4 Zone Rack Mounted Audio Base Station
DESCRIPTION
Models AP-8-RM is a non-alarming audio monitoring base stations mounted in a standard 19" rack for providing 8 audio
zones. The unit has the same amount of audio outputs (RCA) as it does for microphone inputs. Model AP-8-RM will
accommodate eight Louroe Microphones and has eight line level audio outputs. It contains a built-in speaker for
producing live audio and audio playback from a DVR. In addition, it has a selectable RCA audio output for interfacing with
a DVR with only one audio input, or with a VCR. Zone selection is by pushbutton. Contains a Mute switch that mutes the
audio of the remote microphones from being heard at unit's speaker. All Louroe microphones are compatible with the AP-
8-RM.
LOUROE ELECTRONICS 6 9 5 5 VA L J E A N AVENUE, VAN NUYS, CA 91406 TEL (818) 994-6498 FAX
®
8 ZONE RACK MOUNTED AUDIO BASE STATION
INSTALLATION AND OPERATING INSTRUCTIONS
Model AP-8-RM
Contents
AP-8-RM
AD-1
Dual RCA Cable
®
website: www.louroe.com
AP-8-RM
Description
U
listed 8 Zone Rack Mounted Audio
®
Base Station.
Used for listening to live audio
from microphone, as well as
audio playback from DVR's, VCR's
or other audio devices.
U
listed AC ADAPTER.
®
Supplies 12 Vdc to APR-1 and
Microphone.
RCA cable for connection to a
DVR/VCR or other Audio devices
that accept line level input
(0dB @ 600 ).
e-mail: sales@louroe.com
Page 1 of 8
Dual RCA Cable
AD-1 Power Supply
