- Page 1 USB-RS232-TTL-STICK Hardware-Description 2023 February...
- Page 2 INDEX 1. Introduction 1.1. Foreword 1.2. Customer satisfaction 1.3. Customer response 1.4. Brief description 2. Hardware description 2.1. Technical data 2.2. 3 pin connection cable 2.3. LED's 3. Software 3.1. “VCP Driver (Virtual COM-Port)” Installation 4. Appendix 4.1. Contact / Support 4.2.
- Page 3 Introduction Introduction | Seite...
-
Page 4: Customer Satisfaction
1. Introduction 1.1. Foreword Congratulations on purchasing a high quality DEDITEC product! Our products are developed by our engineers according to today's required quality standards. We pay attention already during the development to flexible expandability and long availability. We develop modular! -
Page 5: Brief Description
1.4. Brief description This USB to RS-232 converter (TTL-Level) is suitable for e.g. debugging on microcontroller circuits. Also your processor board will be protected by galvanic isolation. This little USB-Stick transmits serial data with TTL-Level (e.g. debugging informations) on the USB port. Normally there are only TTL-Signals available on serial ports by processors. -
Page 6: Hardware Description
Hardw are description Hardware description | Seite... - Page 7 2. Hardware description 2.1. Technical data +5V power supply (USB-BUS) · USB to RS-232 (TTL-Level) · A LED for TX and RX · Galvanically isolated · 50 Baud ..3MBaud (configurable per software) · Windows VCP (Virtual COM Port) · Linux Driver inclusive ·...
- Page 8 2.2. 3 pin connection cable The connection to the stick on the RS-232 side will be made by a 3pin connection cable. The ends of the wires are labeled with "RX", "TX" and "GND". RS-232 Pin Assignment Brown White Green 2.3.
- Page 9 Softw are Software | Seite...
- Page 10 3. Software 3.1. “VCP Driver (Virtual COM-Port)” Installation Insert the DEDITEC driver CD in your CD drive and start “vcp_driver_install.exe”. The “VCP driver (Virtual COM-Port)” software is also available at our homepage >here<. Software | Seite...
- Page 11 Press “Install”. The driver will be installed. Software | Seite...
- Page 12 The “VCP Driver (Virtual COM-Port)” Software has been installed now. Press “Close” to finish installation. Software | Seite...
- Page 13 Appendix Appendix | Seite...
-
Page 14: Contact / Support
Support Hardware Tel. +49 (0) 22 32 / 50 40 8 – 30 Support via E-mail support@deditec.de 4.2. Environment and disposal You can return the defective or obsolete product to us at the end of its service life. As a manufacturer and distributor of electronic assemblies, we will take care of the proper disposal for you in accordance with the applicable legal regulations. - Page 15 4.3. Revisions Rev 3.01 DEDITEC Design Update 2022 Rev 3.00 DEDITEC Design Update 2021 Rev 2.01 Index added Rev 2.00 Design change Rev 1.00 First DEDITEC Instruction Appendix | Seite...
-
Page 16: Copyrights And Trademarks
4.4. Copyrights and trademarks Linux is a registered trademark of Linus Torvalds. USB is a registered trademark of USB Implementers Forum Inc. LabVIEW is a registered trademark of National Instruments. Intel is a registered trademark of Intel Corporation. AMD is a registered trademark of Advanced Micro Devices, Inc. ProfiLab is a registered trademark of ABACOM Ingenieurbüro GbR.
