Summary of Contents for GTD GTD-LYS200 CW
- Page 1 LED Fresnel Spotlight GTD-LYS200 (CW/WW) User’s Manual Guangzhou GTD Lighting Technology Co., Ltd. Tel: +86-20-61808296 Fax: +86-20-61812282 www.gtd-lighting.com http://...
- Page 2 © 2017 GTD all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. GTD logo and identifying product names and numbers herein are trademarks of GTD. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
GTD-LYS200 (CW/WW) User Manual Contents Safety instructions ..................................3 General guidelines ..................................4 Packing and shipping .................................. 5 Unpacking ....................................... 5 Packing after use..................................... 5 Accessories ....................................5 Product introduction .................................. 6 Installation ....................................6 Clamps installation ..................................6 Device installation ..................................6 Power / Control connection ............................... -
Page 4: Safety Instructions
GTD-LYS200 (CW/WW) User Manual Safety instructions WARNING! Before using the fixture, read the latest version of the product user manual, paying particular attention to the safety instructions. Please check www.gtd-lighting.com for the latest revision/update of the user manual. The manufacture of this fixture, are not responsible for damages, resulting from misuse of this fixture, due to the disregard of the information printed in this user manual. -
Page 5: General Guidelines
Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not stick filters or other materials onto the lens. Do not modify the fixture or install other than GTD manufactured parts. ... -
Page 6: Packing And Shipping
GTD-LYS200 (CW/WW) User Manual Packing and shipping Unpacking Notes All products are quality controlled and checked for any faults before they are dispatched to customers. If the fixture is damaged during delivery, the customer must notify the shipper and manufacturer to file a damage insurance claim. -
Page 7: Product Introduction
GTD-LYS200 (CW/WW) User Manual Product introduction Handle Manual focusing Adjustable screw Lens Barn door module Safety cable mounting position DMX input DMX output Display 10 Fuse 11 Power switch Installation Clamps installation The fixture can be placed on the stage or mounted on the truss facing any direction. The fast-lock clamp gives a quick and easy lock on the truss. -
Page 8: Power/ Control Connection
GTD-LYS200 (CW/WW) User Manual Power/ Control connection Power connection Connection method: L (Live) Brown wire E (Earth) Yellow / Green bi-color wire N (Neutral) Blue wire The voltage and frequency of the power source must be in compliance with the ones marked on the fixture. It is strongly recommended that each fixture are to be connected to the power source separately so that they can be switched on / off individually. -
Page 9: Control Panel
GTD-LYS200 (CW/WW) User Manual Control panel The control panel with buttons and digital display can access the function menu and configure the fixture easily. Press MENU to check or modify the functions of the fixture; Press UP or DOWN to view or select the function menu. -
Page 10: Technical Specification
GTD-LYS200 (CW/WW) User Manual Technical specification Optical Light source: LED 200W, quantity: 1 piece（CW/WW） Expected average lifetime: 50000 hours Beam angle (zoom): LYS200 CW: 18° - 58° (10% peak angle), 9° - 33° (50% peak angle) LYS200 WW: 18° - 58° (10% peak angle), 10° - 36° (50% peak angle) Photometric ... - Page 11 GTD-LYS200 (CW/WW) User Manual Connections AC power: Neutrik powerCon DMX data input/output: Chassis 5-pin Neutrik XLR (in/out) Certification and Safety EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013 Safety: EN 60598-2-17:1989/A2:1991 Photometric LYS200 CW:...
-
Page 12: Cleaning And Maintenance
GTD-LYS200 (CW/WW) User Manual LYS200 WW: Cleaning and maintenance It is required that the fixture should be kept clean and well maintained to ensure its reliability. Its lifespan mainly depends on the working environment and proper operation. Should you have any questions, please consult a technical engineer of GTD Lighting. -
Page 13: Troubleshooting
GTD-LYS200 (CW/WW) User Manual If the LED lamp becomes damaged or deformed in any way it must be replaced. If the light from the LED lamp appears dim, this normally indicates that it is reaching the end of its life span and should be changed at once. -
Page 14: System Wiring Diagram
GTD-LYS200 (CW/WW) User Manual System wiring diagram LCR0006D LED+ LED- Thermal protector XLR board Fan3 SKL0006B Fan4 Fan2 Fan1 SDI0009C Power Switching power supply Thermosensitive GTD-LYS200 Spare parts list Item Notes Display board 5809210024B LYS200-101E11& 102G11 SDI0009C LED drive board... - Page 15 GTD-LYS200 (CW/WW) User Manual Notes: P/N: 1502011030A Time: May 3 , 2017...
