AMERICA'S HIGHEST BEST REVIEWED ALUMINUM TRAILER MANUFACTURER
AS S E MB LY I N ST RUCTION S
ATV82x12-ATP
ATV82x14-ATP
WARNING
Read this INSTRUCTIONS before using this product.
Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
SAVE these instructions for future reference.
W W W . P R I M O T R A I L E R . C O M
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Primo Water ATV82x12-ATP
Summary of Contents for Primo Water ATV82x12-ATP
- Page 1 AMERICA’S HIGHEST BEST REVIEWED ALUMINUM TRAILER MANUFACTURER AS S E MB LY I N ST RUCTION S ATV82x12-ATP ATV82x14-ATP WARNING Read this INSTRUCTIONS before using this product. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury.
- Page 2 SAFETY & PRECAUTIONS DANGER Serious injury and/or property damage can result if this vehicle iys towed before familiarizing yourself with the instructions in the owners manual and cautions listed to the right. CAUTON BEFORE TOWING THIS TRAILER CHECK THAT: • Coupler hitch and trailer ball are the same size •...
-
Page 3: Safety And Precautions
SAFETY & PRECAUTIONS WARNING Uncoupling will cause trailer to come loose from tow vehicle. You must: 1. CHECK that ball LOAD HATING is same as or greater than coupler LOAD RATING. 2. CHECK that ball SIZE is same as coupler. 3. -
Page 4: Hardware List
PARTS, HARDWARE & TOOLS PART LIST PART NO. Main Front Passenger Driver Side Stainless steel Tailgate Fender Tire ITHEM frame Wall side wall side wall ramp corner cap HARDWARE LIST LABEL HW-4 HW-5 HW-6 HW-7 HW-8 HW-10 HW-12 Corner Front Middle Rear Legs Fender... - Page 5 PREPARATION STEP 1 Cut all zip ties and banding. Gather the hardware package, and HW-4 HW-5 HW-6 stainless-steel corner brackets. Gather both driver and passenger side fenders. Gather rear bifold tailgate. Layout side walls on their correct side HW-8 HW-10 HW-7 (driver, passenger, and front).
- Page 6 ASSEMBLYNG STEP 1 HW-7 Add drop bolts through all support legs of each side wall. HW-7 HW-6 HW-6 HW-6 HW-6 HW-12 HW-5 HW-12 HW-5 STEP 2 With bolts sticking through the side wall, hang and attach side walls to the main frame of the trailer.
- Page 7 ASSEMBLYNG STEP 4 Drop ATV side ramps into the side walls. STEP 5 After all sides are attached and hand tighten only, install stainless steel corner caps on pipe top corners of the side kit rails. HW-4 HW-4 ATV-ATP Assembly Instructions V:09/22...
- Page 8 ASSEMBLYNG STEP 6 Go through and tighten all nuts and bolts. STEP 7 Install tailgate. HW-10 HW-10 ATV-ATP Assembly Instructions V:09/22...
- Page 9 HEAD ASSEMBLYNG STEP 8 Bolt both driver and passenger side fenders onto the main frame of trailer. Once all 4 bolts are through, tighten. HW-8 HW-8 HW-8 HW-8 STEP 9 Using shrink wrap butt connectors, attach loose wire from fender to mainframe of trailer. Heat shrink.
- Page 10 ASSEMBLYNG STEP 10 Mount the tires on the axle. ATV-ATP Assembly Instructions V:09/22...
-
Page 11: Warranty
WARRANTY Primo Trailer MFG. Corp. Warranty Information 5-Year Limited Axle Warranty 3-Year Limited Frame Warranty 1-Year Bumper to Bumper Limited Warranty ****IMPORTANT**** Warranty registration Form MUST be filled out within 7 days of Trailer purchase! Please find under the resources tab at www.Primotrailer.com. Thank you! If, however, you encounter a breakdown somewhere on your journey, Primo also offers a limited one-year warranty. - Page 12 480- 378 -0800 2401 SOUTH 7 TH STREET, PHOENIX, ARIZONA 85034 Sales@primotrailer.com WWW.PRIMOTRAILER.COM...
