer (use the thread bobbin with cutting thread): Cutting lawns, grass areas and light weeds. - Page 8 User’s manual – A S Eco String trimmer 5 in 1 REBO • Petrol: octane rating at least 91 RON, lead-free • When handling petrol and oil, increased attention should be paid. Smoking and open fire are not permitted (danger of explosion). •...
-
Page 9: Assembly
User’s manual – A S Eco String trimmer 5 in 1 REBO Draining gasoline • Make sure that no fuel or chain oil gets into the ground. Use a suitable surface. • Empty the tank only outdoors or in well-ventilated rooms. •... - Page 10 User’s manual – A S Eco String trimmer 5 in 1 REBO • Place the cutting disc (golden) on the rotor blade as shown. Place the bell on the rotor blade. • Attention: Left-hand thread! Turn the nut to the left to tighten. Tighten the left-hand thread as shown using the supplied Allen key.
- Page 11 User’s manual – A S Eco String trimmer 5 in 1 REBO • Then screw the bobbin attachment to the left onto the thread, hexagon wrench can then be removed. In the next step, pull the fixing bolt to make the joint flexible. •...
- Page 12 User’s manual – A S Eco String trimmer 5 in 1 REBO • Insert the chain into the furrows of the saw blade and place the chain on the wheel from behind, making sure that the saw blade engages under the wheel at a slightly inclined angle. •...
- Page 13 User’s manual – A S Eco String trimmer 5 in 1 REBO • Place the red plastic housing over the saw blade as shown using the nut. • Changing the thread bobbin: Open the bobbin case by pressing in at the marked point and unscrewing the cover.
-
Page 14: Use Of Included Attachments & Cutting Tools
User’s manual – A S Eco String trimmer 5 in 1 REBO • Insert the spring in the middle again and place the nut washer on it. Adjust the threads as desired and allow them to protrude laterally through the openings provided. 6. -
Page 15: Mowing With Grass Trimmer
User’s manual – A S Eco String trimmer 5 in 1 REBO 6.2 Mowing with grass trimmer • Use the thread cassette to obtain a clean cut even on uneven edges, fence posts and trees. • Carefully guide the trimming thread towards an obstacle and cut with the thread tip around the obstacle. -
Page 16: Maintenance
User’s manual – A S Eco String trimmer 5 in 1 REBO 7. Maintenance 7.1 Regular inspections • Attention! Always wear protective gloves when working on and around cutting tools. When not in use, during transport or storage, always fit transport protection to all cutting tools. Always switch off the engine and remove the spark plug connector before carrying out maintenance or cleaning work. -
Page 17: Cleaning The Air Filter
User’s manual – A S Eco String trimmer 5 in 1 REBO • Replace the spark plug: every 100 hours or 1x a year (depending on which case occurs first) if the insulation body is damaged with strong electrode erosion for heavily soiled or oily electrodes 7.3 Cleaning the air filter •... -
Page 18: Troubleshooting
User’s manual – A S Eco String trimmer 5 in 1 REBO 8. Troubleshooting - Air filter dirty. - Clean/replace air filter. - Fuel filter blocked. - Clean or replace fuel filter. - Lack of fuel supply. - Fill it up. - Fuel line fault. -
Page 19: Technical Data
- Adjusting the chain tension. work. Chain blunt. - Have the chain sharpened again or replace it. 9. Technical data Model AR-HE-MT51ET Tank capacity 900 ml Weight 27 lbs (12.4 kg) Fuel Petrol/Oil mixture 40:1 with 2-stroke oil Drive shaft... -
Page 20: Disposal Instruction
User’s manual – A S Eco String trimmer 5 in 1 REBO 10. Disposal instruction 10.1 Disposal of the packaging • Please make reference to the guidelines and standards for appropriate disposal of the packaging valid in your region. In part, the package may consist of plastic bags - watch this respect, with special care to ensure that this is not out of the reach of children. - Page 21 Hereby declare that the product named below, seen its design and construction as well as according to our sales, has been complied with the relevant and basic health and safety EU-requirements. Name of the product: Arebos Eco String trimmer 5in1 Art. Nr.: AR-HE-MT51ET Model Nr.: 4260627421091...
