- Page 1 LED Fresnel Spotlight GTD-LYS300 (CW/WW) User’s Manual Guangzhou GTD Lighting Technology Co., Ltd. Tel: +86-20-61808296 Fax: +86-20-61812282 www.gtd-lighting.com http://...
- Page 2 © 2017 GTD all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. GTD logo and identifying product names and numbers herein are trademarks of GTD. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
GTD-LYS300 (CW/WW) User Manual Contents Safety instructions ..................................3 General guidelines ..................................4 Packing and shipping .................................. 5 Unpacking ....................................... 5 Packing after use..................................... 5 Accessories ....................................5 Product introduction .................................. 6 Installation ....................................6 Clamps installation ..................................6 Device installation ..................................6 Power / Control connection ............................... -
Page 4: Safety Instructions
GTD-LYS300 (CW/WW) User Manual Safety instructions WARNING! Before using the fixture, read the latest version of the product user manual, paying particular attention to the safety instructions. Please check www.gtd-lighting.com for the latest revision/update of the user manual. The manufacture of this fixture, are not responsible for damages, resulting from misuse of this fixture, due to the disregard of the information printed in this user manual. -
Page 5: General Guidelines
Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not stick filters or other materials onto the lens. Do not modify the fixture or install other than GTD manufactured parts. ... -
Page 6: Packing And Shipping
GTD-LYS300 (CW/WW) User Manual Packing and shipping Unpacking Notes All products are quality controlled and checked for any faults before they are dispatched to customers. If the fixture is damaged during delivery, the customer must notify the shipper and manufacturer to file a damage insurance claim. -
Page 7: Product Introduction
GTD-LYS300 (CW/WW) User Manual Product introduction Hanging rack Adjustable screw Block Light leaf Corrugated Mirror Display Adjustable screw DMX output DMX input power cable fuse 10 Power switch 12 Adjustable screw Installation Clamps installation The fixture can be placed on the stage or mounted on the truss facing any direction. The fast-lock clamp gives a quick and easy lock on the truss. -
Page 8: Power/ Control Connection
GTD-LYS300 (CW/WW) User Manual Power/ Control connection Power connection Connection method: L (Live) Brown wire E (Earth) Yellow / Green bi-color wire N (Neutral) Blue wire The voltage and frequency of the power source must be in compliance with the ones marked on the fixture. It is strongly recommended that each fixture are to be connected to the power source separately so that they can be switched on / off individually. -
Page 9: Control Panel
GTD-LYS300 (CW/WW) User Manual Control panel The control panel with buttons and digital display can access the function menu and configure the fixture easily. Press MENU to check or modify the functions of the fixture; Press UP or DOWN to view or select the function menu. -
Page 10: Dmx Protocol
GTD-LYS300 (CW/WW) User Manual Dimmer Dimmer =0~255 Dimmer channel value Value Setting Zoom Zoom=0~255 Zoom channel value M0:600hz Fade M1:600hz Snap M2:1200hz Fade Dimmer Mode Dimmer Mode Set M3:1200hz Snap M4:600hz Fade System Setting M5:600hz Snap Display Setting Backlight Time... -
Page 11: Technical Specification
GTD-LYS300 (CW/WW) User Manual Technical specification Optical Light source: LED 300W, quantity: 1 piece（CW/WW） Expected average lifetime: 50000 hours Beam angle (zoom): 20.9° - 49.3° Photometric Color temperature: 5400K~5800K(CW) / 2800K~3200K(WW) CRI: >96Ra Electrical ... - Page 12 GTD-LYS300 (CW/WW) User Manual EMC: EN 55103-1:2009, EN 55103-2:2009, EN 61000-3-2:2006+A2:2009, EN 61000-3-3:2013 Safety: EN 60598-2-17:1989/A2:1991 Photometric LYS300 CW: LYS300 WW:...
-
Page 13: Cleaning And Maintenance
GTD-LYS300 (CW/WW) User Manual Cleaning and maintenance It is required that the fixture should be kept clean and well maintained to ensure its reliability. Its lifespan mainly depends on the working environment and proper operation. Should you have any questions, please consult a technical engineer of GTD Lighting. - Page 14 GTD-LYS300 (CW/WW) User Manual Possible Cause Suggested Correction Problem power cables, luminaire power socket). socket for proper connection. No DC voltage from switching power Check if the switching power supply has DC voltage output. Replace supply. the switching power supply.
-
Page 15: System Wiring Diagram
GTD-LYS300 (CW/WW) User Manual System wiring diagram LED Drive High Power LED Transfer Board Focusing LED Fan Switch power Display magnetic susceptibility Switch power EDS360-4812P Power cable 1.0mm2 V+12 Focus Signal motor Caron fuse Power V+48 GTD-LYS300 Spare parts list... - Page 16 GTD-LYS300 (CW/WW) User Manual Appendix 1...
- Page 17 GTD-LYS300 (CW/WW) User Manual Notes: P/N: 1502011086A Time: Aug21 , 2017...
